- Page 1 OHAUS TS4KS Precision Standard Electronic Balance In Stock Qty Available: 1 Used and in Good Condition Buy Today! https://www.artisantg.com/50644-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
- Page 20 Ohaus Corporation 29 Hanover Road Florham Park NJ 07932-0900 PRECISION Standard Electronic Balances TS Series Instruction Manual...
- Page 21 NOTE: NOTE: NOTE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO NOTE: NOTE: COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PUR- SUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PRO- TECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
-
Page 22: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION ....................5 DESCRIPTION ..................... 5 UNPACKING ......................6 INSTALLATION ....................7 Environment ....................7 Draft Shield ....................7 Pan and Pan Support ..................8 AC Adapter .................... - Page 23 SETUP MENU ....................22 Setup Menu Protection ................22 Unit Selection ....................23 Lock Switch ....................24 End ......................25 MENU LOCK-OUT PROTECTION ..............25 CARE AND MAINTENANCE ................26 TROUBLESHOOTING ..................26 Error Codes ....................27 SERVICE INFORMATION ................. 28 SPECIFICATIONS .....................
-
Page 24: Introduction
INTRODUCTION This manual covers installation, operation and troubleshooting for the Ohaus Precision Standard balances, Models TS120, TS200, TS400, TS400D, TS600, TS2K, TS4K and TS4KD. To insure proper operation of the balance, please read this manual completely. DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION... -
Page 25: Unpacking
UNPACKING UNPACKING UNPACKING UNPACKING UNPACKING Your Precision Standard balance was shipped with the following items: • a pan • a pan support • an AC power adapter • a draft shield (TS120, TS200 and TS400D only) includes draft shield and snap clamp •... -
Page 26: Installation
INSTALLATION INSTALLATION INSTALLATION INSTALLATION INSTALLATION Environment Environment Environment Environment Environment The balance should always be used in an environment which is free from excessive air currents, corrosives, vibration, and temperature or humidity extremes. These factors will affect displayed weight readings. DO NOT install the balance: •... -
Page 27: Pan And Pan Support
Pan and Pan Support Pan and Pan Support Pan and Pan Support Pan and Pan Support Pan and Pan Support Square Pan Square Pan Square Pan Square Pan Square Pan Insert the pan support into the hole in the weighing mechanism as shown in the il- lustration. -
Page 28: Operation
OPERATION OPERATION OPERATION OPERATION OPERATION Turning the Balance ON Turning the Balance ON Turning the Balance ON Turning the Balance ON Turning the Balance ON With no load on the pan, turn the balance ON by pressing the ON TARE button. When first switched ON, all segments of the display should be on as shown in the illustration. -
Page 29: Checking Calibration
Checking Calibration Checking Calibration Checking Calibration Checking Calibration Checking Calibration Before using the balance, calibration should be checked. The balance has been calibrated before shipment, however, it could be influenced by factors such as: • Variations in the earths gravitational field at different latitudes of the world. -
Page 30: Taring
Taring Taring Taring Taring Taring When weighing material or objects that must be held in a container, taring enables you to store the container weight in the balance’s memory, separate from the weight of the material in the container. Place an empty container on the pan. Its weight will be displayed. -
Page 31: Using Menus To Configure The Balance
USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE Precision Standard balances contain four display menus which enable you to calibrate and configure the balance for your specific operating requirements. -
Page 32: Calibration Menu
CALIBRATION MENU CALIBRATION MENU CALIBRATION MENU CALIBRATION MENU CALIBRATION MENU Precision Standard balances can be calibrated in two ways: Span calibration or Linearity calibration. Span calibration resets the balance’s weighing range using two weight values: zero and a weight value at or near the balance’s capacity. Linearity calibration minimizes deviation between actual and displayed weights within the balance’s weighing range. -
Page 33: Span Calibration
Span Calibration Span Calibration Span Calibration Span Calibration Span Calibration Press and hold until CAL is TARE TARE TARE TARE TARE displayed, then release it. Balance will display SPAN. Press TARE TARE TARE TARE TARE When is released, C 0g will be TARE TARE TARE... -
Page 34: Linearity Calibration
