MIO
Single Outlet Shower with Riser Kit
IX300020CP & IX300025CP
Installation and Maintenance Instructions
Intatec Ltd
Airfield Industrial Estate
Hixon
Staffordshire
ST18 0PF
n this procedure document we have endeavoured to make the
I
information as accurate as possible.
Tel: 01889 272 180
We cannot accept any responsibility should it be found that
email: sales@intatec.co.uk
in any respect the information is inaccurate or incomplete or
web: www.intatec.co.uk
becomes so as a result of further developments or otherwise.
© Intatec Ltd 2024
Advertisement
Table of Contents
Related Manuals for intatec Inspiration MIO IX300020CP
Summary of Contents for intatec Inspiration MIO IX300020CP
- Page 1 Tel: 01889 272 180 We cannot accept any responsibility should it be found that email: sales@intatec.co.uk in any respect the information is inaccurate or incomplete or web: www.intatec.co.uk becomes so as a result of further developments or otherwise. © Intatec Ltd 2024...
- Page 2 MIO shower valve until the missing parts have been obtained. The shower valve is supplied with the two connectors, containing the filters and check valves, and the union nuts assembled to the body. © Intatec Ltd 2024...
-
Page 3: Technical Data
This type of installation must be carried out in accordance with Part G of the Building Regulations. Whilst pressures are theoretically equal (balanced) most unvented hot systems have a pressure reducing valve on the incoming cold water prior to the hot water storage vessel. © Intatec Ltd 2024... - Page 4 Pumps automatically. Where this is not available a negative head kit may be required to operate Cold Supply direct from mains the pump. Please consult the pump manufacturer’s installation requirements. © Intatec Ltd 2024...
- Page 5 The cold water flow rates may be much greater as they are generally unrestricted from the mains cold water supply. To ensure relatively balanced flow rates, we recommend that a pressure reducing valve or 6 l/min flow regulator is fitted in the cold water supply pipe. © Intatec Ltd 2024...
-
Page 6: Gravity System
If the cold supply to the shower is direct from the cold water mains and the hot water supply is gravity fed from the cold water cistern via the hot water cistern you MUST fit a pressure reducing valve or a 6 l/min flow regulator. © Intatec Ltd 2024... -
Page 7: Site Preparation
• Ensure there are no joint leaks before finishing the wall. • Isolation valves must be fitted in an accessible position to both the hot and cold supplies should the valve need to be isolated in the future for servicing. © Intatec Ltd 2024... -
Page 8: Fitting The Brackets
• Using a suitably sized spanner, tighten the union nuts taking care not to damage the finish on the shower valve, do not over tighten. Notes: The installation shown is for the pipework embedded in to the wall or for a stud wall. © Intatec Ltd 2024... - Page 9 • Refit the temperature control knob in the reverse order ensuring that the control knob is in line with square body section and the 38˚C temperature marking is on the upper surface as shown. PLEASE NOTE THAT ONCE CALIBRATED, THE SECURITY SETTING WILL ONLY BE 38˚C UNDER THE SUPPLY CONDITIONS USED FOR CALIBRATION. © Intatec Ltd 2024...
-
Page 10: Cartridge Replacement
Valves should be serviced annually which should include the following: 1 Cleaning the independent inlet strainers. 2 Cleaning and servicing the thermostatic cartridge - the complete cartridge must be removed. © Intatec Ltd 2024... -
Page 11: Problem Solving
Ensure the valve has not fail-safed, and check that there is hot and cold water flow to the valve. Ensure the check valves are not closed Shower is stiff to operate Build-up of limescale on flow control cartridge - service and de-scale © Intatec Ltd 2024... - Page 12 Wall Bracket Retaining Screw 45mm Wall Bracket Screw End Cap Handset Flexible Hose Spacer Lower Bracket Details 67.5 The diagram is for illustration purposes only as Inta reserves the right to change the design without notice © Intatec Ltd 2024...
- Page 13 Retaining Screw 45mm Wall Bracket Screw End Cap Push Button Handset Flexible Hose Spacer Lower Bracket Details 67.5 The diagram is for illustration purposes only as Inta reserves the right to change the design without notice © Intatec Ltd 2024...
-
Page 14: Slide Rail - Installation
Fix the lower wall bracket clip to the wall using the 45mm long screws provided. Position the upper wall bracket clip onto the wall and mark the position for the 2 retaining screws ensuring that it is vertically above the lower clip and the centre distance does not exceed 630mm. © Intatec Ltd 2024... - Page 15 Assemble the end caps (6) into the ends of the rail. Ensure the sealing washers are inserted into both ends of the flexible hose and connect the hose to the shower valve and the handset (10). Turn on the shower valve and check joints for leakage. © Intatec Ltd 2024...
-
Page 16: Supply Conditions
Introduction The thermostatic shower valve has been specifically designed and manufactured to meet the requirements of BS EN1 1 1 1:2017 and TMV2 Type Scheme. © Intatec Ltd 2024... -
Page 17: Recommended Outlet Temperatures
Failure to make provision within the pipe sizing etc. will affect the performance of the shower valve. © Intatec Ltd 2024... - Page 18 10˚C above the commissioned mixed water discharge temperature. 13. The fail-safe thermostatic shower valve must not be subject to any extreme temperature variations either during the installation or under normal operating conditions. © Intatec Ltd 2024...
- Page 19 The final temperature found during the test should not exceed the values quoted. 4.7 Record all the equipment used during the commissioning. 4.8 The mixed water temperature at the terminal fitting must never exceed 2˚C above the set temperature. © Intatec Ltd 2024...
-
Page 20: In Service Testing
• The sensing part of the thermometer probe must be fully submerged in the water to be tested. • Any thermostatic shower that has been adjusted or serviced must be re-commissioned and re-tested in accordance with the manufacturers’ instructions © Intatec Ltd 2024... - Page 21 Please leave this Manual for the User To activate your product warranty please visit www.intatec.co.uk and click on Product Registration Intatec Ltd Airfield Industrial Estate Hixon Staffordshire ST18 0PF Tel: 01889 272 180 email: sales@intatec.co.uk web: www.intatec.co.uk E & O.E 21-10-24 © Intatec Ltd 2024...
