- Page 1 BEST QUALITY 100% GUARANTEED MTV 1 MUV 1 INSTALLATION MANUAL MAC FAUCETS Products Model 866 558 3200 info@macfaucets.com MTV-1 Toilet Flush Valve MUV-1 Urinal Flush Valve www.macfaucets.com...
- Page 2 **Water pressure over 80 psi is not recommended with most plumbing xtures Limited Warranty Mac Faucets warrant this faucet to be free of defects for a period of one Right or Left Hand Installation year from date of purchase. Mac Faucets will replace, free of charge, during this warranty period, parts that prove defective when properly installed and under normal use and service.
-
Page 3: Recommended Tools
MTV 1 & MUV 1 INSTALLATION MANUAL IMPORTANT: Recommended Tools Fig. 3 • All plumbing must be installed in accordance with applicable codes and regulations. 1. Te on Tape • The use of water hammer arrestors is strongly recommended for commercial applications. All 2. - Page 4 MTV 1 & MUV 1 INSTALLATION MANUAL Fig. 5 Fig.5a FINISHED WALL Install Tube Sleeve, Wall Escutcheon and Supply Stop Fig. 5 TEFLON TAPE 1. Measure from nished wall to rst thread of Adapter or threaded supply pipe (dimension “X”). Cut Tube Sleeve (1) Fig.
- Page 5 MTV 1 & MUV 1 INSTALLATION MANUAL Fig. 7 Install Flush Valve Fig. 7a & 7b 1. As shown in Fig. 7, Slide the TAILPIECE (1) of the FLUSH VALVE (2) into the SUPPLY STOP VALVE (3). Lubricate the TAILPIECE O-RING (4) with water if necessary.
- Page 6 If these items do need replacement they must be purchased separately or order the complete ush valve assembly from MAC Faucets. 1. Remove the soap valve cap (1) from SUPPLY STOP (2) if installed.
