D811324 ver.06 22-09-08
ROLLING-CODE WITH CLONING RADIO CONTROL SYSTEM
CLONIX1-2
MITTO 2-4
433MHz
INSTALLATION AND USER'S MANUAL
Via Lago di Vico, 44
36015 Schio (VI)
Tel.naz. 0445 696511
Tel.int. +39 0445 696533
Fax 0445 696522
Internet: www.bft.it
E-mail: sales@bft.it
Advertisement
Related Manuals for BFT CLONIX1
Summary of Contents for BFT CLONIX1
- Page 1 D811324 ver.06 22-09-08 ROLLING-CODE WITH CLONING RADIO CONTROL SYSTEM CLONIX1-2 MITTO 2-4 433MHz INSTALLATION AND USER’S MANUAL Via Lago di Vico, 44 36015 Schio (VI) Tel.naz. 0445 696511 Tel.int. +39 0445 696533 Fax 0445 696522 Internet: www.bft.it E-mail: sales@bft.it...
- Page 2 ENGLISH INSTALLATION MANUAL Thank you for buying this product, our company is sure that you 1) GENERAL OUTLINE will be more than satisfied with the product’s performance. The The Clonix receiver combines the characteristics of utmost safety product is supplied with a “Warnings” leaflet and an “Instruction in copying variable code (rolling code) coding with the convenien- booklet”.
-
Page 3: Maintenance
INSTALLATION MANUAL ENGLISH as well as manage the complete installation database using the 8) MAINTENANCE EEdbase software. The maintenance of the system should only be carried out by qualified personnel regularly. MITTO transmitters are powered 5) MANUAL PROGRAMMING by a single 12V lithium battery (23A type). In the case of standard installations where no advanced functions Any reduction in the transmitter capacity may be due to the batteries are required, it is possible to proceed to manual storage of the... -
Page 4: Function Description
TABLE A When pressing the key SW1 (for channel 1) or SW2 (for channel 2) for the first time, the receiver sets to the programming mode. Every time the key SW is pressed after that, the receiver switches to the configuration for the subsequent function, that is indicated by the number of flashings (see table). - Page 5 Fig. 1 Fig. 2 BASIC PROGRAMMING OF CLONIX 2 Impulsive output 1 and 2 (to activate, for example, a control unit and its pedestrian opening) Press the key SW1 once. The led begins to flash. Press the hidden key until the led of the receiver stays on. Press the key T1, LED will flash quickly to indicate that it has been memorized Wait for the led to switch off.
- Page 6 Fig. 4 Fig. 3 CLONIX 1-2 LED DL1 UNIFLAT UNIDA UNIFLAT DIP2 DIP1 UNIMITTO Contacts UNIMITTO Fig. 4 Contacts...
