Item#:
1. Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
2. Read the installation, operation, and maintenance
instructions thoroughly before installing or servicing
this equipment.
3. Failure to follow these instructions could result in fire or
explosion, which could cause property damage, personal
injury, or death.
-
Unplug power cord from electrical outlet before replacing
bulb or performing any other service.
This product can expose you to chemicals
including Lead, Chromium (hexavalent
compounds), Di(2-ethylhexyl) phthalate (DEHP)
and Diisononyl phthalate (DINP), which are known
to the State of California to cause cancer and birth
defects or other reproductive harm. For more
information, go to www.P65Warnings.ca.gov.
9 a.m. – 9 p.m., EST
9 a.m. - 6 p.m., EST, Monday - Friday
02117 (Stainless)
02678 (Black)
Keep a copy of your proof of
purchase or order confirmation
which will be needed if you
need to contact us about
warranty coverage.
Purchase Date:
11142022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Firesense 02117
Summary of Contents for Firesense 02117
- Page 1 Item#: 02117 (Stainless) 02678 (Black) 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. 2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment. 3. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.
-
Page 2: Bulb Replacement
Before You Begin Safety Information Package Contents Assembly Operation Specifications Bulb Replacement Thermostat Replacement Troubleshooting Warranty Please read and understand this entire manual before attempting to assemble, operate or install this appliance. If you have any questions regarding the product, please contact Customer Service. English &... - Page 3 N014 AWG minimum size and rated not less than 1875 watts. This heater has been tested in accordance with the CSA Standards. Model Number Length Height Depth 02117 / 02678 22"” 71"–92” 20" Description Telescoping Offset Pole Mounted Infrared Patio Heater Voltage...
- Page 4 covers your heater in the box, there is some chance that material may lodge itself in the heater part of the unit. If you notice this on inspection, please remove it. 1. Read all instructions before use. 21. When turning on your heater for the first time, it is 2.
- Page 5 IR Head unit w/Protective Shield with: * Pre-installed Tilt Switch (safety cut off) * Angle Adjustment Bar * 1500 Watt quartz halogen bulb * Swivel Bracket * 1.1m female connector power cord pre-assembled at head unit, 16/3 grounded electrical cord Mounting Bracket –...
- Page 6 Before beginning assembly, be sure to read and familiarize yourself with the overall assembly process and instructions in this manual. It may be helpful to have someone assist you with the assembly. You will need the following tools (NOT INCLUDED): Complete assembly on a clean, level, preferably carpeted location.
- Page 7 Align Tilt Switch (black box on Head Unit ) to threaded holes on Mounting Bracket , then secure with 2 Bolts/Washers Thread electrical cord through and attach with 4 threaded Bolts/Lock Washers . Ensure that tilt switch (black box) stays horizontal/level. Tighten clamp collar as shown.
- Page 8 Attach the using 4 threaded Bolts/Lock Washers Mount Support Collar Flange to Base Assembly with Wheels as shown in Figure A. Then, secure with Washer/ Spring Washer/Nut as shown in Figure B. Carefully lift pole and head unit assembly and insert lower end of pole into .
- Page 9 CAUTION! OPERATING INSTRUCTIONS This appliance MUST be grounded. When using outdoors, we recommend using a certified GFI (Ground Fault Interrupt) outlet to protect against electrical shock. ALL installations must be in accordance with I.E.E. safety regulations or equivalent. Avoid the use of an extension cord with this appliance. If one is used, it must meet the following requirements: Use either a 12 gauge or 14 gauge wire which is rated not less than 1900 watts.
-
Page 10: Maintenance
Specifications Model: 02117/60694/02678 Voltage: 120 volts Amps: 12.5 amps Wattage: 1500 watts Lamp Type: Quartz Halogen Minimum Operational Height: 9 in. Assembled Weight: 53 lbs. Head Unit Dimensions: 4.5” x 7” x 22” Heater Assembled Dimensions: 22” diameter base, 9 ” height Storage * Always UNPLUG the unit when not in use. - Page 11 INFRARED HEATING ELEMENT approved original equipment and replacement bulbs to ensure the safe operation and maximum performance of your heater. : Do touch the new bulb with bare fingers. Oils from your hand can reduce the lifespan of the bulb by causing a heat spot.
- Page 12 THERMOSTAT approved original equipment and replacement parts to ensure the safe operation and maximum performance of your heater. N O F AN D DISCON N ECT THE HEATER FROM THE ELECTRICAL OUTLET BEFORE YOU BEGIN! Step 1: Remove four corner screws from Step 2: Loosen the two remain inset screws.
- Page 13 Unit fails to turn on Check electrical plug connection at wall outlet for a complete, snug fit. Unit fails to turn on Check to make sure unit is on a dedicated electrical circuit. Unit fails to turn on Make sure unit is on flat ground and tilt switch is LEVEL/horizontal with the ground. Unit fails to turn on Make sure ON/OFF power switch on pole is in ON position.
- Page 14 an additional year Before returning 9 a.m. – 6 p.m., EST, Mon – Fri...
