- Page 1 AUSSIE SAFE BLASTING AUSSIE RAPTOR JULY 2019 Engine Drive Hydro-Blasters SAFE OPERATOR INSTRUCTION MANUAL SAFETY NO.1 Read this manual before using this blaster Covers: Raptor 16 Raptor 18 REF: ARAPENG_MANVER3...
-
Page 2: Blaster Risk Assessment
AUSSIE HIGH PRESSURE BLASTER RISK ASSESSMENT MODELS: In line with the National Occupation Health & Safety Commission’s requirements the data below applies to the following Aussie high pressure water blaster models: Raptor 16 (Class B) Raptor 18 (Class B) ... - Page 3 AUSSIE SAFE BLASTING Aussie Pumps July 2019 Risks associated with operating a high pressure cleaner … for use in daily SAFE WORK METHOD STATEMENT Risk Hazard Risk Controls Rating Entanglement with hose Personal injury of the Warning stickers (tripping, falling) operator or bystanders ...
-
Page 4: Table Of Contents
AUSSIE SAFE BLASTING Aussie Pumps July 2019 AUSSIE ECO CLEAN RAPTOR OPERATOR & MAINTENANCE INSTRUCTIONS Contents: Troubleshooting ............10 Blaster Risk Assessment ..........2 Personal Protective Equipment ......... 11 Warranty ..............4 Operator’s Hand signals ..........12 Safety precautions ............5 Accident Reporting ............ -
Page 5: Safety Precautions
SPECIFICATIONS Model Stock code Engine Pump Pump Pressure Flow rate Pump Model (psi) (lpm) Raptor 16 ABSSRAP/VAN16L Vanguard 31HP RA1650 7,300 PSI 1450 Raptor 18 ABSSRAP/VAN18L Vanguard 35HP RA1850 7,300 PSI 1450 Note: Certification of the operator is mandatory for Class B machines …... -
Page 6: Assembly & Preparation For Use
AUSSIE SAFE BLASTING Aussie Pumps July 2019 ASSEMBLY AND PREPARATION FOR USE Machine Preparation (initial start-up) Before proceeding with assembly of your new Aussie Eco Check pump gearbox. Raptor high pressure blaster, check that all parts listed Note separate reservoirs. With the machine on a below are included. -
Page 7: Hose Connections
AUSSIE SAFE BLASTING Aussie Pumps July 2019 Hose Connections Connect high pressure hose to machine outlet. Connect gun/lance assembly to high pressure hose. Rev lever hose shroud cover coupling. NOTE: Safety Standard AS/NZS 4233.1 requires a hose restraint to be used on coupling between gun... -
Page 8: Care & Maintenance
AUSSIE SAFE BLASTING Aussie Pumps July 2019 Failure release pressure before in the centre of the gauge. If oil level is low, fill to disconnecting the hose quick coupler will correct level with recommended oil (SAE 75W-90). result in the quick coupler o-ring seal DO NOT OVERFILL CRANKCASE! blowing out. -
Page 9: Grit Blaster Instructions (Optional Accessory)
AUSSIE SAFE BLASTING Aussie Pumps July 2019 AUSSIE GRIT BLAST INSTRUCTIONS (optional accessory) GRIT BLAST HEAD SET UP INSTRUCTIONS WARNING: To reduce the risk of injury, always protect eyes and face with safety glasses and mask, and hands and arms with heavy work gloves when spraying abrasive materials. -
Page 10: Troubleshooting
AUSSIE SAFE BLASTING Aussie Pumps July 2019 TROUBLE SHOOTING GUIDE (for engine troubleshooting refer to engine manual) FAULT CAUSE REMEDY Pump sucking air Check water supply & possibility of air ingress. Valves sticking Check & clean or replace if necessary Unloader valve seat faulty Check &... -
Page 11: Personal Protective Equipment
Comfort, function & Safety … at an affordable price protective equipment is issued, instruction and training Aussie Pumps supply a full range of personal safety should be provided regarding its correct use and protection gear rated to 500 BAR (7,300 psi)… call for maintenance. -
Page 12: Operator's Hand Signals
AUSSIE SAFE BLASTING Aussie Pumps July 2019 OPERATOR’S HAND SIGNALS This section provides a set of hand signals for communication Medical Recommendation. when carrying out water jetting operations. If an accident occurs where pressurised water penetrates or appears to have penetrated the skin, medical assistance should be sought immediately. -
Page 13: Parts Identification & Replacement Parts
AUSSIE SAFE BLASTING Aussie Pumps July 2019 PARTS IDENTIFICATION & REPLACEMENT PARTS Raptor 16 Raptor 18 Position Part No Description Nozzles M0124006210 HP CERAMIC TIP NOZZLE (15°ANGLE, TIP SIZE 030) Gun/lance MPA30473000 500 BAR GUN LANCE ASSEMBLY Hose & Restraint... -
Page 14: Resetting The Safety Valve
AUSSIE SAFE BLASTING Aussie Pumps July 2019 Resetting the Safety Valve … ONLY TO BE CARRIED OUT BY QUALIFIED SERVICE TECHNICIAN UNLOADER SAFETY VALVE The safety valve prevents damage to the pump seals and With the pump running at the required pressure, valves caused by a pressure spike. -
Page 15: Pump Parts
AUSSIE SAFE BLASTING Aussie Pumps July 2019 PUMP PARTS RA1650, RA1850 PREMIUM SERIES s/code Description Pieces Order right part first time … BKIT210 Oil Seal & Sight Glass Kit specify the pump model number when ordering parts. BKIT209 Valve Kit... -
Page 16: Warnings
WARNINGS OVERSPEEDING HIGH PRESSURE SETTING Do not operate machine at over 3200 rpm (engine The high pressure pump is factory set to operate at speed). Over speeding can cause serious pump its rated pressure. DO NOT ADJUST. Tampering with damage. the pressure regulator will void warranty and can be DANGEROUS.