Linearity Calibration Linearity Calibration Linearity Calibration Linearity Calibration Linearity Calibration Turn Balance on. After zero reading, press and hold until CAL is TARE TARE TARE TARE TARE displayed, then release. Balance will display SPAN. Press and the display will show MODE MODE MODE... -
Page 35: End
Press . The display will show TARE TARE TARE TARE TARE -C- momentarily, then C followed by the next weight to be placed on the pan. Do not disturb the balance when -C- is displayed. Disturbances will result in improper calibration. Place the required weight on the pan, then press . -
Page 36: User Menu
USER MENU USER MENU USER MENU USER MENU USER MENU The User menu is used to adapt the balance to environmental conditions. It contains submenus which enable you to reset the balance to factory default settings or to select specific range settings. Access to the User menu can be disabled using the Lock Out switch. -
Page 37: Reset To Factory Defaults
To access a submenu: Repeatedly press until the de- MODE MODE MODE MODE MODE sired submenu is displayed. Press to select the displayed TARE TARE TARE TARE TARE submenu. NOTE NOTE NOTE: You must use END to store any NOTE NOTE changes you make to the User menu. -
Page 38: Averaging Level
Averaging Level Averaging Level Averaging Level Averaging Level Averaging Level Averaging level compensates for vibra- tion or excessive air currents. During op- eration, the balance continually takes weight readings from the weighing cell. Successive readings are then digitally pro- cessed to achieve a stabilized display. Use this submenu to specify how much AVERAGING LEVEL AVERAGING LEVEL... -
Page 39: Stability Range
Stability Range Stability Range Stability Range Stability Range Stability Range The stability range specifies how much a displayed weight may change while the stability indicator remains ON. When dis- played weight changes beyond the allow- able range, the stability indicator turns OFF indicating an unstable condition. -
Page 40: End
To view or change the Auto-Zero setting: Access the Auto-0 submenu to dis- play the current setting. Press to change the setting. MODE MODE MODE MODE MODE AUTO ZERO AUTO ZERO AUTO ZERO AUTO ZERO AUTO ZERO Press to accept the displayed TARE TARE TARE... -
Page 41: Setup Menu
SETUP MENU SETUP MENU SETUP MENU SETUP MENU SETUP MENU The Setup menu enables you to retain program balance parameters once they have been set. Access to the Setup menu can be disabled using the Lock Out switch. The following table shows the sequence in which submenus appear on the Setup menu. SETUP MENU TABLE SETUP MENU TABLE SETUP MENU TABLE... -
Page 42: Unit Selection
Unit Selection Unit Selection Unit Selection Unit Selection Unit Selection Unit selection permits you to specify which weighing units will be enabled for use during operation. The adjacent table lists the units available. To enable or disable the various weighing Weighing Units units, use the following procedure: g grams... -
Page 43: Lockswitch
Lockswitch Lockswitch Lockswitch Lockswitch Lockswitch Lockswitch enables you to lock out one or more menu selections. Each menu can be individually locked on or off after all func- tions have been set. The Calibration, User, and Setup menus can be individu- ally locked on or off by selecting the appropriate menu and then locked by the switch located under the right hand side of... -
Page 44: End
To lock out the other menus, press and repeat the procedure in MODE MODE MODE MODE MODE steps 3 and 4. You must use END to exit the Setup menu. Changes you make in the Setup menu Changes you make in the Setup menu Changes you make in the Setup menu Changes you make in the Setup menu Changes you make in the Setup menu... -
Page 45: Care And Maintenance
CARE AND MAINTENANCE CARE AND MAINTENANCE CARE AND MAINTENANCE CARE AND MAINTENANCE CARE AND MAINTENANCE To keep the balance operating properly, the housing and pan should be kept clean and free from foreign material. If necessary, a cloth dampened with a mild detergent may be used. -
Page 46: Error Codes
Error Codes Error Codes Error Codes Error Codes Error Codes The following list describes the various error codes and which can appear on the display and the suggested remedy. Data Errors Data Errors Data Errors Data Errors Data Errors Transient error (hardware error, probably static discharge). If error persists, the balance must be serviced. -
Page 47: Service Information
SERVICE INFORMATION If the Troubleshooting section does not resolve or describe your problem, you will need to contact an authorized Ohaus Service Agent. For Service assistance in the United States, please call Ohaus Corporation toll-free at (800) 526-0659, an Ohaus... - Page 48 MODEL MODEL MODEL MODEL MODEL TS120 TS200 TS120 TS200 TS120 TS200 TS120 TS200 TS120 TS200 TS400D TS400D TS400D TS400 TS400D TS400D TS400 TS400 TS400 TS400 TS600 TS600 TS600 TS600 TS600 TS2K TS2K TS2K TS2K TS2K TS4KD TS4KD TS4KD TS4KD TS4KD TS4K TS4K TS4K TS4K...
