PUIG 8549 Mounting Instructions

HONDA NC 700-750 S '12- / NC 700-750 X '12-
NO compatible with DCT ( Automatic Shifting gear)
M O U
RE F 8549
1 Person
15 min
EASY
ID PIEZA/PART
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
V3.0622
N T I N G
DESCRIPCIÓN
Paramanos derecho
Pieza derecha anclaje manillar Ø6.5
(se suministra montada)
Paramanos izquierdo
Pieza izquierda anclaje manillar Ø6.5
(se suministra montada)
Soporte derecho (R)
Soporte izquierdo (L)
Tornillo Allen M6x75 DIN 7991
Tornillo Allen M5x11 ISO 7380
Tornillo Allen M5x16 ISO 7380
Arandela de nylon M5x1
Arandela de goma Ø4,5 x Ø11,5 x 2mm
Tuerca gafrilada M5
(se suministra montada con las piezas 1-2-3-4)
Arandela de goma Ø30 x Ø6,5 x 1mm
Arandela de plástico Ø30xØ6
Tapón tornillo M5 ISO 7380
Tapón tornillo M6 ISO 7991
Kit adhesivos
www.puig.tv
www.puigusa.com
I N S T R
HANDPR OTEC TOR S
DESCRIPTION
Right handguard
Ø6.5 right handlebar anchoring part
(supplied mounted with handguard)
Left handguard
Ø6.5 left handlebar anchoring part
(supplied mounted with handguard)
Right support (R)
Left support (L)
M6x75 DIN 7991 Allen screw
M5x11 ISO 7380 Allen screw
M5x16 ISO 7380 Allen screw
M5x1 nylon washer
Ø4,5 x Ø11,5 x 2mm rubber washer
M5 special nut
(supplied already mounted on items 1-2-3-4)
Ø30 x Ø6,5 x 1mm rubber washer
Ø30xØ6 plastic washer
M5 ISO 7380 Allen screw cap
M6 ISO 7991 Allen screw cap
Stickers set
Pg. 1/4
info@puigusa.com
U C T I O N
SCREWDRIVER
QTY
1
1
1
1
1
1
2
4
4
8
8
4
2
2
8
2
1
