Kidde NC Series User Manual

NC Series Handheld Programmer User Guide
EN DA DE ES FR IT
1
EN: Installation Sheet
Figures
Figure 1: NC-D-PT Handheld Programmer
(1) BUS connector
Figure 2: Connecting to detectors
(1) Point detector terminals 1 and 3
(2) Beam detector terminals D1 and D2
Description
This installation sheet includes information on the NC-D-PT
Handheld Programmer.
The programmer is compatible for use with the Kidde
Commercial NC Series conventional point and beam detectors.
Use the programmer to:
• Configure conventional point detector sensitivity levels
• Configure conventional point detector status LED powered
indications
• Configure conventional beam detector sensitivity levels
• Configure conventional beam detector beam length
© 2024 Carrier. All rights reserved.
NL NO PT SV
2
Operation
Button functionality
The programmer button functionality is described in the table
below.
Button Function
Reset Press to wake the programmer after an automatic
shutdown [1]
Test Press to read the detector settings
Program Press to confirm a configuration change
Up Press to scroll up a list of values
Down Press to scroll down a list of values
Function Press to confirm the type of configuration to be
performed
Clear Press to clear the programmer LCD
[1] The programmer turns off after 100 seconds if no button is pressed.
1 / 27 P/N 3103030-ML • REV 001 • ISS 04JUN24
