Mac Faucets AUV-3 Owner's Manual

Flush valve
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
MAC FAUCETS LLC.
Owner's Manual Model AUV-3 and ATV-3
AUV-3 Urinal Flush Valve
ATV-3 Toilet Flush Valve

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUV-3 and is the answer not in the manual?

Questions and answers

Related Manuals for Mac Faucets AUV-3

Summary of Contents for Mac Faucets AUV-3

  • Page 1 MAC FAUCETS LLC. Owner's Manual Model AUV-3 and ATV-3 AUV-3 Urinal Flush Valve ATV-3 Toilet Flush Valve...
  • Page 2 MAC FAUCETS LLC. Check your local code and regulations for all plumbing. Water Supply Lines must be the proper size to provide the volume of water required for each unit Flush the water lines through the stop valve at high volume prior to installing...

  • Page 3: Tools Needed

    Tools Needed AUV-3 and ATV-3 NOT SUPPLIED Crescent Wrench or Wide Open Pipe Wrench to tight hex nuts from 1-1/4” to 2”, do not use toothed pipe wrench that can damage the decorative finish of the flush valve Flat screw driver to open/close stop valve, and to adjust water flow Valve is shipped with 4 AAA batteries pre-installed.

  • Page 4: System Flushing

    Stop Valve Installation Before the supply water is turned on, make sure all stop valves are closed tight. To close the valve turn adjustment screw clockwise . Solder sweat adapter onto existing copper tube (if needed). Measure and Flange cut sleeve tube (if needed). Slide flange and tube sleeve over pipe.
  • Page 5 Urinal or Toilet Place flush valve on top of vacuum breaker Spud escutcheon tube. Mate valve body with vacuum breaker tube nut Hand tighten both vacuum breaker tube AUV-3 nut and coupling nut (DO NOT CROSS THREADS). MAC FAUCETS LLC.

  • Page 6: Wire Connections

    Vacuum Breaker Tube Length Measure the length of vacuum breaker tube accurately. If cutting is needed proceed to step 12. If cutting it is needed uninstall and remove the vacuum breaker tube, and make a straight cut. Sand off the sharp edge of the cut. Re-install the vacuum breaker tube to the spud coupling first, and then to the flush valve body.

  • Page 7: Operation

    Place the flush valve cover back on with sensor facing forward. Refasten Allen screws. DO NOT FORGET PLASTIC WASHERS. The flush valve is ready for use. Red Cable, sensor Black Cable, sensor to solenoid to battery pack. MAC FAUCETS LLC.
  • Page 8 Flush valve top cap Manual flush assembly Tailpiece Vacuum breaker thrust washer Vacuum breaker Vacuum breaker tube Vacuum breaker nut Spud nut Spud thrust washer Spud rubber washer Spud escutcheon Stop valve cap Plastic crown nut Stop valve bonnet Stop valve repair kit Vandal resistant stop Stop valve assembly Stop valve body only...

This manual is also suitable for:

Atv-3
