- Page 1 MORAGA Installation Manual SOLTECH Designs and Manufactures Advanced, Solar-Powered LED Technology.
- Page 2 MORAGA 18W...
-
Page 3: Table Of Contents
Contents Introduction Battery Notes Installation and Wiring Compliance Installation Remote Control Guide... -
Page 4: 1 Introduction
01 Introduction Thank you for purchasing MORAGA Urban Lighting Products. Select the right operating mode according to the local legislation needs Introduction and the local sunshine conditions. Keep it away from shadows. Incorporated with a simplified cosmetic appearance, MORAGA combines the latest technology of Superior batteries, efficient solar panels, and Please save these instructions. - Page 5 MORAGA 18W Round Non-Tapered Steel Pole—10Ft SWJRS4001110-BK-3-BC CATALOG LOGIC CODE EXPLANATION SERIES: Round Non-Tapered Steel Poles BASE DIAMETER: 4.0" Base Bottom Diameter GAUGE: 11 Gauge Thickness NOMINAL HEIGHT: 10 Feet Tall FINISH: Black Finish Colors MOUNTING DESIGNATION: 2 7/8” OD Tenon OPTIONS: Base Cover HEIGHT...
-
Page 6: Battery Notes
02 Battery Notes 1. The Superior-battery-powered MORAGA lights are visibly brighter Storage than other outdoor solar lights, and their performance overall is To avoid over discharge of the battery during storage, please recharge more reliable. the lighting fixture every 3 months. Use the dedicated charger to charge, reset the switch when done. -
Page 7: Installation And Wiring Compliance
03 Installation and Wiring Compliance 1. Installation and wiring must comply with the State and National 4. Before installation, if applicable, please ensure the light pole and its Electrical Codes. foundation are solid enough to withstand the lighting fixture(s). 2. The MORAGA 18W model is intended for outdoor use only and 5. -
Page 8: Installation
04 Installation Pole Mount Connect the light head holder Tilt the light head, place the with the light head, and rotate screw on the T shape wrench. the holder to the right position. Install the 4pcs of M8*40mm Light Head There should be NO gap screws screw inside of the light between the light head and... - Page 9 Place the light head on top Press the ON/OFF Button on the of the pole and tighten the two light head to turn the light on. M8* 16mm screws by T shape Then use remote control to set wrench into proper position. the lighting mode.
-
Page 10: Remote Control Guide 010
05 Remote Control Guide 1. On/Off 2. Connect/Test 3. 40%~100% Motion 4. 20%~80% Motion Sensor Mode Sensor Mode (Default) 5. Night Owl Mode 6. Early Bird Mode 7. 100% Constant Mode 10. Timer Mode Disabled 8. 70% Constant Mode 9. 40% Constant Mode 12. - Page 11 3. 40%~100% Motion Sensor Mode 5. Night Owl Mode Constant 40% brightness (turns on at dusk, turns off at dawn); Changes as natural light decreases/increases (turns on at dusk); 70% 100% brightness turns on for 2 minutes when motion is detected. brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 hours (turns off at Dawn).
- Page 12 05 Remote Control Guide 7. 100% Constant Mode 8. 70% Constant Mode 100% brightness from dusk to dawn. 70% brightness from dusk to dawn. 9. 40% Constant Mode 40% brightness from dusk to dawn. 10. Timer Mode Disabled Press this button to turn off Timer Mode; settings revert back to before Timer Mode was last activated.
- Page 13 11. Timer Mode 4 Hours 12. Time Mode 8 Hours This is an additional mode which can work with any other modes. This is an additional mode which can work with any other modes. For example: press this button at any time after you turn on 70% For example: press this button at any time after you turn on 70% Constant Mode.
- Page 14 MORAGA products are covered by a 3 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 3 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
