Thank you for choosing BYD. To better use and maintain the vehicle, please read this
manual carefully before use and keep it for future reference.
Special instructions: BYD Auto Industry Co., Ltd. recommends that you choose genuine
spare parts and use, maintain, and repair the vehicle in accordance with this manual.
The use of non-genuine spare parts to replace or modify the vehicle will affect the
performance of the entire vehicle, especially its safety and durability. Vehicle damage
and performance issues caused thereby will not be covered by the warranty. In addition,
vehicle modifications may also violate national laws and regulations and local government
regulations.
Thank you for choosing BYD. Your valuable comments and suggestions are welcome. To
enjoy better services, please provide your accurate contact information. If there is any
change to the information, contact a BYD authorized dealer or service provider in a timely
manner to update the information in the system. You are also advised to pay attention to
the relevant national laws and regulations and local policies, and register the vehicle as
soon as possible; otherwise vehicle registration may fail.
The descriptions marked with the asterisk (*) in this manual are specific to only some
model configurations, and applicable only when the vehicle has these configurations. If
there is any difference with the vehicle you purchased, the configuration of the actual
vehicle shall prevail.
Pay attention to the "REMINDER", "CAUTION" and "WARNING" symbols in this manual, and
follow the instructions carefully to avoid injury or damage. These symbols are defined as
follows:
REMINDER
Items that must be observed to facilitate maintenance.
CAUTION
Items that must be observed to avoid damage to the vehicle.
WARNING
Items that must be observed to ensure personal safety.
is a safety mark to indicate an operation that should not be performed or an event
that should not happen.
Foreword
