  • Page 1 Instruction Manual WK-MOD Wired Modular Keypad 2024 Version 2.0.0...

  • Page 2: Table Of Contents

    Appendix 3 - Surrounds (HS-MOD-xx) 1 What is the WK-MOD? The WK-MOD is a modular keypad used in a Rako Wired network, it is available in a wide variety of button configurations, as well as fully customisable button positioning and sizes should it be required.

  • Page 3: Installing The Wk-Mod

    2 Installing the WK-MOD Installation should only be carried out by a competent electrician. The WK-MOD has four visible screws on the “Front” section as shown below: These must not be adjusted. Adjusting these may damage WK-MOD Prepare cable(s) in the backbox (minimum 35mm Step 1 backbox depth) ready for connection.

  • Page 4: Terminating The Wk-Mod

    RAK-LINK within the system. No Term - Both Jumpers removed Used when the WK-MOD is not at the end of line. This is usually identifiable by two cables being punched down to the WK-MOD.

  • Page 5: Programming The Wk-Mod

    4 Programming the WK-MOD The WK-MOD is programmed using the Rasoft Pro programming software and a WK-HUB. The following instructions assume: A Project File has been created Rooms have been added to the project file The WK-HUB has been configured The Wired Network is showing no errors on the switches and RAK-LINK 4.1 Adding the WK-MOD as a Device...
  • Page 6 Assign the WK-MOD to a Room, select “Next” Put the WK-MOD into setup mode, press and hold any button on the WK-MOD, whilst keeping this button held down press any other button three times. The backlit LEDs will begin to cycle to indicate the keypad has entered setup mode, the setup window will show “Device Found”...
  • Page 7 Once a suitable template has been selected, select “Next” The WK-MOD will appear in the Device list once successfully set up. 4.1 Configuring the WK-MOD Once the WK-MOD has been assigned in Rasoft Pro, it can be configured further in the Device editor. WK-MOD...

  • Page 8: The Mapping Section

    Each input has its own letter to represent its input, there are up to 12 on the WK-MOD. New mappings can be created by selecting a disabled field and selecting the...

  • Page 9: Keypad Layout

    Room The Room number of the output command. Channel The Channel number of the output command, can be All Channels or a single Channel. Disable map When enabled, the button input will have no output command. WK-MOD Manual Version 2.0.0...
  • Page 10 Set the temperature output. Macro Trigger an internal Macro on the Device; this is not the same as triggering a Macro on a HUB. Macros can be created on the ‘Macro’ tab above the button configuration. WK-MOD Manual Version 2.0.0...

  • Page 11: Keypad Layout Editor

    4.1.4 Keypad Layout Editor The WK-MOD has fully customisable button layouts, which can be configured in the WK-MOD Device menu. The Keypad Layout Editor is found by selecting the tab above the mappings window: Existing templates can be loaded into the mapping page which will change the button layout.

  • Page 12: Appendix 1: Troubleshooting The Wired Network

    RAK-LINK diagnostics - For fault finding, “Daisy Chain” and “STAR” configuration. RAK-STAR diagnostics - For fault finding, “STAR” configuration. A1.1 WK-MOD Diagnostics Letter Indicates Uses/example CAN Transmission Cannot communicate with CAN bus.

  • Page 13: Appendix 2 - Wiring Examples

    More than one Device can be connected to a leg on a STAR system, Devices in the middle of a loop in/loop out should be set to TERM, and the end of lines should be set to STAR. WK-MOD Manual Version 2.0.0...

  • Page 14: Appendix 3 - Surrounds (Hs-Mod-Xx)

    Appendix 3 - Surrounds (HS-MOD-xx) To complete the installation of the WK-MOD a HS-MOD-xx is required as shown above. This is available in a variety of finishes including: ● Satin Chrome (Silk) surround kit - HS-MOD-SC ● Polished Chrome surround kit - HS-MOD-PC ●...
