Page 1 IDEO ATRIX WITCHER HEETAH IGITAL IDEO ATRIX WITCHER ERVICE AND RDERING SSISTANCE PESA Switching Systems, Inc. 330-A Wynn Drive Northwest Huntsville AL 35805-1961 USA www.pesa.com FFICE Tel: 256.726.9200 Fax: 256.726.9271 ERVICE EPARTMENT Tel: 256.726.9222 (24/7) Toll Free: 800.323.7372 Fax: 256.726.9268 Email: service@pesa.com...
Page 2 © 2002 PESA Switching Systems, Inc. All Rights Reserved. Cheetah is a trademark of PESA Switching Systems, Inc. in the United States and/or other countries. Microsoft, Windows, and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Page 3: About This Manual
WITCHER About This Manual This manual provides detailed instructions for the installation, operation, and maintenance of the PESA Cheetah 512x512 Digital Video Matrix Switcher. Warnings, Cautions, and Notes Warning statements identify conditions or practices that can result in personal injury or loss of life.
Page 4: Table Of Contents
Output Combiner Card ......................... 54 3.2.1 Output Combiner Card LED Indicators ................. 55 Output Monitor Card ........................55 3.3.1 Output Monitor Card LED Indicators ..................56 3500 System Controller Cards ..................... 56 3.4.1 GND............................56 3.4.2 +5V ............................56 PESA S WITCHING YSTEMS...
Page 5 APPENDIX B. – SNMP .......................... 75 APPENDIX C. – PESA TC MIB DEFINITIONS ..................77 APPENDIX D. - PESA MATRIX FRAME CONTROLLER DEBUG PORT PROTOCOL....109 Figures Figure 1. Cheetah 512x512 Front View ....................2 Figure 2. Cheetah 512x512 Rear View ....................3 Figure 3.
Page 6 Table 3. AC Power Filter Assembly ......................13 Table 4. Strobe Switch Functions ......................15 Table 5. PESA CPU Link Protocols ......................30 Table 6. COM1 and COM 2 Pin Assignments ..................31 Table 7. COM 3/PRC Pin Assignments ....................31 Table 8.
Page 7 Table 22. Power Supply LED Indicators ....................64 Table 23. Power Supply LEDs ........................66 Table 24. Matrix Board LEDs ........................67 Table 25. Output Board LEDs ........................68 Table 26. Input Board LEDs........................69 Table 27. Ethernet Configuration ......................72 PESA S WITCHING YSTEMS...
Page 8: Chapter 1 - Introduction
Chapter 1 – Introduction 1.1 Product Description The Cheetah 512x512 is a fully-featured digital video matrix switcher capable of handling both Serial Digital Interface (SDI) and High-Definition Television (HDTV), as well as other non- standard digital signals, in the same frame. Copper and fiber input and output modules provide for maximum flexibility.
Page 9: Figure 1. Cheetah 512X512 Front View
81-9059-0519-0 Rev. D 512 D HEETAH IGITAL IDEO ATRIX WITCHER PESA S WITCHING YSTEMS...
Page 10: Figure 2. Cheetah 512X512 Rear View
81-9059-0519-0 Rev. D 512 D HEETAH IGITAL IDEO ATRIX WITCHER PESA S WITCHING YSTEMS...
Page 11: Specifications
Conforms to both SMPTE 259M for SDI and SMPTE 292M Connector type (copper) ..............75 Ohm BNC Return loss .............>15dB minimum to 270 Mbps (SDI) >15 dB minimum to 1.5 Gbps (HD) Connector type (fiber)............SFF modules w/LC type PESA S WITCHING YSTEMS...
Page 12: Chapter 2 - Installation
WITCHER Chapter 2 – Installation 2.1 Introduction This section details the Cheetah 512x512 Digital Video Matrix Switcher installation procedures. 2.2 General If specified when ordered, the Cheetah Switcher will be configured for the intended system at the factory. Before attempting to install any frame, matrix card, controller card, or power supply, read this section carefully.
Page 13: Choosing An Installation Location
Consider the connection from this equipment to the supply circuit, and the effect that possible overloading can have on overcurrent protection circuits and supply wiring. Refer to nameplate ratings when addressing this concern. PESA S WITCHING YSTEMS...
Page 14: Mounting In Equipment Rack
6. Bundle together any cables connected to a single input/output card and separate them from the other bundles with enough slack to create a service loop. This will permit individual card replacement without disruption to the other input/output cards. Figure 1. PESA S WITCHING YSTEMS...
Page 15: Installing The Cheetah Power Supplies
AC line voltage ranges from 95-250 VAC and with AC line frequencies of 50/60 Hz automatically. In the event of a Cheetah Power Supply failure, return the malfunctioning unit to the PESA Service Department for replacement. The power supplies contain lethal voltages when operating and should only be serviced by the PESA Service Department.
Page 16 81-9059-0519-0 Rev. D 512 D HEETAH IGITAL IDEO ATRIX WITCHER Department for a RMA number before returning any units for replacement. The Service Department’s phone number is listed on the front page of this manual. PESA S WITCHING YSTEMS...
Page 17: Figure 4. Power Supply Locations (Front View)
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 4. Power Supply Locations (front view) PESA S WITCHING YSTEMS...
Page 18: Installing The Power Supplies
3. Push the latch on the front of the power supply up. 4. Once the latch is pushed up, carefully pull the power supply out of the equipment chassis. Repeat for each power supply you need to remove. PESA S WITCHING YSTEMS...
Page 19: Power Cord Connections
The following table describes the power connections for pigtail power cords. Table 2. IEC-Type Plug Power Connections 200-240V Green/Yellow Stripe Safety Ground Blue AC Line Brown AC Line Green/Yellow Stripe Blue Brown Figure 5. IEC-Type Plug Power Connections PESA S WITCHING YSTEMS...
