Polon-Alfa DUT-6046AD Installation And Maintenance Manual

Smoke and heat detector
Hide thumbs

Advertisement

Table of Contents

SMOKE AND HEAT DETECTOR
DUT-6046AD TYPE
WITH G-40S BASE,
SOUNDER
AND SHORT CIRCUIT ISOLATOR
POLON 4000 and POLON 6000 INTERACTIVE FIRE DETECTION AND ALARM SYSTEM
_________________________________________________________________________________
INSTALLATION AND MAINTENANCE MANUAL
IK-E372-001
IB Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DUT-6046AD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Polon-Alfa DUT-6046AD

Summary of Contents for Polon-Alfa DUT-6046AD

  • Page 1 SMOKE AND HEAT DETECTOR DUT-6046AD TYPE WITH G-40S BASE, SOUNDER AND SHORT CIRCUIT ISOLATOR POLON 4000 and POLON 6000 INTERACTIVE FIRE DETECTION AND ALARM SYSTEM _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E372-001 IB Edition...
  • Page 2 IK-E372-001 The DUT-6046AD Universal Smoke and Heat Detector with Sounder, which is the subject of this manual, meets the essential requirements of the following European Parliament and Council (EU) regulations and European Union directives: CPR/305/2011 The European Parliament and the Council (EU) regulation of March 9, 2011 stipulating harmonized conditions for placing construction products on the market and repealing Council Directive 89/106/EEC;...
  • Page 3 IK-E372-001 POLON-ALFA S.A. 85-861 Bydgoszcz, ul. Glinki 155 DUT-6046AD TYPE SMOKE AND HEAT DETECTOR WITH G-40S BASE, SOUNDER AND SHORT CIRCUIT ISOLATOR DUT-6046AD Intended use: Fire safety - point smoke detector based on the scattered light and heat principle, with an integrated short-circuit isolator and sounder, designed for fire alarm systems used in buildings.
  • Page 4 IK-E372-001 H a r m o n i z e d t e c h n ic a l s p e c if i c a t i o n E N 5 4 - 3: 20 0 1 Per for m an ce Pr o d u ct es sen ti a l f eat u r es A1 :2 00 2...
  • Page 5 IK-E372-001 H a r m o n i z e d t e c h n ic a l s p e c if i c a t i o n E N 5 4 - 5: 20 0 0 Pr o d u ct es sen ti a l f eat u r es Fea tu r es A1 :2 00 2...
  • Page 6 IK-E372-001 H a r m o n i z e d t e c h n i c a l s p e c if i c a t i o n Pr o d u ct es sen ti a l f eat u r es Fea tu r es E N 5 4 - 7: 20 0 0 A1 :2 00 2 + A2 :2 00 6...
  • Page 7 IK-E372-001 H a r m o n i z e d t e c h n i c a l s p e c if i c a t i o n Pr o d u ct es sen ti a l f eat u r es Fea tu r es E N 5 4 - 1 7:2 0 05 AC :2 00 7...

  • Page 8: Intended Use

    The detectors are equipped with an internal short-circuit isolator and sounder. The DUT-6046AD Universal Addressable Smoke and Heat Detectors are intended for operation in the addressable detection...

  • Page 9: Operation Description

    IK-E372-001 4 OPERATION DESCRIPTION The DUT-6046AD Smoke Detector operates based on the Tyndall principle: light scattering on smoke particles. Smoke particles entering the measuring chamber reflect the light emitted by the emitting diode. The scattered light reaches the photodiode resulting in photocurrent. Heat entering the detector causes changes in thermistor resistance.
  • Page 10 IK-E372-001 Interaction: - Independent sensors (0) - sensors work independently (OR feature) - Interdependent sensors (1) - an increase of fire factor in one sensor increases sensitivity of the other sensor and accelerates fire detection, - Sensors in coincidence (2) - sensors operate in coincidence (AND function), for the detector to signal an alarm, the alarm threshold must be exceeded by two sensors sensing different fire factors, i.e.

  • Page 11: Operating Conditions

    LED, which shows correct communication with the control panel. Prolonged use of the DUT-6046AD Detector can cause dust to accumulate inside the smoke detector. After exceeding the self-regulation range, as a result of progressive soiling of the smoke detector, the detector enters a technical alarm condition, sending information on excessive contamination to the control panel.
  • Page 12 IK-E372-001 After assembly, the detector should be checked using a smoke imitator (producing no heat), and then using a temperature simulator (producing no smoke). The detector should be then reinstalled in the detection line. NOTE: If cleaning does not allow to reach the desired result, the detector should be sent to the manufacturer for repair.
  • Page 13 IK-E372-001 7 DETECTORS INSTALLATION The detectors are installed (height, layout) in accordance with selected design guidelines. The detectors are installed in rooms where equipment and accumulated materials will emit visible smoke when the fire starts. If it is difficult to determine the most likely fire factor (type of smoke) that may be produced in the first stage of fire development, appropriate tests should be performed (at the design stage) using several types of detectors or mixed protection should be adopted, e.g.

  • Page 14: Safety Conditions

    9 STORAGE AND TRANSPORTATION 9.1 Storage The DUT-6046AD Detectors should be stored in closed rooms with no corrosive vapors and gases in the atmosphere, within the temperature range from 0°C to +40°C, and with the relative humidity below 80% at +35°C.
  • Page 15 IK-E372-001 Fig. 5. The directional characteristics of the detector siren seated in base. IK-E372-001/12.2018...
  • Page 16 IK-E372-001...
  • Page 17 IK-E372-001...
