Commercial Series Outdoor LPG Patio Heater
SAVE YOUR
RECEIPT!
Warranty claims
require proof of
purchase and
Before returning your item, our product support
other order
team is available via email, phone, or web chat.
information.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Item/Model #
60368, 60485, 61130, 61185, 61444, 61726, 61727, 61728, 61729,
61730, 61735, 61736, 61737, 61738, 61739, 61740, 61741, 61742,
61743, 62555, 62784, 62785, 62987, 63008, 63009, 63010
WARNING
FOR OUTDOOR USE ONLY!
DANGER
FOR YOUR SAFETY:
If you smell gas:
1. Shut off gas at the source.
2. Extinguish any open flames.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire
department.
DANGER
DANGER indicates an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury.
DANGER
Failure to comply with the precautions
and instructions provided with this heater
can result in death, serious bodily injury,
and property loss or damage from
hazards of fire, explosion, burn,
asphyxiation, and/or carbon monoxide
poisoning. Only persons who can
understand and follow the instructions
should use or service this heater.
Questions, problems, missing parts?
We can help!
Hablamos ingles y español.
ASSEMBLY / CARE & USE INSTRUCTIONS
This product can expose you to chemicals
including Carbon Monoxide, Lead, Chromium
(hexavalent compounds), Di(2-ethylhexyl)
phthalate (DEHP) and Diisononyl phthalate
(DINP), which are known to the State of
California to cause cancer and birth defects or
other reproductive harm. For more information,
go to www.P65Warnings.ca.gov.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance. An LP-cylinder not
connected for use shall not be stored in the
vicinity of this or any other appliance
Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, injury or death. Read the installation,
operation and maintenance instructions
thoroughly before installing or servicing this
equipment.
If the patio heater model is equipped with a base
weight/sand box, it is strongly recommended that
you fill it with sand or fine gravel and attach it
securely to the bottom of the heater. In windy
conditions, store the heater in a protected area or
otherwise secure it. Unsecured heaters can be
blown over in moderate to high wind. Damage due
to weather or acts of God is not covered under
warranty.
cservice@welltraveled.net
(866) 985-7877 (Toll-free US line)
9 am – 6 pm EST, Mon – Sat
www.balkenehome.com
9 am – 6 pm EST, Mon – Fri
WARNING
WARNING
.
WARNING
CAUTION
09182023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 60368 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Firesense 60368

  • Page 1 ASSEMBLY / CARE & USE INSTRUCTIONS IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Item/Model # 60368, 60485, 61130, 61185, 61444, 61726, 61727, 61728, 61729, 61730, 61735, 61736, 61737, 61738, 61739, 61740, 61741, 61742, 61743, 62555, 62784, 62785, 62987, 63008, 63009, 63010...
  • Page 2: Table Of Contents

    BEFORE YOU BEGIN TABLE OF CONTENTS TOPIC PAGE Before You Begin Safety Information Package Contents Hardware Contents Assembly Operating Instructions 9-12 Care & Maintenance Troubleshooting Warranty Information BEFORE YOU BEGIN Please read and understand this entire manual before attempting to assemble, operate, or install this appliance.
  • Page 3: Safety Information

    SAFETY INFORMATION WARNING DANGER DANGER: • This product is fueled by liquid propane Indicates a hazardous situation that, if not FOR OUTDOOR USE ONLY avoided, WILL cause death or serious injury. gas (LPG). LPG is invisible, odorless, and flammable. An odorant is normally added to CARBON MONOXIDE HAZARD WARNING help detect leaks and can be described as...
  • Page 4: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Reflector Panel 4 packed in inner carton Reflector Center Cap 1 packed under base Head Assembly 1 packed in inner carton Tank Housing Gas Hose 1 attached to head assembly Upper Post Lower Post Regulator 1 packed in inner carton Post Supports 3 packed in inner carton...
  • Page 5: Assembly

    ASSEMBLY PREPARATION Estimated assembly time: 60 minutes Required for assembly (not included): Before beginning assembly of this appliance, make sure all parts and hardware are present. Compare contents with the list • Phillips screwdriver w/ medium blade on page 4. If any part is missing or damaged, do not attempt to •...
  • Page 6 ASSEMBLY Attach Lower Post to Post Supports . Align holes in Lower Post with holes at the top of the Post Supports, then insert Large Bolts through each of the 6 sets of the aligned holes and secure each with a Flange Nut.
  • Page 7 ASSEMBLY Install Head Assembly: Loosen or remove the 4 Small Bolts & Lock Washers pre-installed in the neck of the Head Assembly . Route the Gas Hose down through the post and align 4 small holes on neck of the Head Assembly with the holes at the top of the post.
  • Page 8 ASSEMBLY Install Reflector: Place a Washer on the top of each installed Reflector Stud. Lower Reflector onto Reflector Studs. Place an additional Washer on each Reflector Stud, then secure with Wing Nuts. Hand-tighten securely. Hardware: 6x Washer 3x Wing Nut Connect the LPG cylinder (not included): NOTE: Use a standard 20lb propane tank only.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS CAUTION WARNING Before attempting to operate this appliance: • Perform all leak tests outdoors. • Extinguish all open flames before leak-testing. • Read and understand all safety • NEVER leak test while smoking. information in this manual • Do not use heater until all connections have been leak tested and show •...
  • Page 10: Before Turning Gas Supply On

    OPERATING INSTRUCTIONS A minimum supply pressure of 14 in. W.C./0.5 PSI is required for the purpose of input adjustment of propane gas. The minimum gas supply pressure of 11 in. W.C./0.4 PSI is required for the purpose of hose adjustment. The minimum input rating for a heater for automatic operation rating less than full input rating is 1500 BTU.
  • Page 11 OPERATING INSTRUCTIONS CAUTION: WARNING FOR YOUR SAFETY Avoid inhaling fumes emitted from the heater's first use. Both smoke and Be careful when attempting to odor from the burning of oils used in manufacturing will appear. Both manually light this heater. smoke and odor will dissipate after approximately 30 minutes.
  • Page 12: Pre-Operation Checklist

    OPERATING INSTRUCTIONS PRE-OPERATION CHECKLIST: WARNING For a safe and pleasant heating experience, perform this check before FOR YOUR SAFETY each use: Heater head will be extremely hot after use. Handle with extreme caution. BEFORE OPERATING: • I am familiar with the entire owner's manual and understand all precautions noted.
  • Page 13: Care & Maintenance

    CARE AND MAINTENANCE To enjoy years of outstanding performance from your heater, make sure to WARNING perform the following maintenance activities on a COLD HEATER regularly: FOR YOUR SAFETY • Do NOT touch or move the KEEP EXTERIOR SURFACES CLEAN. heater for at least 45 1.
  • Page 14: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Gas valve is off Turn gas valve on Fuel tank is low/empty Refill LPG tank Orifice is blocked Clean orifice Purge air from lines: open gas lines and Air in supply system or recently swapped cylinder depress control knob for up to 2 minutes Burner will not light...
  • Page 15: Limited Warranty

    LIMITED WARRANTY • THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED. Customers in the Contiguous US • PURCHASER ASSUMES ALL RISKS IN THE ASSEMBLY AND OPERATION OF THIS UNIT. With proof of purchase from an authorized retailer, this product is warranted for a period of 1 year from original purchase •...
