Summary of Contents for Ryobi R18PLP130

  • Page 1 FRONT PAGE R18PLP130...

  • Page 2: Intended Use

    ■ When operating a power tool outdoors, use an IMPORTANT! extension cord suitable for outdoor use. Use of a It is essential that you read the instructions in this manual cord suitable for outdoor use reduces the risk of electric before assembling, operating, and maintaining the shock.
  • Page 3 tool or these instructions to operate the power tool. CORDLESS POLE LOPPER SAFETY WARNINGS Power tools are dangerous in the hands of untrained users. WARNING! Keep hands away from the blade. Contact with the blade will result in serious personal injury. ■...

  • Page 4: Additional Safety Warnings

    between cutting positions. Carefully adjust the harness ■ When transporting the product in a vehicle, secure it to comfortably help to support the weight of the product. against movement or falling to prevent injury to persons Identify the quick-release mechanism and practice using or damage to the product.

  • Page 5: Symbols On The Product

    SYMBOLS ON THE PRODUCT Safety alert Read and understand all instructions before operating the product. Follow all warnings and safety instructions. Wear eye, ear, and head protection. Wear non-slip, heavy duty protective gloves. Wear non-slip safety footwear when using the product. Do not expose the product to rain or damp conditions.
  • Page 7 R18PLP130 Pivoting button C-clip Cutting blade Telescopic pole Front handle Harness hangers Lock-out trigger On/Off trigger Rear handle Shaft coupling Blade cover Telescopic release latch Operator's manual Harness Extension pole Battery pack Charger Know your product...
  • Page 8 Wear eye, ear, and head protection Connect the telescopic pole connection to the powerhead pole connection point. while operating the product. When handling the blade assembly, wear non-slip, heavy-duty gloves. Wear non-slip safety footwear that will protect your feet and improve your footing on slippery surfaces.
  • Page 9 Slide the shaft coupling downwards Connect the pole lopper attachment to the telescopic pole. Turn the shaft coupling and turn it counterclockwise to secure clockwise to secure the connection. the connection. Remove the blade cover. On the powerhead, slide the lock-out Insert the battery pack into the battery trigger forwards and squeeze the on/off port until the latches click into place.
  • Page 10 Operating the Installing the Cleaning the p.11 p.14 p.18 product extension pole product 32mm Replacing the Storing the p.16 p.19 blade product...

  • Page 11: Operating The Product

    ≤60˚ ≥15m (50 ) 32mm OPERATING THE PRODUCT DANGER! Risk of electrocution! Do not operate within 10 m of overhead electrical lines. Position the product at an angle of 60° or less, depending on the specific situation. Keep bystanders at least 15 m away. WARNING: Always use two hands to operate the product.
  • Page 12 3. Connect the pole lopper attachment to the telescopic pole. Turn the shaft coupling clockwise to tighten. 4. Press the pivoting button to adjust the working angle. The working angle of the pole lopper can be adjusted to 75°. 5. Remove the blade cover. WARNING: Keep bare hands away from the blades at all times.
  • Page 13 8. On the powerhead, slide the lock-out trigger forwards and squeeze the on/ off trigger to power on the product. Use the product for cutting and pruning small limbs and branches. NOTE: Use the hook for removing loose branches or for stabilising the product before cutting.
  • Page 14 INSTALLING THE EXTENSION POLE 1. Press the latches and remove the battery pack from the battery port. 2. Connect the extension pole to the telescopic pole. Turn the shaft coupling clockwise to secure the connection. 3. Connect the pole lopper attachment to the extension pole.
  • Page 15 WARNING: Always use two hands to operate the product. Hold the product with one hand on the front handle and the other hand on the rear handle. 6. Insert the battery pack into the battery port until the latches click into place. 7.

  • Page 16: Replacing The Blade

    REPLACING THE BLADE 1. Press the latches and remove the battery pack from the battery port. 2. Remove the C-clip using long nose pliers. 3. Remove pin. Turn counterclockwise using wrench. Remove the nut. 4. Remove the bolt. 5. Remove the used cutting blade and dispose of it properly.
  • Page 17 6. Install the bolt and nut. 7. Turn the nut clockwise using a wrench. Install the pin. 8. Install the C-clip using long nose pliers. Maintenance...

  • Page 18: Cleaning The Product

    CLEANING THE PRODUCT 1. Press the latches and remove the battery pack from the battery port. 2. Clean the product with a soft, dry cloth. Do not use water and soap to clean the product. 3. Lubricate the blades lightly before and after use.

  • Page 19: Storing The Product

    STORING THE PRODUCT WARNING: Remove all foreign materials from the product before storing. 1. Press the latches and remove the battery pack from the battery port. 2. Turn the shaft coupling on the telescopic pole counterclockwise, remove the pole lopper attachment from the telescopic pole.

  • Page 20: Product Specifications

    RB1840C, RB1840X, RB18L13, RB18L26, RB18L15, RB18L15A, RB18L15B, RB18L20, RB18L20A, RB18L25, RB18L25A, RB18L30, RB18L30A, RB18L40, RB18L40A, RB18L50, RB18L50A, RB18L60, RB18L60A, RB18L90, RB18L90A REPLACEMENT PARTS Blade assembly 205378001 NOTE: Visit your local special orders desk or contact RYOBI customer service for replacement parts.
  • Page 24 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149 Melbourne, Australia Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. 961478323-01...