Page 20: Ac External Power Requirements
You must ensure that these settings match the settings in the 3500Plus System Controller software. If specified by the customer when ordering, these switches will be set at the factory; however, the customer can adjust them as required for system expansion. PESA S WITCHING YSTEMS...
Page 21: Figure 6. Level Code Switch Location (Front View)
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 6. Level Code Switch Location (front view) PESA S WITCHING YSTEMS...
Page 22: Table 4. Strobe Switch Functions
The Input Offset displays in the lower section of the window). MSB Frame Specifics the type of frame the boards are plugged into. For the Cheetah 512x512 frame, set this to 1. LSB Frame Network (not used) Not used. Sets the starting output number. Each switch position increments the output number by 4.
Page 23: Fuses
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V Fuse 5 Fuse 7 CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Fuse 6 Fuse 8 Figure 7. Fuse Locations PESA S WITCHING YSTEMS...
Page 24: Figure 8. Fuse Protection
Supply Supply Supply Supply Supply Backplane Backplane Backplane Backplane ackplane Backplane Backplane Backplane Backplane Fuse 1 Fuse 2 Fuse 3 Fuse 4 Fuse 5 Fuse 7 Fuse 8 Fuse 6 Figure 9. Filter and Power Distribution PESA S WITCHING YSTEMS...
Page 25: Figure 10. Fuses For The Input/Output Cards Cards
Fuse 1 Fuse 2 Fuse 3 Fuse 4 Fuse 1 Fuse 2 Fuse 3 Fuse 4 Fuse 5 Fuse 6 Fuse 7 Fuse 5 Fuse 6 Fuse 7 Figure 10. Fuses for the Input/Output Cards Cards PESA S WITCHING YSTEMS...
Page 26: Installing The Output Monitor Control Card
32 based on the Frame strobe setting (see LSB and MSB Frame Strobe setting on page 15). For example, if the Frame strobe is set to 10, the internal Output Monitor Card strobe will be set to 42. PESA S WITCHING YSTEMS...
Page 27: Figure 11. Output Monitor Control Card (Front View)
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 11. Output Monitor Control Card (front view) PESA S WITCHING YSTEMS...
Page 28: Installing The 3500Plus System Controller Card
If only one System Controller Card is installed in the Cheetah Switcher, install it in the upper card slot. If you do not use the controller cards, you must connect the Cheetah to a remote system controller. PESA S WITCHING YSTEMS...
Page 29: Figure 12. System Controller Card Locations (Front View)
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 12. System Controller Card Locations (front view) PESA S WITCHING YSTEMS...
Page 30: Installing The Matrix Frame Controllers
For every frame type, at least one Matrix Frame Controller (MFC) is required. The function of the frame controller is to determine frame size, level, input offsets, output offsets, plus other physical characteristics of the frame hardware. For detailed information about this card, see section 3.6, Matrix Frame Controller, on page 59. PESA S WITCHING YSTEMS...
Page 31: Figure 13. Matrix Frame Controller Cards
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 13. Matrix Frame Controller Cards PESA S WITCHING YSTEMS...
Page 32: Installing The Digital Video Matrix Cards
3.5, 64x64 Digital Video Crosspoint Matrix Card, on page 58. The Digital Video Matrix Cards are installed in the lower portion of the Cheetah Switcher. To install the cards in the Cheetah Switcher follow these steps: PESA S WITCHING YSTEMS...
Page 33: Figure 14. Matrix Card Locations (Front View)
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 14. Matrix Card Locations (front view) PESA S WITCHING YSTEMS...
Page 34: Installing Input/Output Buffer Cards
These dip switches are set at the factory. Do not change the settings! The following graphic shows an overview of the location of all of the input and output buffer cards. The following pages show close-up views of the cards. PESA S WITCHING YSTEMS...
Page 35: Figure 16. Input/Output Signal Connectors (Rear View)
REFERENCE OUTPUT MONITOR CONTROL CONTROL SLOT A ALARM PRC LOOP COM 4 COM 3 / PRC AUX FRAME CTRL SLOT B Input Cards Output Cards Input Cards Output Cards Figure 16. Input/Output Signal Connectors (rear view) PESA S WITCHING YSTEMS...
Page 36: Rear Panel Connectors
COM 2 RCP PANEL PORT ALARM ALARM SYSTEM FRAME REFERENCE OUTPUT MONITOR CONTROL CONTROL SLOT A ALARM PRC LOOP AUX FRAME CTRL COM 4 COM 3 / PRC SLOT B Figure 18. System Interface Connector Panel Close-up PESA S WITCHING YSTEMS...
Page 37: Control Connectors Com 1 And Com 2
Make sure the communication rate for COM 2 in the 3500Plus software matches the baud rate you are using (in the software, select System > Communications). Table 5. PESA CPU Link Protocols Protocol Document Number CPU Link Protocol No. 1 Extensions (P1E)
Page 38: Control Connectors Com3/Prc And Com4
Table 7. COM 3/PRC Pin Assignments Pin Signal In/Out CTS+ Input (not used) MATRIX+ Bi-directional CTLR- Output RTS- Output (not used) Ground CTS- Input (not used) MATRIX- Bi-directional CTLR+ Output RTS+ Output (not used) PESA S WITCHING YSTEMS...
Page 39: System Control Alarm Connector
COM 2 RCP PANEL PORT ALARM ALARM SYSTEM FRAME REFERENCE OUTPUT MONITOR CONTROL CONTROL SLOT A ALARM PRC LOOP AUX FRAME CTRL COM 4 COM 3 / PRC SLOT B Figure 21. System Control Alarm Connector PESA S WITCHING YSTEMS...
