Optoma HD26 Setup And Operation Instructions

Optoma HD26 3D Projector setup and operation, revision 4
1. Components:

Optoma HD26 3D Projector

HP Laptop Computer – Windows 10

Unipolar X-Shutter 10 polarization modulator
2. Connect all power cords and cables to the equipment.

Power cords for all three components

HDMI cable between projector and computer, make sure that it's plugged in all the way
Note: HDMI #1 is normally used on the projector. If HDMI #2 is used, it must be selected on
the remote control to make it the current active input.

Synchronization cable between polarization modulator and projector

Audio-out cable from projector to sound system
3. Turn on equipment
A. Power up projector first. The HDMI icon that appears in the lower RH corner indicates
that the projector is ready.
B. The polarization modulator can be powered up second so it's not forgotten, but does not
need to be on until the stereo projection is ready to start.
C. Power on the computer. The computer must detect the projector at start-up.
D. Wait until the projector is ready before trying to send any media to the screen.
E. The volume for the projector should be at the maximum of 10 if the sound is to be
controlled by an external sound system. This will be the case at DSS meetings. Make sure the
audio-out cable is inserted into the projector.
4. Stereoscopic 3D software and executable program types

StereoPhoto Maker

Stereoscopic player

M.Objects

ProShow (executable slide show)

MyAlbum (executable slide show)

5. Adjust the projector for on-screen display
A. The image size is controlled by the distance to the screen and the lens zoom
adjustment. Work the focus as the size is being set, since the focus also affects screen
size. If a presentation involves 16:9 ratio, use a full sized 1920 x 1080 image for setup.
B. Focus sharply at final screen size.
Last saved: 2/5/2019
(for photos)
(for video)
(executable slide show)
