Alpha WSERD30-B 1/30C Manual

WSERD30-B 1/30C MOTOR GUIDE p1
1. TECHNICAL SPECIFICATIONS
Protection ndex: IP20 I
Up to 15 remotes can be assigned
to each motor.
2. CHARGING AND WAKING UP
!
Please charge the motor using charger V/1A before operation.
The motor won't function until it has been charged.
Method A
Plug 5V/1A
for a few seconds till motor vibrates.
Method B
Short press program button 5 times and
release, the LED light turns green, and the motor
vibrates.
3. PAIR REMOTE TO MOTOR
Press program button for
half a second, the motor will vibrate.
4. CHANGING THE RUNNING DIRECTION
Method A.
Short press motor's program button 3 times, LED flashes red 3 times, motor vibrates.
Method B.
Press UP and DOWN buttons
simultaneously.
5. TURN ON STEP BY STEP FUNCTION
Note: If the motor is in step-by-step mode, pressing the UP or DOWN button for 3s will make the motor will run continuously.
Press UP and DOWN buttons
once simultaneously.
ALPHA SUPPORT PHONE (02) 4355 4775
Received requency: 433.92MHz
Charging: V/1A Type C
Working Temp: -10°C to 60°C
M OTOR
5
charger into charging port
Press UP and DOWN
together and release.
3
1
Short press motor
Press the STOP button
6 times within 10s.
The motor will move in small increments
Press the STOP button
once within 10s.
F
5
USB Charging port
Press the STOP button once,
the motor will vibrate.
Press the DOWN button once
within 10s, the motor will vibrate.
Press the UP button once within
10s, the motor will vibrate.
Code: Rolling
Charge ime: 5-6 hours T
Programming button
Reserved interface
( for factory use only
The remote should now
control the motor.
The motor's running direction is reversed.
The motor's running direction
is reversed.
per remote's button press .
The motor will run
step by step.
)