Page 40: Prc Loop Connector
COM 3 / PRC SLOT B Figure 24. PRC Loop Connector PRC Loop may be connected to PESA PRC-type equipment with a cable assembly (Part No. 81- 9028-0395-0) constructed as shown in the following figure. 81-9029-0813-0 to 81-9029-0813-0 to PRC Control Connector...
Page 41: Rcp Panel Port Connectors
(Part No. 81-9028-0043-2, Belden 8451, or equivalent) as illustrated in the following figure. The connector body has an integral strain relief which requires the use of a nylon cable tie which is included with the connector. If this cable tie is not available, use PESA Part No. 81-9021-0028-8. 81-9029-0811-0 to...
Page 42: Network Connectors
Figure 28. Network Connectors LED indicators are provided as follows: Table 9. Ethernet LED Indicators ON = Ethernet LINK established 100M ON = The Ethernet connection speed is 100Mb/s OFF = The Ethernet connection speed is 10Mb/s PESA S WITCHING YSTEMS...
Page 43: Figure 29. Matrix Frame Controller Cards, Slot A And Slot B
+2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 29. Matrix Frame Controller Cards, Slot A and Slot B PESA S WITCHING YSTEMS...
Page 44: Frame Alarm Connector
AUX FRAME CTRL COM 4 COM 3 / PRC SLOT B Figure 30. Frame Alarm Connector Customer Part Number Supplied 81-9029-0811-0 Connector Alarm (-) Controller B (Bottom) Alarm (+) Controller A (Top) Alarm (+) Figure 31. Alarm cable PESA S WITCHING YSTEMS...
Page 45: Aux Frame Control Connector
COM 3 / PRC SLOT B AUX FRAME CTRL Figure 32. Aux Frame Control Connector Table 10. Aux Frame Control Pin Assignments Signal In/Out CTS+ Input Input Output RTS- Output Ground CTS- Input Input Output RTS+ Output PESA S WITCHING YSTEMS...
Page 46: House Sync Input Connectors
RCP PANEL PORT COM 1 COM 2 SYSTEM FRAME ALARM ALARM REFERENCE OUTPUT MONITOR CONTROL CONTROL SLOT A ALARM PRC LOOP AUX FRAME CTRL COM 4 COM 3 / PRC SLOT B Figure 34. Output Monitor Connectors PESA S WITCHING YSTEMS...
Page 47: Input/Output Signal Connectors
For SDI applications, a DAC monitor grade, 10-bit output board can be installed as an option. For HD applications, a HD to SD conversion card can be installed as an option. The Output Slots labeled with a “d” in the following diagram represent dual output slots. PESA S WITCHING YSTEMS...
Page 48: Figure 35. Input/Output Signal Connectors (Rear View)
WITCHER Fuse 1 Fuse 2 Fuse 3 Fuse 4 Fuse 1 Fuse 2 Fuse 3 Fuse 4 Fuse 5 Fuse 6 Fuse 7 Fuse 5 Fuse 6 Fuse 7 Figure 35. Input/Output Signal Connectors (rear view) PESA S WITCHING YSTEMS...
Page 49: Figure 36. Outputs And Dual Outputs 1-256
Fuse 2 81d-96d 81-96 97d-112d COM-2/PWR B Fuse 2 97-112 113d-128d 113-128 129d-144d COM-3/PWR C Fuse 3 129-144 145d-160d 145-160 161d-176d COM-3/PWR C Fuse 3 161-176 177d-192d 177-192 193d-208d 193-208 COM-4/PWR D Fuse 4 225d-240d 225-240 PESA S WITCHING YSTEMS...
Page 50: Figure 37. Inputs 1-256, Outputs And Dual Outputs 17-64 And 209-256
17-32 33-48 49-64 65-80 81-96 COM-2/PWR B Fuse 2 97-112 113-128 129-144 COM-3/PWR C Fuse 3 145-160 161-176 177-192 193-208 COM-4/PWR D Fuse 4 209-224 225-240 241-256 Outputs 209d-224d Fuse 4 209-224 COM-4/PWR D 241d-256d 241-256 PESA S WITCHING YSTEMS...
Page 51: Figure 38. Outputs And Dual Outputs 257-496
Fuse 5 321-336 337d-352d 337-352 353d-368d 353-368 COM-2/PWR B Fuse 6 369d-384d 369-384 385d-400d COM-3/PWR C Fuse 6 384-400 401d-416d 401-416 417d-432d COM-3/PWR C Fuse 7 417-432 433d-448d 433-448 449d-464d COM-4/PWR D Fuse 7 449-464- 481d-496d 481-496 PESA S WITCHING YSTEMS...
Page 52: Figure 39. Inputs 257-512, Outputs 273-320 And 465-512
COM-1/PWR A 289-304 305-320 321-336 COM-2/PWR B Fuse 6 337-352 353-368 369-384 385-400 COM-3/PWR C Fuse 6 401-416 417-432 433-448 449-464 COM-4/PWR D Fuse 7 465-480 481-496 497-512 Outputs 465d-480d Fuse 7 COM-4/PWR D 465-480 497d-512d 497-512 PESA S WITCHING YSTEMS...
Page 53: Switch Locations And Settings
(SPST) switches numbered 1 through 8. Each input/output backplane supports 4 cards. The following figure depicts the location of these switches with the cards removed, and the dip switch settings. These dip switches are set at the factory. Do not change the settings! PESA S WITCHING YSTEMS...
