GENERAL SAFETY RULES WARNING: Do not attempt to operate the machine until you have thoroughly read and completely understood all instructions, rules, etc. contained in this manual. Failure to comply may result in accidents involving fire, electric shock, or serious personal injury. Keep this owner's manual and review frequently for continuous safe operation.
Page 3
18. Always wear a face or dust mask if operation creates a lot of dust and/or chips. Always operate the tool in a well ventilated area and provide for proper dust removal. Use a suitable dust extractor. ADDITIONAL RULES FOR Morticers 1.
Unpacking and Assembly Cut the strapping and open the box 2 which contains the floor stand. Remove all parts from the packaging. Open the door and remove the bag containing the feet. Note that the keys to lock the door are secured to the inside of the lock.
Page 5
The table bed is locked in position for safe transport. Locate the locking socket head bolt on the front, which locks lateral table movement and loosen it. Locate the ratchet lever on the right hand side, which locks longitudinal movement and loosen it. Take the handle and pass it through the hole in the shaft.
Page 6
Fit the two hold down clamps over the vertical bars as shown. Squeezing the locking plate and the thumb rest together will allow the clamp to slide up and down. Use the cam lever to lower the round pad and clamp the timber.
Page 7
Setting the Chisel & Auger Wearing a sturdy glove or using a cloth to support the sharp end of the chisel & auger. Insert the chisel & auger up into the bushing and into the drill chuck. Lock the chisel into place using the socket head bolt.
Page 8
On the left hand side of the morticer there is a scale and two ratchet handles on a sliding collar. The upper handle is used to set the starting position of the head. Lowering the starting position of the head is useful when working with small timbers and speeds up the process.
Page 9
Using the Morticer Set the gap between auger cutting lip and chisel tips. Next set the chisel square to the back fence. The easiest way to do this is to lower the chisel and wind the sliding bed forwards until it just touches the back of the chisel.
Position the table so that the chisel cuts almost its complete width. The chippings will be ejected into the space created by the previous cut. Continue moving along the mortice, cutting a series of holes, until the complete length of the mortice has been cut. If a mortice deeper than 20mm is required: Go back to the position of the first cut and repeat the procedure going deeper with the chisel.
Speed of cut is too slow Move chisel through timber faster Declaration of Conformity for CE Marking Charnwood Declare that Hollow Chisel Morticer, Model W325 Conforms with the following Directives: Machinery Directive 2006/42/EC Low Voltage Directive 2006/95/EC And further conforms to the machinery example for which the EC type examination Certificate No.
Page 12
Charnwood W325 Morticer Parts Drawing A...
Page 13
Charnwood W325 Morticer Parts List A A001 Base A061 Screw, M6 x 10mm A002 Middle Base A062 Cover A003 Drift A063 Gear A004 Set Screw, M6 x 35 A064 Shaft A005 Hex Nut M6 A065 Connecting Bend A006 Washer M10...
Page 14
Screw M6 x 25 A119 Screw M8 x 20 A060 Chuck 16mm A120 #CAP Capacitor 16uf 450V Charnwood W325 Morticer Parts Drawing B Charnwood W325 Morticer Parts List B Base Stand Base Stand Hex Nut M10 Door Washer M10 Door Latch...
Page 15
Charnwood W325 Morticer Parts Drawing C Charnwood W325 Morticer Parts List C Shaft Locking Handle Setting Piece Locking Screw Spring Spring Clamping Body C-Clip/ Circlip Stop Disc...
