Transformer Protection Relay
Instruction Manual
ADR233B
Software Version: V5.xx
Hardware Version: V1.xx
ADR233B
Doc ID
: ADR233B/IM/01
Ref ID
: ADR233B/IM/TP
Rev No. : 05
Page No. : 1 of 479

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADR233B and is the answer not in the manual?

Questions and answers

Related Manuals for Ashida ADR233B

Summary of Contents for Ashida ADR233B

  • Page 1 ADR233B ADR233B Transformer Protection Relay Instruction Manual Software Version: V5.xx Hardware Version: V1.xx Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/TP Rev No. : 05 Page No. : 1 of 479...
  • Page 2 ADR233B Preface The ADR233B Relay Instruction Manual describes common aspects of Transformer protection application and use of product. It includes the necessary information to safety, install, set, test, and operate the relay functionality. The instruction manual can be used by power engineers and other experienced protective relaying applications.

  • Page 3: Safety And General Information

    • Are able to safely perform switching operation in accordance with accepted safety and to isolate ground and label it. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SGI Rev No. : 05 Page No. : 3 of 479...

  • Page 4: Symbols And External Labels On The Equipment

    However, the manual cannot cover all conceivable circumstances or include detailed information on all topics. In the event of doubts or specific problems, do not take any action without proper authorization. Contact the appropriate person from Ashida Technical / After Sales Service department and request the necessary information.

  • Page 5: Equipment Use

    Equipment Use If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SGI Rev No. : 05 Page No. : 5 of 479...
  • Page 6 Where internal batteries are fitted they should be replaced with the recommended type and be installed with the correct polarity to avoid possible damage to the equipment, buildings and persons. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SGI Rev No. : 05...

  • Page 7: Decommissioning And Disposal

    Any equipment containing batteries should have them removed before disposal, taking precautions to avoid short circuits. Particular regulations within the country of operation, may apply to the disposal of batteries. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SGI Rev No. : 05...

  • Page 8: Technical Specifications For Safety

    Pollution Degree 2 Compliance is demonstrated by reference to safety standards. Altitude Operation up to 2000m IEC 60255-27:2005 EN 60255-27: 2005 CE MARKING Directives: Compliance demonstrated by reference to safety standards Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SGI Rev No. : 05 Page No. : 8 of 479...
  • Page 9 Page Intentionally Left Blank...
  • Page 10 Insulation and dielectric strength testing 2.3.8 Cables and Connectors 2.3.9 Power Supply Connections 2.3.10 Earth Connection Dimensions and Electrical Connection 2.4.1 Mechanical Details – Basic Model Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 10 of 479...
  • Page 11 3.2.2 Microsoft .Net Framework 3.5.1 3.2.3 Installing ASHIDA Relay-Talk System 3.2.4 Uninstalling and Repairing ASHIDA Relay-Talk System Procedure 3.3.1 ASHIDA Relay Talk System Version2 (RTV2 S/W) 3.3.2 Features in RTV2 Software 3.3.3 Standard Toolbar buttons 3.3.4 Download Device Template Substation...
  • Page 12 3.11.1 To read the History Faults from Device 3.11.2 To view the History Faults file 3.12 Alias 3.13 Control 3.14 Disturbance Record Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 12 of 479...

  • Page 13: Section 4 : Protection Function & Logic Functions

    GOOSE subscriber functionality can be globally enabled or disabled Section 4 : PROTECTION FUNCTION & LOGIC FUNCTIONS Sr. No. Description Page No. Protection function & Logic Functions Overview Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 13 of 479...
  • Page 14 4.16 Circuit Breaker Failure detection Function (W1/W2) 4.16.1 CBF Operating Logic (CB FAIL) 4.17 Thermal Overload Protection Function 4.18 Programmable Logic control Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 14 of 479...
  • Page 15 6.8.1 Equipment Data 6.8.2 Ph Differential 6.8.3 6.8.4 Phase OC 6.8.5 Ground OC 6.8.6 Residual OC 6.8.7 Sequence OC 6.8.8 Under Voltage Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 15 of 479...

