ASUS Vivobook T3300KA
Repair Manual
IMPORTANT NOTICE:
This document is intended for ASUS Authorized Service Providers only. Performing any repairs without authorization will void
warranty. ASUS will not be liable for any damages that may occur while performing any procedures provided in this guide.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vivobook T3300KA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus Vivobook T3300KA

Summary of Contents for Asus Vivobook T3300KA

  • Page 1 Repair Manual IMPORTANT NOTICE: This document is intended for ASUS Authorized Service Providers only. Performing any repairs without authorization will void warranty. ASUS will not be liable for any damages that may occur while performing any procedures provided in this guide.
  • Page 3 Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
  • Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
  • Page 5 ASUS Vivobook T3300KA Overview Front View Rear View On selected models Detachable keyboard ❶ Array microphones ❶ Latch hooks ❷ Camera ❷ Docking connector ❸ Touch screen panel ❸ Keyboard ❹ Touchpad Top View Bottom View Using the cover stand ❶...
  • Page 6 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
  • Page 7 Components Top View KEYBOARD MODULE FP POWER BUTTON LCD COVER WIFI ANTENNA TP FFC LCD MODULE CAMERA 13M FPC BATTERY CABLE SPEAKER MODULE IO FFC IO BOARD CAMERA 5M FPC MAIN BOARD BATTERY POGO FFC THM BOT ASSY EDP CABLE FP HOLDER THM SSD PAD Back...
  • Page 8 Components Bottom View KEYBOARD MODULE LCD COVER MODULE THM BOT ASSY LCD MODULE BATTERY MAIN BOARD IO BOARD THM BOT ASSY Back...
  • Page 9 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Pad Plastic Tweezers Use a pair of tweezers to remove/insert/tidy cables. G500 Thermal Grease Thickness Gauge Thickness compass specification 0.05mm-1.5mm.

  • Page 10: Keyboard(Optional)

    KEYBOARD(OPTIONAL) Disassembly Notice Please be sure to pull out adapter and shut down the system. Step 1 : Remove the Keyboard. Assembly Notice About keyboard module , Please notice the two points bellow. 1.The keyboard module needn’t to disassemble. 2.If the keyboard module is damaged Pull and remove please replace a new one.
  • Page 11 LCD COVER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Use LCD Screen Opening Plier to enlarge the gap. Enlarge the gap Step 2 : Use Plastic Blade to separate the A Cover and Panel. Step 3 : Disconnect the Battery Cable.
  • Page 12 LCD COVER AND LCD MODULE ASSEMBLY NOTICE Assembly Notice To avoid damaging the panel when you assemble the LCD COVER and LCD MODULE. Please follow below steps to assemble it. Please follow below numbers to press the LCD MODULE SIDE. LCD COVER SIDE LCD MODULE SIDE...
  • Page 13 POGO FFC and FP POWER BUTTON Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screw *2pcs and then remove the FP HOLDER and FP POWER BUTTON. Step 2 : Release the POGO FFC GASKET. Assembly Notice Step 3 : Remove screw *2pcs and then remove the POGO FFC.
  • Page 14 IO BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the IO FFC connector. Screws Spec Torque (kgf-cm) Step 2 : Remove screw *2 pcs. Step 3 : Remove IO BOARD. 2.0 ±...
  • Page 15 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Tear off the THM SSD PAD. Step 2 : Remove the screw *1pc. Assembly Notice Step 3 : Remove the SSD . Please make sure to paste THM SSD PAD before Screws Spec Torque (kgf-cm)
  • Page 16 SPEAKER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect and remove the TP FFC (yellow mark). Step 2 : Disconnect and remove the EDP Cable (green mark). Step 3 : Disconnect the SPEAKER connector (red mark) and remove screw *4 pcs. Screws Spec Torque (kgf-cm)

  • Page 17: Thermal Module

    THERMAL MODULE (with MAIN BOARD) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect CMOS CABLE (yellow mark) connector. Screws Spec Torque (kgf-cm) Step 2 : Disconnect WIFI Antenna (green mark) connector. SCREW M2*2L (4.5,0.6) (K) 2.0 ±...
  • Page 18 THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Please follow the screw numbers to remove screw *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the THERMAL MODULE from MB. SCREW M2*2L (4.5,0.6) (K) 2.0±0.2 Recommend that the force point is at green block, and pull up thermal module to take...

  • Page 19: Main Board

    MAIN BOARD Mainboard connector placement CAMERA 13M FPC CAMERA 5M FPC SPEAKER ANTENNA POGO FFC TP FFC BATTERY EDP CABLE Back...
  • Page 20 MAIN BOARD Materials on mainboard MB RF ABSORBER DIMM CONDUCTIVE TAPE MIC RUBBER CPU KAPTON Back...
  • Page 21 CAMERA and ANTENNA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Release the tapes and remove the Antenna. Assembly Notice Step 2 : Release the tapes and remove the CMOS CAMERA MODULEs. For Antenna assembly, please follow the mark below to tidy cable.
  • Page 22 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Pull out the BATT ADHESIVE *3pcs. Assembly Notice Step 2 : Remove the Battery. Step 3 : Remove the Battery Cable. 1. Please pull the adhesive up about 30 degree slowly, and don't pull out the tape in vertical direction! 2.

  • Page 23: Lcd Module

    LCD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. The below parts have been as the LCD MODULE. Please book the LCD MODULE if one of parts is damaged. Back...