-
Page 49: Parts Information
PARTS INFORMATION PARTS INFORMATION PARTS INFORMATION If you require replacement parts or would like to purchase accessories, please call Ohaus Corporation toll-free at (800) 526-0659, an Ohaus Product Parts Specialist will be available to help you. REPLACEMENT PARTS REPLACEMENT PARTS... -
Page 50: Limited Warranty
Ohaus. In lieu of a properly returned warranty registration card, the warranty period shall begin on the date of shipment to the authorized dealer. - Page 51 Ohaus Corporation 29 Hanover Road, Florham Park, NJ 07932, USA Tel: (973) 377-9000, Fax: (973) 593-0359 With offices worldwide. P/N 77331-04 © Ohaus Corporation 1997, 1999 all rights reserved.
- Page 52 PAN SUPPORT Accessory P/N 76790-00 Replace the pan. Standard For PRECISION Electronic Balances ® OHAUS is the registered trademark of Ohaus Corporation as are the following Installation Instructions Installation Instructions Installation Instructions Installation Instructions Installation Instructions ® ® ® ®...
- Page 53 Models TS400, TP400 and TP600 the cover. Next, press the rear clip of the snap clamp down into place. Replace the pan and pan support. ® OHAUS is the registered trademark of Ohaus Corporation as are the following ® ® ® ® trademarks: CENT-O-GRAM...
-
Page 54: Installation Instructions
UNPACKING The Leveling Kit includes the following components: 1 FCC label 1 level assembly with 2 lockwashers 3 set screws installed 2 phillips screws 1 brass foot 4 leveling feet (2 pairs) © Ohaus Corporation 1991, 1999, all rights reserved. -
Page 55: Installation
INSTALLATION INSTALLATION INSTALLATION INSTALLATION INSTALLATION A phillips screwdriver, 1/16” hex wrench and 9/64” hex wrench will be required to install the leveling kit. Disconnect power to the balance. Remove the pan and pan support. Turn the balance over. FCC Label Remove the FCC label. - Page 56 Remove the three phillips head Remove screws which secure the balance cover to the base. 10. Hold the base and cover together and turn the balance right side up. 11. Lift the cover off. Remove Remove screw on rear panel (not shown) 12.
- Page 57 If minor adjustment is needed, use the leveling feet. 19. Recalibrate the balance as explained in the instruction manual supplied with the balance. Ohaus Corporation 29 Hanover Road, Florham Park, NJ 07932, USA Tel: (973) 377-9000,...
- Page 58 Ohaus Corporation 29 Hanover Road, Florham Park, NJ 07932, USA Tel: (973) 377-9000, Fax: (973) 593-0359 With offices in England, Germany, France, Spain, Italy, Poland, Mexico, Japan, Korea and China. © Ohaus Corporation 1996, 1998 all rights reserved. P/N 76902-30 R1198...
- Page 59 Ohaus Corporation 29 Hanover Road Florham Park NJ 07932-0900 RS232 INTERFACE ACCESSORY Part Number 77018-01 ANALYTICAL Standard Series PRECISION Standard Balance Series Instruction Manual...
- Page 60 NOTICE: NOTICE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO NOTICE: NOTICE: NOTICE: COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PUR- SUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PRO- TECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
- Page 61 TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION ....................4 INSTALLATION ....................4 USING MENUS TO CONFIGURE THE BALANCE ..........6 PRINT MENU ....................... 7 Print Menu Protection ..................7 Reset to Factory Defaults ................8 Baud Rate .....................
-
Page 62: Introduction
INTRODUCTION INTRODUCTION INTRODUCTION INTRODUCTION INTRODUCTION The RS232 Interface Accessory is a bidirectional interface which enables ei- ther a Precision Standard or an Analytical Standard balance to communicate with a printer or computer equipped with an RS232 serial port. The interface assembly is easily installed in the balance and com- munication parameters are configured through the balance’s front panel. - Page 63 Remove the cover. On the rear of the balance, a protec- tive thin plate covers the hole for the 9-pin RS232 connector. Peel off the plate to expose the hole. Remove Plate Place the circuit board and connector assembly in the balance so that the 9- pin connector fits through the hole.
