- Page 1 VIVOTEK Fixed Dome Series Mounting Bracket Installation Guide Using AM-51E mounting bracket and compatible accessories Rev. 1.0 Ordering part no.:100171300G QIG Part no.: 625043100G IP Sur veillance...
- Page 2 Compatible VIVOTEK Cameras Fixed Dome series FD8366-V, FD8166A, FD8166A-N You may also refer to VIVOTEK's website for the list of supported models. Support for other models can be available through time. Package Contents: AM-51E, Installation Guide, 4x panhead M3x5. Installation...
- Page 3 B holes A holes AM-51E Mounting Bracket Mechanical Drawings A_100 ` 0.2 NUT-M5 NUT-M3-6X 電腦刻字(穿透) C_77.8 ` 0.2 NOTE: 1. Route cables before you secure the accessories to a wall. 2. For details on the cabling connections with network cameras, please refer to their Quick Installation Guide.
-
Page 4: Installing The Mounting Bracket
Installing the Mounting Bracket 1. Route cables through the junction box. 2. Install the bracket to the junction box using either the A or B holes. Before installation, align the A mark on the base plate with that on the rotation plate. If using the 3.5"... - Page 5 IMPORTANT: Install the bracket with the arrow mark pointing toward the shooting direction you prefer. If installed high on the wall, the arrow mark should be pointing down. If the junction box became deformed during the construction process, you can detach the rotation plate and install the bracket separately.
- Page 6 Note that you can still adjust the shooting direction by 90 degrees by turning the rotation plate. 3. Route cables through the cabling hole. 4. Pass cables through the waterproof rubber seal and complete all cabling requirements as documented in the camera QIG. 10cm...
- Page 7 5. Align the camera's shooting direction with the arrow mark, and you can find and match the mouting holes. Tighten the screws to install camera. FD8366-V FD8166A Series...
- Page 8 6. Tune and focus, and refer to the documentation that came with your cameras for the rest of configuration details. Install the dome cover. M3X5 FD8166A FD8166A top cover AM-51E FD8366-V top cover M3X5 T10 driver FD8366-V AM-51E 3.5” box...
