SUPPER LARGE CALIBER
LEAKAGE CLAMP METER
USER'S MANUAL
Precaution For Use
Thank you for purchasing our 7100 series Supper Large Caliber Leakage Current
Clamp Meter, In order to better for use of the product, please be certain:
-- Read this user manual carefully.
-- Comply with the operating cautions in this manual.
Under any circumstance, shall pay special attention on safety in using this meter. Pay
attention to the text labeled on the panel and backplane of the meter
Keep the clamp clean and maintain regularly.
Do not place and store the meter in high temperature and humidity or dewy places and
under direct sunlight for a long time.
Battery voltage is low, please replace the battery in time. Replace the battery, please
pay attention to the battery polarity
If you not use the meter for a long time, please take out batteries.
Testing with this clamp meter, should try to keep the tested conductor in the center of
the clamp.
Use, disassembly and maintenance of this leakage current meter shall hand by
authorized personnel.
Due to the reason of this instrument, if it is dangerous to continue using, should
stopped and sealed immediately ,and handled by an authorized institution.
The meter manual with the danger mark "
operate safely
The meter manual with the extremely dangerous mark "
instructions to operate safely.
", users must follow instructions to
", users must in strict follow