Page 54: Figure 40. Matrix Backplane Dip Switch Location And Settings
RCP PANEL PORT ALARM ALARM SYSTEM FRAME REFERENCE OUTPUT MONITOR CONTROL CONTROL SLOT A ALARM PRC LOOP COM 4 COM 3 / PRC AUX FRAME CTRL SLOT B Figure 40. Matrix Backplane Dip Switch Location and Settings PESA S WITCHING YSTEMS...
Page 55: Power Supply Backplane Dip Switches
(SPST) switches numbered 1 through 8. Each power supply backplane supports two power supplies. The following figure depicts the location of these switches and the dip switch settings. These dip switches are set at the factory. Do not change the settings! PESA S WITCHING YSTEMS...
Page 56: Figure 41. Power Supply Backplane Dip Switch Locations And Settings (Viewed From The Front Of The Frame)
+2.5V +2.5V +2.5V CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL CTRL Figure 41. Power Supply Backplane Dip Switch Locations and Settings (viewed from the front of the frame) PESA S WITCHING YSTEMS...
Page 57: Matrix Backplane Dipswitches
(SPST) switches numbered 1 through 8. Each backplane supports 4 cards. The following figure depicts the location of this switch with the matrix cards removed, and the dip switch settings. These dip switches are set at the factory. Do not change the settings! PESA S WITCHING YSTEMS...
Page 58: Figure 42. Input/Output Backplane Dip Switch Locations And Settings (Viewed From The Rear Of The Frame)
129-256 1-128 384-512 257-384 385-512 257-384 1-128 129-256 385-512 257-384 129-256 1-128 257-384 385-512 257-384 385-512 385-512 257-384 257-384 385-512 Figure 42. Input/Output Backplane Dip Switch Locations and Settings (viewed from the rear of the frame) PESA S WITCHING YSTEMS...
Page 59: Connection Guide
13. Connect the digital video sources to the video inputs using Belden 8281 coaxial cable or equivalent 75 ohm coaxial cable. 14. Connect the video outputs to the digital video destinations using Belden 8281 coaxial cable or equivalent. PESA S WITCHING YSTEMS...
Page 60 81-9059-0519-0 Rev. D 512 D HEETAH IGITAL IDEO ATRIX WITCHER PESA S WITCHING YSTEMS...
Page 61: Chapter 3 - Operation And Functional Description
The output combiner is available in either SDI or HD multi-rate versions, each of which can support option cards for dual output BNC or fiber option output. The SD can also support a 10-bit digital analog (DAC) card. The HD-MR card support HD to SD conversion as an option card. PESA S WITCHING YSTEMS...
Page 62: Output Combiner Card Led Indicators
32 based on the Frame strobe setting (see LSB and MSB Frame Strobe setting on page 15). For example, if the Frame strobe is set to 10, the internal Output Monitor Card strobe will be automatically set to 42. Figure 44. Output Monitor Card PESA S WITCHING YSTEMS...
Page 63: Output Monitor Card Led Indicators
This test point provides a convenient ground when measuring voltages at the other test points. 3.4.2 +5V The voltage measured between this test point and GND is the output of the voltage regulation circuit and should be 5 ±0.1 VDC. PESA S WITCHING YSTEMS...
Page 64: Battery
This SPDT toggle switch is used to enable and disable the backup memory power source. Early designs of PESA system controllers used a battery for backup power. This switch was used to prevent the battery from discharging during prolonged storage.
Page 65: Reset
HD to SD Conversion Figure 46. 64x64 Crosspoint Matrix Card Diagram 3.5.1 LED Indicators Five LED indicators are located on the 64x64 matrix card faceplate, as illustrated in the following figure, and described in Table 19. PESA S WITCHING YSTEMS...
Page 66: Matrix Frame Controller
Matrix Frame Controller (MFC) is required. The function of the frame controller is to determine frame size, level, input offsets, output offsets, plus other physical characteristics of the frame hardware. Both PESA’s PRC protocol and NET PRC protocol are PESA S...
Page 67: Figure 48. Matrix Frame Controller
See Appendix A on page 72 for details on Ethernet configuration options. COMMUNICATIONS CONTROL STATUS ACTIVE RESET 88888888 SCROLL MATRIX FRAME CONTROLLER Figure 48. Matrix Frame Controller PESA S WITCHING YSTEMS...
Page 68: Matrix Frame Controller Led Indicators
The next seven characters indicate the actual message. Press the “Scroll” button to view successive pages. Each page will appear for 30 seconds, then reset to page 0. Descriptions of the displayed messages are detailed in Table 21on the next page. PESA S WITCHING YSTEMS...
Page 69: Table 21. 8-Character Display Messages
Indicates whether there are any errors detected on any output cards. OTE BAD MTX OK Indicates whether there are any errors detected on any matrix cards. MTX BAD PSB OK Indicates whether there are any errors detected on any power supply cards. PSB BAD PESA S WITCHING YSTEMS...
Page 70: Matrix Frame Controller Switch Locations And Settings (S1 And S2)
Each fan circuit has a diode output so that with redundant power supply, either circuit will drive the fans. The highest temperature supply normally controls the fan. Figure 51. Power Supply LED Indicators and Test Points PESA S WITCHING YSTEMS...
Page 71: Led Indicators And Test Points
Blinking Indicates there is an over-current condition in the power supply. This Current must be fixed immediately! 3.7.2 +28V and GND Test Points The test points labeled +28V and GND are used to determine whether +28V power is present. PESA S WITCHING YSTEMS...
Page 72: Chapter 4 - Maintenance And Repair
The air filter should be checked monthly to ensure that an adequate supply of clean air is available to cool this equipment. If the air filter is dirty, either clean it with low-pressure air, vacuuming, or a mild soap-and-water solution; or replace it with a new air filter (PESA Part No. 81-9065-2360-0).
