Toto DUROPLAST ECO TCW09S Quick Installation Instructions

SPECIFICATIONS
G
½
140~160
G
½
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.5 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc )
ATTENTION
Don't use abrasive cleaners or solvents on faucets and fittings.
1.
2. As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the basic
installation principles are the same.
3. Don't remove the flow regulator because it will damaged the
system.
Flow regulator
S060192R
DAILY CARE
Cleaning the main unit, toilet seat and lid.
503
■ Wipe the components with a soft damp cloth.
* Wet and wring out a soft cloth for wiping the surface of the
282.4
component
■ Cleaning very dirty components.
* Wet a soft cloth with diluted dish detergent and wipe down
the component surfaces.
* Then wipe off the detergent solution with a damp cloth.
■ If toilet bowl cleaner gets on the plastic components.
* Wipe down the component surface with a wet cloth and
wipe dry
INSTALLATION
0 +30
477 26
0
-30
1
155
2
3
DUROPLAST ECO WASHER W/ BIDET FUNCTION
Bolt
Washer
Base Plate
Rubber
Bushing
Adjustment back and front.
Base
plate
(SOFT CLOSING MODEL)
4
With Joint
Joint
Strainer
Hose
Packing
MAINTENANCE
You can remove the eco-washer when cleaning the closet
TROUBLESHOOTING
PROBLEM
Spray unsatisfactory
1. STRAINER
TCW09S
Without Joint
Strainer
Ø13
CHECK
SOLUTION
POINT
1 Remove and clean
R5
