- Page 1 FINE COAT FC 9700 OPERATING MANUAL wagner-group.com...
- Page 2 FineCoat 9700 ...
- Page 3 FineCoat 9700 Maximum Minimum Minimum 3 - 10 cm ...
- Page 4 FineCoat 9700...
- Page 5 FineCoat 9700...
-
Page 6: Table Of Contents
FineCoat 9700 CONTENTS Translation of the original operating instructions Contents Explanation of symbols used SAFETY REGULATIONS ______________________ 13 This symbol indicates a potential danger EXPLANATORY DIAGRAM ____________________ 15 for you or for the device. CHOOSING THE SPRAY NOZZLE SET ___________ 15 Under this symbol you can find important information on how to 3.1 Swapping the spray nozzle set _________________ 15... -
Page 7: Safety Regulations
FineCoat 9700 SAFETY REGULATIONS c) Avoid accidental starting-up. Ensure that the switch SAFETY REGULATIONS is in the “OFF” position before inserting the plug into the socket. Accidents can occur if you carry the power tool while your finger is on the switch or if you connect the power All local safety regulations in force must be observed. - Page 8 FineCoat 9700 SAFETY REGULATIONS personnel and only with original spare parts. This be taken that no solvent vapours are driven to the ensures that the tool safety is maintained. motor-operated blower or that no solvent containing vapours form in the area around the paint spraying b) If the supply cord is damaged, it must be replaced by system.
-
Page 9: Explanatory Diagram
FineCoat 9700 EXPLANATORY DIAGRAM/ CHOOSING THE SPRAY NOZZLE SET EXPLANATORY DIAGRAM (FIG. 1) POS. DESIGNATION POS. DESIGNATION Air filter indicator ((lights up red if the main air filter is Spray gun complete blocked)) Spray jet width adjustment Air hose connection Air cap (to set the working direction) Storage compartment for small parts / accessories Ventilating hose... -
Page 10: Technical Data
FineCoat 9700 TECHNICAL DATA/ INTRODUCTION/ PREPARING THE COATING MATERIAL TECHNICAL DATA COATING MATERIAL COATING MATERIALS SUITABLE FOR USE Voltage: 230 V~, 50 Hz Solvent-based and water-soluble lacquer paints Power consumption: 1150 W Mordants, glazes, impregnations, oils, clear varnishes, syn- Max. current consumption thetic enamels, coloured paints, alkyd resin varnishes, prim- ers, radiator paints, hammer effect enamels, anti-rust paints, Spray nozzle set (standard) -
Page 11: Setting The Spray Gun
FineCoat 9700 SETTING THE SPRAY GUN /STARTING OPERATION/ SPRAYING TECHNIQUE SETTING THE SPRAY GUN STARTING OPERATION SETTING THE REQUIRED SPRAY PATTERN (FIG. 6) Before connecting to the mains supply make sure that the mains voltage corresponds to the operating voltage on the rating plate. -
Page 12: Transportation
FineCoat 9700 BREAKS IN WORK/ TRANSPORTATION/ TAKING OUT OF OPERATION AND CLEANING 12.1 ASSEMBLY TRANSPORTATION ATTENTION! Follow the steps described below exactly for assembly. Otherwise 1. Coil power cable around the basic unit. the gun may be damaged. 2. Insert spray gun into gun mounting on the device. 3. -
Page 13: Correction Of Malfunctions
FineCoat 9700 MAINTENANCE Warning If the supply cord of this appliance is damaged, it must only be replaced by a repair shop appointed by the manufacturer, because special purpose tools are required. The wires in this mains lead are coloured in accordance with the following code: green/yellow = earth blue = neutral... -
Page 14: Accessories And Spare Parts
FineCoat 9700 CORRECTION OF MALFUNCTIONS MALFUNCTION CAUSE REMEDY • • Atomisation too coarse Material volume too large Reduce volume • • Nozzle contaminated Clean • • Viscosity of coating material too high Dilute further • • Too little pressure build-up in Tighten container container •... -
Page 15: Spare Parts Finecoat 9700
FineCoat 9700 ACCESSORIES AND SPARE PARTS 15.2 SPARE PARTS FINECOAT 9700 (FIG. 18) ORDER NO. POS. DESIGNATION 2434503 Filter cover set 2434505 Air filter (4 pcs.) 2434506 Storage compartment cover 2442013 Air hose 2430409 Cleaning brush set 2324 751 Air hose fixing strap 15.3 SPARE PARTS GUN (FIG. -
Page 16: Testing Of The Unit
Wagner or one of our dealers will take back your used Wagner waste electrical or electronic equipment and will dispose of it for you in an environmentally friendly way. Please ask your... - Page 20 Info@orkla.se Deutschland conseil@euromair.com Tel.: +49 / 75 44 / 505 -1664 Fax: +49 / 75 44 / 505 -1155 wagner@wagner-group.com www.wagner-group.com AUS Wagner Spraytech Australia Pty. Импортёр: Изготовитель: Ltd. ООО «ВинТех рус» Дж. Вагнер Гмбх, 8 – 10 Dansu Court 143960 МО, г.