Page 73: Table 23. Power Supply Leds
(the PWR OK LED is on). If the other power supplies are functional and the Current LED is still blinking, then replace the power supply. No alert conditions are present. None PESA S WITCHING YSTEMS...
Page 74: Table 24. Matrix Board Leds
+2.5V Green None normal operating parameters. Port A, Port B Indicate whether the board is communicating with the (Surface- Yellow None frame controller via mounted on communications port A or B. the PCB) PESA S WITCHING YSTEMS...
Page 75: Table 25. Output Board Leds
4.5V power supplies are not continues, replace the board. working. Port A, Port B Indicate whether the board is communicating with the (Surface- Yellow None. frame controller via mounted on communications port A or B. the PCB) PESA S WITCHING YSTEMS...
Page 76: Table 26. Input Board Leds
This is a surface mount LED located on the PCB. Indicates that the +3.3V power is stable and within normal operating +4.8V Green None parameters. This is a surface mount LED located on the PCB. PESA S WITCHING YSTEMS...
Page 77: Pesa Customer Service
A or B. the PCB) 4.2.2 PESA Customer Service If the troubleshooting information above does not resolve your problem, contact PESA’s Customer Service Department. Contact information for the Customer Service Department appears on the front cover of this document.
Page 78: Return Material Authorization (Rma)
ATRIX WITCHER 4.3.2 Return Material Authorization (RMA) Before returning any equipment for service or replacement, contact PESA’s Customer Service Department for an RMA number. Contact information for the Customer Service Department appears on the front cover of this document. 4.4 PESA Documentation...
Page 79: Appendix A. - Ethernet Configuration
Specifies the IP address to receive SNMP 0.0.0.0 traps. These fields are accessed via the DB-9 RS-232 connector on the Matrix Frame Controller. Communication parameters for this serial interface default to 38400 baud, no parity, 8 data bits, and 1 stop bit. PESA S WITCHING YSTEMS...
Page 80 NETPRC : MASTER NETPRC port : 1000 TELNET : ON TELNET port : 23 TELNET pass : RCOMM : public WCOMM : private TCOMM : public TRAP : OFF AUTH : OFF TARGET : 000.000.000.000 > PESA S WITCHING YSTEMS...
Page 81 AUTH : OFF TARGET : 000.000.000.000 > For example, to set the read community string to 'pesa', enter >ET RCOMM pesa and press return. To view your changes, wait for the '>' prompt and enter 'ET'. PESA S WITCHING YSTEMS...
Page 82: Appendix B. - Snmp
RFC 2012 – SNMPv2 TCP MIB Objects RFC 2013 – SNMPv2 UDP MIB Objects Two enterprise MIBs are used to provide full control of Cheetah Switchers. The first, PESA- TC.MIB, is a MIB which defines some textual conventions. The second, PESA-MATRIX.MIB, contains objects which allow SNMP-based control and monitoring of one or more Cheetah Switchers.
Page 83 $ snmpset 192.168.0.106 -c private pesaPresetMemberRowStatus.1.2.1 i 1 PESA-MATRIX-MIB::pesaPresetMemberRowStatus.1.2.1 = INTEGER: active(1) $ snmpset 192.168.0.106 -c private pesaPresetMemberSyncSource.1.2.1 b syncA PESA-MATRIX-MIB::pesaPresetMemberSyncSource.1.2.1 = BITS: 80 syncA(0) $ snmpset 192.168.0.106 -c private pesaPresetMemberSourceNum.1.2.1 u 1 PESA-MATRIX-MIB::pesaPresetMemberSourceNum.1.2.1 = Gauge32: 1 $ snmpset 192.168.0.106 -c private pesaPresetMemberRowStatus.1.2.2 i 1 PESA-MATRIX-MIB::pesaPresetMemberRowStatus.2.2.1 = INTEGER: active(1)
Page 84: Appendix C. - Pesa Tc Mib Definitions
81-9059-0519-0 Rev. D 512 D HEETAH IGITAL IDEO ATRIX WITCHER Appendix C. – PESA TC MIB Definitions PESA-MATRIX-MIB DEFINITIONS ::= BEGIN IMPORTS MODULE-IDENTITY, OBJECT-TYPE, Counter32, Unsigned32, NOTIFICATION-TYPE, TimeTicks FROM SNMPv2-SMI PesaSyncSource, PesaMatrixStatus, PesaFrameStatus, PesaBoardStatus, PesaSourceStatus, PesaDevices, PesaDestinationStatus, pesa FROM PESA-TC-MIB...
Page 85 ::= { pesaMatrixTable 1 } PesaMatrixEntry ::= SEQUENCE pesaMatrixIndex Unsigned32, pesaMatrixName SnmpAdminString, pesaMatrixLevel Unsigned32, pesaMatrixNumSources Unsigned32, pesaMatrixSourcesLowerBound Unsigned32, pesaMatrixSourcesUpperBound Unsigned32, pesaMatrixNumDests Unsigned32, pesaMatrixDestsLowerBound Unsigned32, pesaMatrixDestsUpperBound Unsigned32, pesaMatrixSwitchCount Counter32, pesaMatrixFailedSwitchCount Counter32, pesaMatrixBlockedSwitchCount Counter32, pesaMatrixStatus PesaMatrixStatus, pesaMatrixStatusNotify TruthValue, PESA S WITCHING YSTEMS...
Page 86 MAX-ACCESS read-write STATUS current DESCRIPTION "The highest source number in the matrix. Normally, this is equivalent to pesaMatrixNumSources. Matrices that do not support dynamic range assignment will treat this as read-only." ::= { pesaMatrixEntry 6 } PESA S WITCHING YSTEMS...
