Document
LPN00709X0001A0_B
Date:
06-13-2023
INSTALLATION INSTRUCTIONS
Created By:
TMT
C-AR-A-SAL Series
FIGURE 12
C L
ø0.344" (9 mm) hole
2 Required
2.000"
(51 mm)
1.375"
(35.0 mm)
5.5"
(140 mm)
ø0.625" (16 mm) hole
NOT TO SCALE