  • Page 16: Section 7 : Communications

    Page No. User Guide Overview FRONT PANEL AND CONTROL User interface 8.2.1 LCD Display 8.2.2 Touch Keys 8.2.3 LEDS 8.2.4 Communication ports Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 16 of 479...
  • Page 17 To View – Status 8.4.6.3 Fault Record 8.4.6.3.1 To View – Fault Record 8.4.6.4 Error Log 8.4.6.4.1 To View – Error Lof Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 17 of 479...
  • Page 18 W1 Residual OC (If Disabled) 8.4.11.7.2 W1 Residual OC (If IEC Curve is selected) 8.4.11.7.3 Residual OC (If IEEE / US Curve is selected) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 18 of 479...
  • Page 19 Flow Chart Overview Main Menu EDIT and SAVE settings Measurement 9.3.1 To View – Measurement 1 9.3.2 To View – Measurement 2 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 19 of 479...
  • Page 20 System Config 9.7.1 CT/VT RATIO –System Config Protection Clear Records Output & LED Test 9.11 Group 1 9.11.1 Equipment Data 9.11.2 Ph Differential Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 20 of 479...
  • Page 21 Over Voltage (59) (If Disabled) 9.11.9.2 Over Voltage (59) (If Enabled) 9.11.10 V/Hz Protection 9.11.10.1 V/Hz Protection (If Disabled) 9.11.10.2 V/Hz Protection (If Enabled) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 21 of 479...
  • Page 22 Through Fault Stability Check 11.4.3 Pick up and Trip Test 11.5 Testing of Binary Input 11.6 Testing of Binary Output 11.7 LED Test Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/ToC Rev No. : 05 Page No. : 22 of 479...
  • Page 23 Page Intentionally Left Blank...

  • Page 24: Introduction And Specifications

    ADR233B Section 1 Introduction and Specifications Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 24 of 479...
  • Page 25 ADR233B Contents INTRODUCTION AND SPECIFICATIONS Overview Features TECHNICAL SPECIFICATIONS Typical Tests Information Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 25 of 479...
  • Page 26 INTRODUCTION AND SPECIFICATIONS Overview ADR233B ADITYA series relay has been Designed and produced by ASHIDA. It is Economical and reliable Multifunction Transformer Protection Relay. Its construction is simple and compact. It provides integrated protection, Control and Monitoring functions for AC Transformer.
  • Page 27 Settings upload / download. • Online Measurement. • Disturbance analysis. • Event analysis/ Fault Records. • Relay Assistance for Relay testing at site. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 27 of 479...

  • Page 28: Transformer Protection

    ADR233B Ordering Information 1.3.1 Basic Version Ordering Information ADR233B (Basic Version) Model 233B Example 233B TRANSFORMER PROTECTION Sub Type Basic Version Variant Standard Language English Protocol IEC 103 MODBUS RTU IEC 61850 MODBUS TCP IEC104 CT / PT & RTD...
  • Page 29 DUAL 10/100 Base-T Ethernet RJ45 Rear Port DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-422 Rear Port DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port 1.3.2 Enhance Version: Ordering Information ADR233B (Enhanced Version) Model 233B Example 233B...
  • Page 30 DUAL FO Ethernet Rear Port & RS-485 Rear Port + IRIGB Port Single FO Ethernet Rear Port & Single 10/100 Base-T RJ45 + RS-485 Rear Port + IRIGB Port 1.3.3 Modular Version: Ordering Information ADR233B (Modular Version) Model 233B Example...
  • Page 31 Single FO Ethernet Rear Port & RS-485 Rear Port + IRIGB Port DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port (with PRP / HSR) DUAL FO Ethernet Rear Port & RS-485 Rear Port (with PRP / HSR) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No.

  • Page 32: Technical Specifications

    32 DI & 32 DO (Available only in Cabinet Details “Modular Version M-19”) Applications ADR233B numerical multifunction relay is designed for Transformer protection, Backup protection, Machine protection, and shunt reactor protection applications. This Relay is designed with fast and selective tripping ensures the stability and availability of electrical power system.
  • Page 33 Up to 15% of highest dc supply, As per IEC 60255-26: 2013 Relay power up time < 2.5 Sec Opto Isolated Input: Opto Isolated input operating 24–230VDC 48–230VDC 110–230VDC 230 VDC Range Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 33 of 479...
  • Page 34 No. of Analogue Channel : 14 Channels (User assignable through RTV2) No. of Digital Channel : 32 Channels (User assignable through RTV2) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 34 of 479...

