- Page 1 TUP-40 FIXED TEMPERATURE/RATE-OF-RISE HEAT DETECTOR _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E291-001GB IIB Edition...
- Page 2 IK-E291-001GB The TUP-40 heat detector, covered by this manual, complies with the requirements of the following European Union directives: 89/106/EWG - on construction goods; 2004/108/WE - on electromagnetic compatibility. The TUP-40 detector has been approved with the EC Certificate of Conformity No. 1438/CPD/0019, issued by the Scientific and Research Centre for Fire Protection (CNBOP) Józefów, Poland, an EU...
-
Page 3: Technical Specifications
1 PURPOSE The TUP-40 heat detector is designed for detection and indication of a fire hazard or a fire in indoor premises, in which during the initial phase of a fire a very fast rise of temperature can be observed or –... -
Page 4: Design Descriptions
Fig. 1 TUP-40 heat detector design 5 PRINCIPLE OF OPERATION The TUP-40 heat detector reacts to rise of temperature which occurs in the initial phase of a fire. In case a pre-set temperature rise threshold is exceeded, the detector electronic circuit transmits a current signal to the fire control panel. -
Page 5: Installation
IK-E291-001GB Table 1 A1R class Rate of air temperature rise from typical Minimum Maximum operation temperature actuation time actuation time K/min The heat detectors operation parameters are listed in Table 2 (acc. to PN-EN 54-5:2003 standard). Table 2 Maximum Minimum Maximum static Typical operation Detector class... -
Page 6: Servicing And Maintenance
IK-E291-001GB 7 SERVICING AND MAINTENANCE During the operation life, the TUP-40 detector should be subjected to periodical inspection at least once per 6 months in order to confirm the detector proper operation and its appropriate interoperation with the control panel. During periodical inspections it is necessary to remove a possible dust layer, spider-web and other detection circuit contamination. - Page 7 IK-E291-001GB...
