W ired RAK Application Sheet What is the WCM-072? The WCM-072 wired keypad is a seven button keypad for use with the wired system. It will transmit Scene 1-4 and Off in one room and Scene 1 and Off in another before any custom programming is added.
Page 2
Screw the grid for the screwless cover plate into the backbox. TIP: If the wired network is powered then the backlit LEDs on the keypad will illuminate. Step 5 Clip the cover plate into the grid to complete installation. WCM-072 Manual Version 2.0.2...
Page 3
Finally screw the cover plate into the back box Step 5 through the screw holes in the transparent surround. Installation of the WCM is now complete. WCM-072 Manual Version 2.0.2...
Page 4
WCM Diagnostic Feedback - For fault finding “Daisy Chain” and “Star” configuration. RAK-LINK diagnostics - For fault finding “Daisy Chain” and “Star” configuration. RAK-STAR diagnostics - For fault finding “Star” configuration. WCM-072 Manual Version 2.0.2...
