Alpha WSERD30-B Manual

1. TECHNICAL SPECIFICATIONS
Protection index: IP20
Up to 15 remotes can be assigned
to each motor.
2. CHARGING AND WAKING UP
!
Please charge the motor using the
The motor won't function until it has been charged.
Method A
Plug 5V 1A
for a few seconds till motor vibrates.
Method B
Short press
the motor vibrates, then release, the
once and buzzer sounds once.
3. PAIR REMOTE TO MOTOR
Press program button for
2 second , the motor will vibrate. s
4. CHANGING THE RUNNING DIRECTION
Method A.
Press motorhead's button for about 10 seconds until the motor vibrates 3 times, then release.
The LED flashes red 3 times and buzzer sounds 3 times.
Method B.
Press UP and DOWN buttons
simultaneously.
5. TURN ON STEP BY STEP FUNCTION
Note: If the motor is in step-by-step mode, pressing the UP or DOWN button for 3s will make the motor will run continuously.
Press UP and DOWN buttons
simultaneously.
Alpha Tubular Motors Pty Ltd
Unit 108, 12 Pioneer Avenue
Tuggerah NSW 2259 Australia
WSERD30-B
ALPHA SUPPORT PHONE (02) 4355 4775
Received frequency: 433.92MHz
Working Temperature: -10°C - 60°C
Charging: 5V/1A Type C
M OTOR
5V 1A charger before operation.
charger into charging port
program button for 2 seconds,
LED will flash
Press UP and DOWN once
simultaneously and release.
3
Long press for 10 seconds
Press the STOP button
6 times within 10s.
The motor will move in small increments
Press the STOP button
once within 10s.
5V
es red
Press the STOP button once,
the motor will vibrate.
Press the DOWN button once
within 10s, the motor will vibrate.
Press the UP button once within
10s, the motor will vibrate.
GUIDE p
Battery: Lithion-ion
18650-2550mAh 11.1V radio
Charge time: 5-6 hours
Charging port
Programming button
The remote is paired and
can control the motor.
The motor's running direction is reversed.
The motor's running direction
is reversed.
per remotes button press .
The motor will run
step by step.
sales alphamotors.com.au @
www. alphamotors
T +61 2 4355 4775
1
.com.au
