Thermostatic Mixing Valves
61022CPB & 61028CPB
Intamix Pro V
Installation and Maintenance Instructions
Intatec Ltd
Airfield Industrial Estate
Hixon
Staffordshire
ST18 0PF
In this procedure document we have endeavoured to make the
information as accurate as possible.
Tel: 01889 272 180
We cannot accept any responsibility should it be found that in
Fax: 01889 272 181
any respect the information is inaccurate or incomplete or
email: sales@intatec.co.uk
becomes so as a result of further developments or otherwise.
web: www.intatec.co.uk
© Intatec Ltd. 2021
Advertisement
Table of Contents
Related Manuals for intatec Intamix Pro V 61022CPB
Summary of Contents for intatec Intamix Pro V 61022CPB
- Page 1 We cannot accept any responsibility should it be found that in Fax: 01889 272 181 any respect the information is inaccurate or incomplete or email: sales@intatec.co.uk becomes so as a result of further developments or otherwise. web: www.intatec.co.uk © Intatec Ltd. 2021...
- Page 2 61028CPB 13.0 l/min Kv value: 61022CPB 4.0 m 61028CPB 4.5 m Connections: 22mm & 28mm compression for copper pipe Note: Use BS EN 1057 R250 (half hard) copper pipe with compression joints to BS EN 1254-2 © Intatec Ltd 2021...
- Page 3 In the case of highly aggressive water, arrangements must be made to treat the water before it enters the thermostatic mixing valve, in accordance with current legislation. Otherwise, the TMV may become damaged and not operate correctly. © Intatec Ltd 2021...
- Page 4 It is essential that access to the valve or connections is totally unobstructed for any maintenance which may be required. The pipework to or from the valve must not be used to support the valve unless adequately supported. © Intatec Ltd 2021...
- Page 5 1. Using a suitably sized screwdrive unscrew the knob retaining screw. 2. Note the position of the lug on the body and the corresponding recess inside the knob. © Intatec Ltd 2021...
- Page 6 3. Limescale can be removed from internal components by immersion in a suitable de-scaling fluid. 4. When the components have been checked and maintained, the mixed water outlet temperature should be checked using a thermometer following the procedure detailed in the Commissioning section. © Intatec Ltd 2021...
- Page 7 Adverse effect created by other draw off points on the system. 4 No flow/reduced flow from valve i. In line filters are blocked. ii. Insufficient supply pressure. iii. Debris obstructing valve operation. iv. Valve requires servicing. © Intatec Ltd 2021...
- Page 8 To activate your product warranty please visit www.intatec.co.uk and click on Product Registration Intatec Ltd Airfield Industrial Estate Hixon Staffordshire ST18 0PF Tel: 01889 272 180 Fax: 01889 272 181 email: sales@intatec.co.uk web: www.intatec.co.uk E & O.E © Intatec Ltd 2021 26-04-21...
