- Page 1 NORDcanopy HU Installation, use and maintenance manual www.nordcooking.com...
-
Page 2: Table Of Contents
® NORDcanopy | HU Contents 1. In the kit 2. Hanging the kitchen canopy 3. Leveling the canopy 4. Opening the front panel 5. Fastening kitchen canopy sections together 6. Installing the steam filters 7. Connecting the condensation drain 8. Lighting connection 9. -
Page 3: In The Kit
® NORDcanopy | HU 1. In the kit 1 – Supply air adjustment plate 2 – Supply air connection 3 – Exhaust air connection 4 – Exhaust air adjustment plate 5 – Suspension points 6 – Lighting 7 – Front panel 8 –... -
Page 4: Hanging The Kitchen Canopy
25.08.2020 Teostas Nimetus: HU juhendi joon Kontrollis Safety Kinnitas Tähis: LEHT: ETS NORD AS It is prohibited to hold or add additional weight on 1 / 1 the top of the canopy. 2. Hanging the kitchen canopy M5/10 www.etsnord.com RDM-038-0524... -
Page 5: Leveling The Canopy
® NORDcanopy | HU 3. Leveling the canopy Is performed for each section. 4. Opening the front panel ø6 The panel locks automatically. ATTN! At the end of the installation, make sure that the panels are correctly fixed. 5. Fastening kitchen canopy sections together 5.1 Sequential connection M5/10 ø4/16... -
Page 6: Installing The Steam Filters
® NORDcanopy | HU 5.2 Installation of the ceiling panel between the sections M5/10 ø4/16 6. Installing the steam filters www.etsnord.com RDM-038-0524... -
Page 7: Connecting The Condensation Drain
® NORDcanopy | HU 7. Connecting the condensation drain 3/8" 3/8" 8. Lighting connection ATTN! Performed by electrician. Images are for illustrative purposes. RDM-038-0524 We reserve the right to make changes. -
Page 8: Measuring And Adjusting Airflow
® NORDcanopy | HU 9. Measuring and adjusting airflow NORDcanopy canopies are fitted with measuring nozzles located inside the canopy. ATTN! During measurement, HFU steam filters must be fitted and front panel must be closed. In order to adjust supply airflow, the position of the adjusting plate, located in the supply chamber, is adjusted. =k√∆p *The supply panels k-factor contain the “AirGrip”... -
Page 9: Accessories
® NORDcanopy | HU 10. Accessories 10.1 Cover plates 1 – Side panel support 2 – Island canopy side panel 3 – Wall installation canopy side panel L/R 4 – Front panel 5 – Section beam (sequential connection) 10.2 Installing the cover plates A –... -
Page 10: Kitchen Canopy Maintenance
® NORDcanopy | HU C – Sectional canopy cover plates 11. Kitchen canopy maintenance All internal and external surfaces of the kitchen canopy, including light fixtures, are cleaned using neutral clean- ing agents. Carefully rinse the surfaces after cleaning, in order to avoid harmful interactions of cleaning agents and high temperatures. - Page 11 21363 Malmö Sweden Phone: +46 40-94 68 70 Address: Förrådsvägen 5 151 58 Södertälje Sweden Phone: +46 8 550 301 40 info@etsnord.se www.etsnord.se ETS NORD International info@etsnord.com www.etsnord.com ETS NORD Ventilation Manufacturing LLC UAE Sepin Rayo sepin.rayo@etsnord.com +971 5257 02916...
