Summary of Contents for TRENDnet TEW-670AP
-
Page 2: Table Of Contents
Table of Content INTRODUCTION ................................ 3 .................................. 3 UMMARY ................................3 EATURES ..............................4 ACKAGE ONTENTS ............................4 YSTEM EQUIREMENTS ......................5 IRELESS ERFORMANCE ONSIDERATIONS PRODUCT OVERVIEW ............................6 INSTALLATION ................................7 ... -
Page 3: Introduction
Introduction Summary The 300Mbps Concurrent Dual Band Wireless N Access Point provides high performance wireless n speed, coverage, and managed controls. Concurrent Dual Band technology creates two separate wireless n networks at the same time—one on the 2.4GHz frequency and the other on the less congested 5GHz frequency. -
Page 4: Package Contents
CD-ROM (User’s Guide) • Cat. 5 Ethernet cable (1m / 3.2ft) • Power adapter (12V, 1A) System Requirements To begin using the TEW-670AP, make sure you meet the following as minimum requirements: • PC/Notebook. • Operating System – Microsoft Windows 7/Vista/XP/2000 •... -
Page 5: Wireless Performance Considerations
Wireless Performance Considerations There are a number of factors that can impact the range of wireless devices. 1. Adjust your wireless devices so that the signal is traveling in a straight path, rather than at an angle. The more material the signal has to pass through the more signal you will lose. 2. -
Page 6: Product Overview
Product Overview Front View • Power/ Status • Ethernet • WLAN 2.4GHz • WLAN 5GHz • Rear View • RJ-45: 1 * 10/100 Fast Ethernet • Reset Button (5 second for reboot, 5~10 seconds for reset to factory default ) •... -
Page 7: Installation
4. Click on the Properties button. You should then see a screen like the following. 5. Ensure your TCP/IP settings are correct. The default IP address of the TEW-670AP 192.168.10.100. To manage the TEW-670AP your IP address must be within the same IP... -
Page 8: Wizard Configuration
1. Open your browser (e.g. Internet Explorer). 2. Type in http://192.168.10.100 in the address bar and press Enter. 3. Click <OK> to navigate into TEW-670AP configuration home page. Click <Next> to enter WLAN configuration. Drag the security bar to your settings or enter the name for your wireless network (SSID) and security key. - Page 9 Verify if settings are accurate and click Reboot to apply settings. NOTE: After Wireless settings are applied, you need to connect from your WLAN client with the security settings you just finished configuring. Remember the type of security & security key.
-
Page 10: Advance Configuration
Advance Configuration TEW-670AP provides web-interface for configuration through web browser, such as Internet Explorer, Firefox or Safari. Status This page allows you to monitor the current status of your AP. You can use the status page to quickly see if you have any updated firmware available (bug fixes, updates). You can navigate from this page with a few interesting options for reminding or skipping this page forever &... -
Page 11: Lan
WLAN Settings: This section displays the current WLAN configuration settings you’ve configured in the Wizard / Basic Settings / Wireless Settings section. Wireless configuration details such as SSID, Security settings, BSSID, Channel number, mode of operation are briefly shown. The LAN Tabs reveals LAN settings which can be altered at will. If you are an entry level user, try accessing a website from your browser. -
Page 12: Schedule
Start IP: This will be the beginning of the pool of IP addresses available for client devices. End IP: This will be the end of the pool of IP addresses available for client devices. Domain name: The Domain Name for the existing or customized network. Schedule This page allows user to set up schedule function for Firewall and Power Saving. -
Page 13: Event Log
Event Log View operation event log. This page shows the current system log of the Broadband router. It displays any event occurred after system start up. At the bottom of the page, the system log can be saved <Save> to a local file for further processing or the system log can be cleared <Clear>... -
Page 14: Wireless 2.4G & 5G
WIRELESS 2.4G & 5G TEW-670AP is a dual band concurrent product, therefore two wireless radio configurations are provided. Both radios share the same features except for open band and available channels under “Basic” section. Basic Radio: You can turn on/off wireless radio. If wireless Radio is off, you cannot associate with AP through wireless. -
Page 15: Mode: Wds
Enable SSID#: We support 4 multiple SSIDs in this device. Please select how many SSIDs you would like to use in your network environment. ESSID1~4: ESSID is the name of your wireless network. It might be a unique name to identify this wireless device in the Wireless LAN. -
Page 16: Advanced
Set Security: WDS Security depends on your AP security settings. Note: it does not support mixed mode such as WPA-PSK/WPA2-PSK Mixed mode. Advanced This tab allows you to set the advanced wireless options. The options included are Authentication Type, Fragment Threshold, RTS Threshold, Beacon Interval, and Preamble Type. -
Page 17: Security
Disabling “Broadcast ESSID” can provide better security. WMM: Wi-Fi MultiMedia if enabled supports QoS for experiencing better audio, video and voice in applications. Encryption: When you choose to disable encryption, it is very insecure to operate TEW-670AP. - Page 18 WEP Encryption When you select 64-bit or 128-bit WEP key, you have to enter WEP keys to encrypt data. You can generate the key by yourself and enter it. You can enter four WEP keys and select one of them as a default key. Then the router can receive any packets encrypted by one of the four keys.
-
Page 19: Filter
WPA Pre-Shared Key Encryption Wi-Fi Protected Access (WPA) is an advanced security standard. You can use a pre-shared key to authenticate wireless stations and encrypt data during communication. It uses TKIP or CCMP (AES) to change the encryption key frequently. So the encryption key is not easy to be cracked by hackers. -
Page 20: Wps (Wi-Fi Protected Setup)
Enable wireless access control: Enable the wireless access control function Adding an address into the list Enter the "MAC Address" and "Comment" of the wireless station to be added and then click <Add>. The wireless station will now be added into the "Current Access Control List" below. If you are having any difficulties filling in the fields, just click "Clear"... -
Page 21: Client List
Self Pin Code: This is the WPS PIN code of the wireless router. You may need this information when connecting to other WPS-enabled wireless devices. SSID: This is the network broadcast name (SSID) of the router. Authentication Mode: It shows the active authentication mode for the wireless connection. Passphrase Key: It shows the passphrase key that is randomly generated by the wireless router during the WPS process. -
Page 22: Time
Old Password: Fill in the current password to allow changing to a new password. New Password: Enter your new password and type it again in Repeat New Password for verification purposes Time The Time Zone allows your AP to reference or base its time on the settings configured here, which will affect functions such as Log entries and Schedule settings. -
Page 23: Power Saving
Power Saving Saving power in WLAN/Ethernet mode can be enabled/disabled in this page. Diagnostic This page could let you diagnosis your current network status. Firmware This page allows you to upgrade the router’s firmware. To upgrade the firmware of your Broadband router, you need to download the firmware file to your local hard disk, and enter that file name and path in the appropriate field on this page. -
Page 24: Backup
Backup This page allows you to save the current router configurations. When you save the configurations, you also can re-load the saved configurations into the router through the Restore Settings. If extreme problems occur you can use the Restore to Factory Defaults to set all configurations to its original default settings. -
Page 25: Appendix A - Fcc Interference Statement
FCC Interference Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 26: Limited Warranty
If a product does not operate as warranted during the applicable warranty period, TRENDnet shall reserve the right, at its expense, to repair or replace the defective product or part and deliver an equivalent product or part to the customer. The repair/replacement unit’s warranty continues from the original date of purchase. - Page 27 Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go http://www.gnu.org/licenses/gpl.txt...