-
Page 64: Using Menus To Configure The Balance
USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE USING MENUS TO CONFIGURE THE BALANCE The Analytical Standard and Precision Standard balances both contain four display menus which enable you to calibrate and configure the balance for your specific operating requirements. -
Page 65: Print Menu
PRINT MENU PRINT MENU PRINT MENU PRINT MENU PRINT MENU When the interface is installed, the Print menu is used to configure the RS232 interface parameters and customize the balance’s print functions for your requirements. The following table shows the sequence in which submenus appear on the Print menu. PRINT MENU TABLE PRINT MENU TABLE PRINT MENU TABLE... -
Page 66: Reset To Factory Defaults
To access a submenu: Repeatedly press until the de- MODE MODE MODE MODE MODE sired submenu is displayed. Press to select the displayed TARE TARE TARE TARE TARE submenu. NOTE: NOTE: NOTE: You must use END to store any NOTE: NOTE: changes you make to the Print menu. -
Page 67: Baud Rate
Baud Rate Baud Rate Baud Rate Baud Rate Baud Rate This submenu is used to select the de- sired baud rate. There are five available baud rates to choose from: 300, 1200, 2400, 4800 and 9600. To view or change the baud rate: Access the Baud submenu to dis- play the current setting. -
Page 68: Parity
Parity Parity Parity Parity Parity Parity can be set to Odd, Even, None, or a marker of 0 or 1 as follows: Access the Parity submenu to display the current setting. Press to change the setting. MODE MODE MODE MODE MODE Press to accept the displayed... -
Page 69: Auto Print Feature
Auto Print Feature Auto Print Feature Auto Print Feature Auto Print Feature Auto Print Feature When enabled, the Auto Print feature causes the balance to automatically out- put display data in one of two ways: con- tinuously, or upon stability. To select one of these Auto Print methods, or to turn the feature off: Access the AutoP submenu to dis-... -
Page 70: Print Numeric Data Only
When is released, STABLE will be TARE TARE TARE TARE TARE displayed again and the Print menu will be returned. Print Numeric Data Only Print Numeric Data Only Print Numeric Data Only Print Numeric Data Only Print Numeric Data Only This submenu is used to select numeric data only, or full display data for RS232 output. -
Page 71: Menu Lock-Out Protection
MENU LOCK-OUT PROTECTION MENU LOCK-OUT PROTECTION MENU LOCK-OUT PROTECTION MENU LOCK-OUT PROTECTION MENU LOCK-OUT PROTECTION Access to the Print Menu can be disabled using the lock-out switch located under the right side of the balance, near the display. Turn display off and unplug the power cord. Slide the balance toward you, with the front over the edge of a table. -
Page 72: Using The Interface
USING THE INTERFACE USING THE INTERFACE USING THE INTERFACE USING THE INTERFACE USING THE INTERFACE When the interface is installed, a short press on the switch will initiate a MODE MODE MODE MODE MODE print command. Data output is in the format shown under the P command in the RS232 Command Table. - Page 73 RS232 COMMAND TABLE RS232 COMMAND TABLE RS232 COMMAND TABLE RS232 COMMAND TABLE RS232 COMMAND TABLE Command Command Command Command Command Character Character Description Description Character Character Character Description Description Description ? ? ? ? ? Print current mode Field: Mode Stab CR Length: blank if stable “...
- Page 74 RS232 COMMAND TABLE (Cont.) RS232 COMMAND TABLE (Cont.) RS232 COMMAND TABLE (Cont.) RS232 COMMAND TABLE (Cont.) RS232 COMMAND TABLE (Cont.) Command Command Command Command Command Character Character Character Character Character Description Description Description Description Description Set stable data only printing (set x = 0 for OFF, or x = 1 for ON). T T T T T Same effect as pressing tare button V V V V V...
-
Page 75: Care And Maintenance
SERVICE INFORMATION If the Troubleshooting section does not resolve or describe your problem, you will need to contact an authorized Ohaus Service Agent. For Service assistance in the United States, please call Ohaus Corporation toll-free at (800) 526-0659. An Ohaus Product... -
Page 77: Limited Warranty
Ohaus. In lieu of a properly returned warranty registration card, the warranty period shall begin on the date of shipment to the authorized dealer. - Page 78 Florham Park, NJ 07932, USA Tel: +44 (0) 1954 251343, Tel: (201) 377-9000, Fax: +44 (0) 1954 250205 Fax: (201) 593-0359 With offices in Germany, France, Spain, Italy, Canada, Mexico and Japan. P/N 77017-01 R0296 © Ohaus Corporation 1993, 1996 all rights reserved.
