GE PHP7030DTBB Installation Instructions Manual

Installation
Instructions
Questions? Call us at 1.800.432.2737 or visit GEAppliances.com.
In Canada, call 1.800.561.3344 or visit GEAppliances.ca.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT
•
for local inspector's use.
IMPORTANT
•
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Product failure due to improper installation is not
covered under the Warranty.
This appliance must be properly
grounded.
ATTENTION INSTALLER
•
— ALL COOKTOPS MUST BE HARD WIRED
(DIRECT WIRED) INTO AN APPROVED
JUNCTION BOX. A "PLUG AND RECEPTACLE" IS
NOT PERMITTED ON THESE PRODUCTS.
• Proper installation is the responsibility of the
installer and product failure due to improper
installation is NOT covered under warranty.
• Consider recycling options for your appliance
packaging material.
PARTS INCLUDED
Baffle
(For all installations
except over an oven)
4 Phillips Screws
WB01X1137
Foam Tape
WB06K5042
30 and 36"
Electric Cooktop - Induction
— Save these instructions
— Observe all governing
2 Hex-Head Screws
2 Hold Down
Brackets
or order alternate
installation kit
WB01X24570
MATERIALS YOU WILL NEED
Junction Box
(Sized for conduit per
local electrical codes.)
TOOLS YOU MAY NEED
Pencil
Phillips Head
Screwdriver
1/4" Nut Driver
Ruler or Straightedge
CUTTING THE COUNTERTOP
If you are installing the cooktop in a solid surface
material such as granite, quartz or any other natural
or synthetic solid surface, we recommend that the
cutout be prepared by a professional cabinet or
countertop installer.
Cooktop cutouts in wood or wood-laminate
countertops may be able to be prepared using a
saber saw and electric drill.
Large Size 90º or Straight
Wire Nuts Squeeze Connector
for 1" Conduit
Saber Saw
1/8" Drill Bit & Electric or
Hand Drill
Safety Glasses
31-2001162 Rev. 1 10-22 GEA
