No.
197:
198:
199: - 212:
213:
214:
215:
216: - 350:
If any operation error occurs after changing the setting value, change the setting value to the original one.
15.6.3 <024:CIS scan position during ADF scanning>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
This value is used when automatic scan position adjustment (TESTMODE>"2"SCAN TEST>"3"SHEET POS ADJ) fails.
15.6.4 <026:Distance from the standby position of CIS to the shading start point>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
White shading can be adjusted finely.
Normally, do not change the setting value. If any operation error occurs after changing the setting value, change the setting value to the original one.
15.6.5 <031Vertical scan start position adjustment>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Adjust the position at which vertical scanning of a book starts. The larger the adjustment value, the narrower the left-side margin of the image becomes.
15.6.6 <032Horizontal scan start position adjustment>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Adjust the position at which horizontal scanning of a book starts. The larger the adjustment value, the narrower the top margin in the image becomes.
15.6.7 <033Vertical scan magnification correction>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Correct the magnification of vertical scanning of a book. The larger the adjustment value, the more the image stretches in the vertical scanning direction.
15.6.8 <035: - 036:Reader motor speed change>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Though no market adjustment work needs to be carried out, enter factory defaults at image processor PCB replacement.
15.6.9 <041: Vertical scan start position adjustment (when scanning on a document fed from ADF)>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Adjust the position at which vertical scanning of a document fed from the ADF starts. The larger the adjustment value, the narrower the left-side margin of the
image becomes.
15.6.10 <042: Horizontal scan start position adjustment (when scanning on a document fed from ADF)>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Adjust the position at which horizontal scanning of a document fed from the ADF starts. The larger the adjustment value, the narrower the top margin of the image
becomes.
15.6.11 <043: Horizontal scan end position correction ((copy:scanning on ADF)>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Adjust the position at which horizontal scanning of a document being copied ends (when scanning on a document fed from ADF). The larger the adjustment value,
the narrower the bottom margin of the image becomes.
15.6.12 <044: Horizontal scan end position correction (superfine:scanning on ADF)>
imageCLASS MF7460 / imageCLASS MF7470 / imageCLASS MF7480
Adjust the position at which horizontal scanning of a FAX document scanned in superfine mode ends. The larger the adjustment value, the narrower the bottom
margin of the image becomes.
Function
shading target value (green)
shading target value (blue)
Not used
XYZ correction value (X) of standard white plate 8273
XYZ correction value (Y) of standard white plate 8737
XYZ correction value (Z) of standard white plate 9427
Not used
Default Setting range
272 0-511
272 0-511
1-9999
1-9999
1-9999
Chapter 15
Unit
15-25
0018-0255
0018-0256
0018-0257
0018-0258
0018-0259
0018-0260
0018-0261
0018-0263
0018-0264
0018-0265
