R I V E R Q U I V E R
L O C K R E P L A C E M E N T
I N S T A L L A T I O N
I N S T R U C T I O N S
W W W. R I V E R S M I T H . C O M
@ R I V E R S M I T H U S A

Advertisement

loading
Need help?

Need help?

Do you have a question about the RIVER QUIVER and is the answer not in the manual?

Questions and answers

Related Manuals for RIVERSMITH RIVER QUIVER

Summary of Contents for RIVERSMITH RIVER QUIVER

  • Page 1 R I V E R Q U I V E R L O C K R E P L A C E M E N T I N S T A L L A T I O N I N S T R U C T I O N S W W W.
  • Page 2 CONTENTS INCLUDED PARTS & TOOLS NEEDED INSTALL THUMB CATCH ONTO TUMBLER STEP 1 - STEP 2 - INSERT TUMBLER INTO REEL BOX LID STEP 3 - INSTALL WASHERS AND TUMBLER NUT STEP 4 - CHECK ALIGNMENT, KEYS, AND LOCK NOTE: ALL DAMAGED LOCK PARTS MUST BE REMOVED PRIOR TO INSTALLING REPLACEMENT LOCK...

  • Page 3: Included Parts

    INCLUDED PARTS LOCK REPLACEMENT KIT KEYS TUMBLER NUT TUMBLER ALIGNMENT THUMB CATCH WASHER TOOLS NEEDED CHANNEL LOCKS OR LARGE PLIERS The SWIFTCAST Rod Holder is built and tested to the highest possible standards to securely transport and protect your gear, however it is not meant as a long term storage solution.
  • Page 4 STEP 1 Install Thumb Catch onto Tumbler Pre-assemble Thumb Catch onto the Tumbler. Ensure the catch is on the same side as the tumbler latch for proper installation. THUMB TUMBLER CATCH LATCH CATCH TUMBLER THUMB CATCH + TUMBLER COMPLETE ASSEMBLY...
  • Page 5 STEP 2 Insert Tumbler (with Thumb Catch) into tumbler hole on the Reel Box Lid. From the outside face of the Reel Box Lid, insert the Tumbler (with Thumb Catch installed) through the open tumbler hole. Quickly move to Steps 3-5 as the Tumbler is now loose and unsecured.
  • Page 6 STEP 3 Install the Washers and Tumber Nut onto Tumbler On the inside of the Reel Box Lid, first install the Alignment Washer. Then overtop the Alignment Washer, install the Tumbler Nut. Use a pair of channel locks or large pliers to securely tighten the Tumbler Nut. •...
  • Page 7 If secure, you are now LOCKED. LOADED. READY TO FISH. ENSURE LID USE KEY TO CHECK ENSURE LOCK IS CLOSES TIGHTLY LOCK MECHANISM WORKING NOTE: River Quiver must be locked in order to function properly.
  • Page 8 L I M I T E D L I F E T I M E WA R R A N T Y Riversmith takes pride in the products we manufacture and will warrant that all Rod Holders will be free from defects in workmanship and materials for the life of the product to the original purchaser (“you”), subject to the...
