Quick Installation Guide
TV-IP602WN
1.01

Advertisement

loading
Need help?

Need help?

Do you have a question about the TV-IP602WN and is the answer not in the manual?

Questions and answers

Summary of Contents for TRENDnet TV-IP602WN

  • Page 1 Quick Installation Guide TV-IP602WN 1.01...
  • Page 2 Table of Contents English 1. Before You Start Hardware Installation and Configuration Troubleshooting Wireless Tips Version 03.14.2011...
  • Page 3: System Requirements

    1. Before You Start Package Contents Ÿ TV-IP602WN Ÿ CD-ROM (Utility and User’s Guide) Ÿ Multi-Language Quick Installation Guide Ÿ 2 x 2dbi Detachable Antennas Ÿ Network Cable (1.5m/5ft.) Ÿ Mounting Kit Ÿ Power Adapter (12V DC, 1.5A) System Requirements A computer with a wired network adapter properly installed.
  • Page 4 2. Hardware Installation and Configuration Note: It is recommended that you configure the IP Camera from a wired computer. 1. Insert the Utility CD-ROM into your CD-ROM drive. 2. Click Run autorun.exe (Windows 7/Vista only). 3. Click Setup Wizard. 4. Click Next. Then follow the Setup Wizard instructions.
  • Page 5 6. Double click on the SetupWizard icon on your desktop. 7. Connect the provided network cable from one of your Router's network ports to the Ethernet port on the IP Camera. 8. Connect the Power Adapter to the IP Camera and then to a power outlet.
  • Page 6 13. If you would like to change the administrator password, click Change Password, enter a new password, retype the new password and then click Next. Leave Change Password unchecked if you do not wish to change the password. Note: 1. Setting a password prevents other users from accessing the TV-IP602WN's configuration.
  • Page 7 17. Click Next. 18. Please wait while the settings on your cameras are being saved. 19. Select By using wireless and then click Next. 20. Disconnect the RJ-45 cable. Verify that the LINK (RED) LED is lit and then click Next. Note: The TV-IP602WN will not work wirelessly until you disconnect the Ethernet cable from the back of the camera.
  • Page 8 22. Click on the following URL or click Link to open up the browser configuration. 23. Enter the User name and Password, and then click OK. By default: User Name: admin Password: admin 24. Right click on the information bar and select Install This Add-on for All Users on This Computer…...
  • Page 9 Install IPView Pro 2.0 in the Autorun window and refer to the User's Guide on the CD for more information. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register register your product Online at: Thank you for choosing TRENDnet...
  • Page 10 Troubleshooting I inserted the Utility CD-ROM into my computer's CD-ROM Drive but the installation menu does not appear automatically. What should I do? For Windows 7, if the installation menu does not appear automatically, click on the Windows Icon on the bottom left hand corner of the screen,, click the “Search programs and files”...
  • Page 11 Configuration. If you do not have a DHCP server on your network, the default IP address is 192.168.10.30. The default administrator ID and password is admin. If you still encounter problems or have any questions regarding the TV-IP602WN, please contact TRENDnet's Technical Support Department.
  • Page 12 Wireless Tips The following are some general wireless tips to help minimize the impact of interference within an environment. Assign your network a unique SSID Do not use anything that would be identifying like “Smith Family Network”. Choose something that you would easily identify when searching for available wireless networks. Do not turn off the SSID broadcast The SSID broadcast is intended to be on and turning it off can cause connectivity issues.
  • Page 13 There are a number of other environmental factors that can impact the range of wireless devices. 1. Adjust your wireless devices so that the signal is traveling in a straight path, rather than at an angle. The more material the signal has to pass through the more signal you will lose. 2.
  • Page 18 Copyright ©2011. All Rights Reserved. TRENDnet.