Page 87 A failed switch is defined as any switch the matrix was commanded to take but that was unsuccessful for any reason." ::= { pesaMatrixEntry 11 } pesaMatrixBlockedSwitchCount OBJECT-TYPE SYNTAX Counter32 MAX-ACCESS read-only STATUS current DESCRIPTION PESA S WITCHING YSTEMS...
Page 88 "This table describes the chassis which house the physical elements of matrix space. A matrix may reside on one or more frames. frame may contain one or more matrices." ::= { pesaMatrixMibObjects 2 } pesaFrameEntry OBJECT-TYPE SYNTAX PesaFrameEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION PESA S WITCHING YSTEMS...
Page 89 "The product id for this frame, if available." ::= { pesaFrameEntry 3 } pesaFrameSerialNumber OBJECT-TYPE SYNTAX SnmpAdminString MAX-ACCESS read-only STATUS current DESCRIPTION "The serial number for this frame, if available." ::= { pesaFrameEntry 4 } pesaFrameHardwareRev OBJECT-TYPE SYNTAX SnmpAdminString MAX-ACCESS read-only PESA S WITCHING YSTEMS...
Page 90 A blocked switch is a switch that has failed because of administrative policies." ::= { pesaFrameEntry 10 } pesaFrameStatus OBJECT-TYPE SYNTAX PesaFrameStatus MAX-ACCESS read-only STATUS current DESCRIPTION "The overall status of the frame." PESA S WITCHING YSTEMS...
Page 91 DESCRIPTION "An entry in the pesaFrameInvTable." INDEX pesaFrameIndex, pesaFrameInvIndex ::= { pesaFrameInvTable 1 } PesaFrameInvEntry ::= SEQUENCE pesaFrameInvIndex Unsigned32, pesaFrameInvDeviceType PesaDevices, pesaFrameInvProductId SnmpAdminString, pesaFrameInvSerialNumber SnmpAdminString, pesaFrameInvHardwareRev SnmpAdminString, pesaFrameInvSoftwareRev SnmpAdminString, pesaFrameInvStatus PesaBoardStatus, pesaFrameInvStatusNotify TruthValue, pesaFrameInvLastChanged TimeTicks PESA S WITCHING YSTEMS...
Page 92 DESCRIPTION "The software revision of this element, if available." ::= { pesaFrameInvEntry 6 } pesaFrameInvStatus OBJECT-TYPE SYNTAX PesaBoardStatus MAX-ACCESS read-only STATUS current DESCRIPTION "The overall status of the frame element." ::= { pesaFrameInvEntry 7 } PESA S WITCHING YSTEMS...
Page 93 "An entry in the pesaSourcesTable." INDEX pesaSourceLevel, pesaSourceNum ::= { pesaSourcesTable 1 } PesaSourcesEntry ::= SEQUENCE pesaSourceLevel Unsigned32, pesaSourceNum Unsigned32, pesaSourceName SnmpAdminString, pesaSourceSwitchCount Counter32, pesaSourceFailedSwitchCount Counter32, pesaSourceBlockedSwitchCount Counter32, pesaSourceStatus PesaSourceStatus, pesaSourceStatusNotify TruthValue, pesaSourceLastChanged TimeTicks, pesaSourceSignalPresence TruthValue PESA S WITCHING YSTEMS...
Page 94 "The total number of blocked switches that have occurred in the matrix since the last reset that involved this source. A blocked switch is a switch that has failed because of administrative policies." ::= { pesaSourcesEntry 6 } pesaSourceStatus OBJECT-TYPE PESA S WITCHING YSTEMS...
Page 95 "This table contains entries for each destination in the matrix. Each destination represents a row in a plane in matrix space." ::= { pesaMatrixMibObjects 5 } pesaDestsEntry OBJECT-TYPE SYNTAX PesaDestsEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "An entry in the pesaDestsTable." INDEX pesaDestLevel, pesaDestNum PESA S WITCHING YSTEMS...
Page 96 "The total number of successful switches that have occurred in the matrix since the last reset that involved this destination." ::= { pesaDestsEntry 4 } pesaDestFailedSwitchCount OBJECT-TYPE SYNTAX Counter32 MAX-ACCESS read-only STATUS current DESCRIPTION "The total number of failed switches that have occurred in the PESA S WITCHING YSTEMS...
Page 97 SYNTAX TimeTicks MAX-ACCESS read-only STATUS current DESCRIPTION "The value of sysUpTime when pesaDestStatus last changed." ::= { pesaDestsEntry 9 } pesaDestDetectedFormat OBJECT-TYPE SYNTAX INTEGER unknown(0), formatHD(1), formatSD143(2), formatSD177(3), formatSD270(4), formatSD360(5), formatSD540(6) MAX-ACCESS read-only STATUS current DESCRIPTION PESA S WITCHING YSTEMS...
Page 98 "An entry in the pesaSourceGroupsTable." INDEX { pesaSourceGroupIndex } ::= { pesaSourceGroupsTable 1 } PesaSourceGroupsEntry ::= SEQUENCE pesaSourceGroupIndex Unsigned32, pesaSourceGroupName SnmpAdminString, pesaSourceGroupRowStatus RowStatus pesaSourceGroupIndex OBJECT-TYPE SYNTAX Unsigned32 MAX-ACCESS not-accessible STATUS current DESCRIPTION "The index for this group." PESA S WITCHING YSTEMS...
