- Page 1 BEST QUALITY 100% GUARANTEED Faucet and Soap Dispenser in One TiO-32/TiO-34 INSTALLATION MANUAL Models TiO-32 & TiO-324 866 558 3200 info@macfaucets.com TiO-34 & TiO-344 www.macfaucets.com...
-
Page 2: Tools Needed
Tools Needed Model TiO-32 Rubber Washer Lock Nut Dispenser hose Sensor Cable Model TiO-34 Sensor cable Plug to Faucet Hose Solenoid Valve Plug to power Optional supply AC Adapter Plug to power supply 1/2” - 14 2-13/16 Y cable connector... - Page 3 TIO 32/TIO 34 INSTALLATION MANUAL Rubber Washer Faucet Disc Rubber Washer Lock nut Sealing Gasket Lock nut Sensor Cable Sensor Cable Insert faucet shank through sink hole Place washer and lock nut onto shank Tighten lock nut Mark holes for valve and install on Connect cold supply line the wall, follow instructions on label NOTE: Drain the water line before the hose...
- Page 4 LIMITED WARRANTY Mac Faucets warrants this product to be free of defects for a period of one year from date of purchase. Mac Faucets will replace, free of charge, during this warranty period, parts that prove defective when properly installed and under normal use and service.
- Page 5 Sensor Cable plugs and push into place. housing. Plug to Solenoid Valve Y Cable connector PYOS & BY MAC FAUCETS SYSTEMS SOAP REFILL INSTRUCTIONS 1. Unscrew bottle 2. Add soap 3. Soap bottle back. Do not overtighten Connect Power cable...
-
Page 6: Battery Replacement Instructions
DO NOT USE HEAVY CREAM SOAPS OR GRIT TYPE SOAPS It is best to use same brand of soap every time, and not to let dispenser remain dry for to long PYOS & BY MAC FAUCETS SYSTEMS SOAP REFILL INSTRUCTIONS PYOS &... - Page 7 TIO 32/TIO 34 INSTALLATION MANUAL GALLON CONTAINER INSTALLATION NOTE: GALLON CONTAINER MUST BE PLACED ON LEVEL SURFACE CAPABLE OF SUPPORTING 10LB WEIGTH OR GREATER Center Line Place the gallon container against the wall underneath the bracket. 11” Mount wall bracket onto wall in a level horizontal position.
- Page 8 TIO 32/TIO 34 INSTALLATION MANUAL Available Washroom Accessories TiO-324 TiO-344 ADA Grab Series Two-in-one Automatic Two-in-one Automatic Models GB-18, GB-36 and GB-42 Faucet and Soap Dispenser Faucet and Soap Dispenser (with 4” riser for high vessel sink) (with 4” riser for high vessel sink) ATD-10 AAD-12 ASD-13...