Page 99 STATUS current DESCRIPTION "An entry in the pesaSourceGroupMembersTable." INDEX pesaSourceGroupIndex, pesaSourceGroupMemberLevel, pesaSourceGroupMemberNum ::= { pesaSourceGroupMembersTable 1 } PesaSourceGroupMembersEntry ::= SEQUENCE pesaSourceGroupMemberLevel Unsigned32, pesaSourceGroupMemberNum Unsigned32, pesaSourceGroupMemberRowStatus RowStatus pesaSourceGroupMemberLevel OBJECT-TYPE SYNTAX Unsigned32 MAX-ACCESS not-accessible STATUS current DESCRIPTION PESA S WITCHING YSTEMS...
Page 100 STATUS current DESCRIPTION "An entry in the pesaDestGroupsTable." INDEX { pesaDestGroupIndex } ::= { pesaDestGroupsTable 1 } PesaDestGroupsEntry ::= SEQUENCE pesaDestGroupIndex Unsigned32, pesaDestGroupName SnmpAdminString, pesaDestGroupRowStatus RowStatus pesaDestGroupIndex OBJECT-TYPE SYNTAX Unsigned32 MAX-ACCESS not-accessible STATUS current DESCRIPTION PESA S WITCHING YSTEMS...
Page 101 STATUS current DESCRIPTION "An entry in the pesaDestGroupMembersTable." INDEX pesaDestGroupIndex, pesaDestGroupMemberLevel, pesaDestGroupMemberNum ::= { pesaDestGroupMembersTable 1 } PesaDestGroupMembersEntry ::= SEQUENCE pesaDestGroupMemberLevel Unsigned32, pesaDestGroupMemberNum Unsigned32, pesaDestGroupMemberRowStatus RowStatus pesaDestGroupMemberLevel OBJECT-TYPE SYNTAX Unsigned32 MAX-ACCESS not-accessible STATUS current DESCRIPTION PESA S WITCHING YSTEMS...
Page 102 ::= { pesaMatrixMibObjects 10 } pesaGroupBlockingEntry OBJECT-TYPE SYNTAX PesaGroupBlockingEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "An entry in the pesaGroupBlockingTable." INDEX pesaGroupBlockingSource, pesaGroupBlockingDest ::= { pesaGroupBlockingTable 1 } PesaGroupBlockingEntry ::= SEQUENCE pesaGroupBlockingSource Unsigned32, pesaGroupBlockingDest Unsigned32, pesaGroupBlockingRowStatus RowStatus PESA S WITCHING YSTEMS...
Page 103 ::= { pesaMatrixMibObjects 11 } pesaBlockingEntry OBJECT-TYPE SYNTAX PesaBlockingEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "An entry in the pesaBlockingTable." INDEX pesaBlockingLevel, pesaBlockingSourceNum, pesaBlockingDestNum ::= { pesaBlockingTable 1 } PesaBlockingEntry ::= PESA S WITCHING YSTEMS...
Page 104 RowStatus." ::= { pesaBlockingEntry 4 } -- Presets pesaPresetTable OBJECT-TYPE SYNTAX SEQUENCE OF PesaPresetEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "This table describes a collection of preset switch configurations." ::= { pesaMatrixMibObjects 12 } pesaPresetEntry OBJECT-TYPE PESA S WITCHING YSTEMS...
Page 105 When pesaPresetStatus is set to inactive(1), the preset will not have any members (see pesaPresetMembersTable)." ::= { pesaPresetEntry 3 } pesaPresetMembersTable OBJECT-TYPE SYNTAX SEQUENCE OF PesaPresetMembersEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "This table describes a collection of preset switch configurations. PESA S WITCHING YSTEMS...
Page 106 STATUS current DESCRIPTION "With pesaPresetMemberLevel, identifies an entry in pesaDestsTable." ::= { pesaPresetMembersEntry 2 } pesaPresetMemberSourceNum OBJECT-TYPE SYNTAX Unsigned32 MAX-ACCESS read-create STATUS current DESCRIPTION "With pesaPresetMemberLevel, identifies an entry in pesaSourcesTable." ::= { pesaPresetMembersEntry 3 } PESA S WITCHING YSTEMS...
Page 107 INDEX pesaCurrentLevel, pesaCurrentDestNum ::= { pesaCurrentTable 1 } PesaCurrentEntry ::= SEQUENCE pesaCurrentLevel Unsigned32, pesaCurrentSourceNum Unsigned32, pesaCurrentDestNum Unsigned32 pesaCurrentLevel OBJECT-TYPE SYNTAX Unsigned32 MAX-ACCESS not-accessible STATUS current DESCRIPTION "With pesaCurrentSourceNum, identifies an entry in pesaSourcesTable. With pesaCurrentDestNum, identifies PESA S WITCHING YSTEMS...
Page 108 MAX-ACCESS not-accessible STATUS current DESCRIPTION "This table allows the taking of a switch." ::= { pesaMatrixMibObjects 16 } pesaTakeSwitchEntry OBJECT-TYPE SYNTAX PesaTakeSwitchEntry MAX-ACCESS not-accessible STATUS current DESCRIPTION "An entry in the pesaTakeSwitchTable." INDEX pesaTakeSwitchLevel, pesaTakeSwitchSourceNum, pesaTakeSwitchDestNum PESA S WITCHING YSTEMS...
Page 109 RowStatus MAX-ACCESS read-create STATUS current DESCRIPTION "Setting this object to 'active' will cause a switch to be taken." ::= { pesaTakeSwitchEntry 4 } -- notifications pesaMatrixNotifications OBJECT IDENTIFIER ::= { pesaMatrixMibObjects 19 } pesaMatrixConfigurationConflict NOTIFICATION-TYPE OBJECTS PESA S WITCHING YSTEMS...
Page 110 "Notification that a frame's status has changed." ::= { pesaMatrixNotifications 4 } pesaFrameInvNotifyStatusChange NOTIFICATION-TYPE OBJECTS pesaFrameInvStatus, pesaFrameInvLastChanged STATUS current DESCRIPTION "Notification that a frame element's status has changed." ::= { pesaMatrixNotifications 5 } pesaSourcesNotifyStatusChange NOTIFICATION-TYPE OBJECTS pesaSourceStatus, pesaSourceLastChanged PESA S WITCHING YSTEMS...
Page 111 OBJECT IDENTIFIER ::= { pesaMatrixConformance 1 } pesaMatrixCompliances OBJECT IDENTIFIER ::= { pesaMatrixConformance 2 } pesaMatrixCompliance MODULE-COMPLIANCE STATUS current DESCRIPTION "The compliance statement for SNMP entities which manage PESA Matrices." MODULE -- this module MANDATORY-GROUPS pesaMatrixGroup, pesaMatrixNotificationGroup GROUP pesaGroupingGroup DESCRIPTION "Support for this group is only required for implementations...
Page 112 "Read-write access is only applicable when the Matrix supports dynamic configuration of matrix space." OBJECT pesaMatrixDestsUpperBound MIN-ACCESS read-only DESCRIPTION "Read-write access is only applicable when the Matrix supports dynamic configuration of matrix space." ::= { pesaMatrixCompliances 1 } -- units of conformance PESA S WITCHING YSTEMS...
Page 113 PESA S WITCHING YSTEMS...
Page 114 512 D HEETAH IGITAL IDEO ATRIX WITCHER pesaTakeSwitchRowStatus, pesaTakePreset STATUS current DESCRIPTION "This group supports notifications of significant conditions associated with a PESA Matrix." ::= { pesaMatrixGroups 1 } pesaGroupingGroup OBJECT-GROUP OBJECTS pesaSourceGroupName, pesaSourceGroupRowStatus, pesaSourceGroupMemberRowStatus, pesaDestGroupName, pesaDestGroupRowStatus, pesaDestGroupMemberRowStatus STATUS current DESCRIPTION "This group supports grouping."...
Page 115 512 D HEETAH IGITAL IDEO ATRIX WITCHER pesaMatrixNotificationGroup NOTIFICATION-GROUP NOTIFICATIONS pesaMatrixConfigurationConflict, pesaMatrixNotifyStatusChange, pesaMatrixSwitchNotification, pesaFrameNotifyStatusChange, pesaFrameInvNotifyStatusChange, pesaSourcesNotifyStatusChange, pesaDestNotifyStatusChange STATUS current DESCRIPTION "This group supports notifications of significant conditions associated with a PESA Matrix." ::= { pesaMatrixGroups 6 } PESA S WITCHING YSTEMS...
Page 116: Appendix D. - Pesa Matrix Frame Controller Debug Port Protocol
Debug Port Protocol The PESA Matrix Frame Controller Debug Port protocol is an RS-232 connection that allows service personnel to directly interact with the PESA Matrix frame controller in order to determine the health of the matrix and to perform certain diagnostics.
Page 117: Response Modes
HE – Help Menu Syntax: HELP [<cmd>] Where: cmd is optional in order to receive more help on specific commands. Response: HELP provides a list of the available commands Comment: PESA S WITCHING YSTEMS...
Page 118 ME – Memory Statistics Syntax: Where: Response: Comment: Responds with data about those memory parameters that can indicate whether the system is experiencing a memory leak or something similar. (They get what we can give them.) PESA S WITCHING YSTEMS...
Page 119 AC – Active Status Syntax: Where: Response: SINGLE – single frame controller in system. ACTIVE – active frame controller in dual system. STANDBY – inactive frame controller in dual system. Comment: Indicates whether the board is active or standby. PESA S WITCHING YSTEMS...
Page 120 Immediately after the response to this command is sent, the debug port enters into the reFLASHING mode. The board will require a reset to return to where it can receive the standard debug port commands enumerated here. PESA S WITCHING YSTEMS...
Page 121 Roll Call is used to determine if a board exists in the system, which port the board is used to communication on, which slot the board is in relative to the board type, and the boards general condition (Error and / or Over Temperature). PESA S WITCHING YSTEMS...
Page 122 Slot is the matrix board slot. Response: WC = xxxx OD1 = xxxx OD2 = xxxx CRC = xxxx Total Errors = xxxx Comment: See “Matrix Frame Controller Hardware Interface Protocol MFCHIP” to get specific information on the response. PESA S WITCHING YSTEMS...
Page 123 Output Monitor (Address = 17): WC = xxxx OD1 = xxxx OD2 = xxxx OD3 = xxxx CRC = xxxx Total Errors = xxxx Comment: See “Matrix Frame Controller Hardware Interface Protocol MFCHIP” to get specific information on the response. PESA S WITCHING YSTEMS...
Page 124 The data following the type is the hex (dec) temperature number For each board of the specified type in the system. Comment: See “Matrix Frame Controller Hardware Interface Protocol MFCHIP” to get specific information on the temperature. PESA S WITCHING YSTEMS...
Page 125 If a software module does not exist, then “Invalid” is displayed. VT – Vertical Trigger Syntax: VT [<A | B>] Where: VT – no port change. VT A – change to Port A. VT B – change to Port B Response: PESA S WITCHING YSTEMS...
Page 126 M = Matrix P = Power Supply Response: <Board Type>: <error count> <error count> … Comment: Response gives the number of error counts for all of the boards in the frame for the board type that was specified. PESA S WITCHING YSTEMS...
Page 127 The MFCHIP Debug command is used to store information about MFCHIP Buffer Descriptors and MFCHIP communication problems in a block of RAM. This information can be used to determine what type of errors are occurring with MFCHIP communications. PESA S WITCHING YSTEMS...