  • Page 35: Transformer Differential Protection

    Drop –off 0.95 x Setting ±5% For operating Time IDMT Characteristic As per class5 of 60255-151 cl.5.2** shape or 50ms whichever is greater Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 35 of 479...
  • Page 36 Setting ± 7.5% **** Note 4 Alarm Reset value 97% of thermal setting ± 5% Operating Time ± 7.50% of calculated time Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 36 of 479...
  • Page 37 3.4 Kg approximate Basic version 3.5 Kg approximate Enhanced version 6 Kg approximate Modular 14’’ version 8.2 Kg approximate Modular 19’’ version III. Pollution Degree Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 37 of 479...

  • Page 38: Typical Tests Information

    IEC61000-4-9, IEC60255-26 (ed3) VIII. Radiated Electromagnetic Field Disturbance IEC60255-22-3, IEC60255-26 (ed3) Test Conducted Disturbance Induced By Radio IEC60255-22-6, IEC60255-26 (ed3) Frequency Field Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 38 of 479...
  • Page 39 : IEC 60255-21-2 Shock Response Test : IEC 60255-21-2 Seismic Test : IEC 60255-21-3 NOTE: Detailed Type Test Reports are available on request Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&S Rev No. : 05 Page No. : 39 of 479...
  • Page 40 Page Intentionally Left Blank...
  • Page 41 ADR233B Section 2 Installation and Procedure Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 41 of 479...

  • Page 42: Table Of Contents

    2.4.14 Mechanical Dimensions (Modular 19’’ Model) 2.4.15 Back Terminal Details for (Modular 19’’ Model) 2.4.16 Electrical Connection diagrams for (Modular 19’’ Model) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 42 of 479...

  • Page 43: Instalation Procedure

    Before installation of ADR233B Relay, User must be familiar with relay configuration features and its options. For safe and effective installation, cable connections should be done carefully. This section contains drawings of typical AC and DC connections of the ADR233B Basic Enhanced and Modular version.

  • Page 44: Dismantling The Goods

    Installation Procedure 2.3.1 Safe Mounting of Modular version ADR233B supports rack mounting and can be mounted into panels using M6 X 15 screws. The fitting screws are supplied along with the relay. Procedure for mounting the device into panel: Loose the M6 X 15 screws from the relay, then insert the Relay in to the panel cut-out as show below.

  • Page 45: Safe Mounting Of Enhanced And Basic Version

    2.3.2 Safe Mounting of Enhanced and Basic version ADR233B E0 & B0 relay’s supports flush mounting and can be mounted into panels using fitting clamps with M5 X 10 screws. The fitting clamp and screws are supplied along with the relay.
  • Page 46 Caution: All screws of fitting clamps should be properly tightened. Always use M5x10 screws for fitting the clamps. The Relay after fastening to the Panel with M6 X 15 Screws is shown below. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05...

  • Page 47: Relay Connection And Diagram

    CT circuit rating and integrity of connection. Protective fuse rating. Integrity of the earthing connection. Voltage and current rating of external wiring, applicable as per application. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 47 of 479...

  • Page 48: Relay Operating Condition

    Caution: Before carrying out any work on the equipment, user should be familiar with the Safety Section and the ratings on the equipment’s rating label. Figure 7: Rear view-Terminal Connection of ADR233B-M0 (19”) version Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P...
  • Page 49 Inputs Auxiliary Binary Inputs / Ethernet Ports Supply Input Outputs Figure 8: Rear view-Terminal Connection of ADR233B-M0 (14”) version Figure 9: Rear view -Terminal Connection of ADR233B-E0 version Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05...
  • Page 50 Terminal Blocks CT / PT Connections The terminal blocks of ADR233B consists of up to 36 x M4 screw terminals in Modular version, 30 x M4 screw terminals in Enhance version and 24 x M5 screw terminals in Basic version. M4 terminal blocks are used for CT and PT connections The wires should be terminated with rings using 90°...
  • Page 51 Auxiliary Power Input / Output Connections The terminal block of ADR233B used for Auxiliary supply, Status input, relay output contacts is as shown below. The wires should be terminated with straight pin type lugs, with no more one lug per terminal.

  • Page 52: Power Supply Connections

    The supply range is also mentioned on the Terminal sticker and before energising, care should be taken to confirm that the auxiliary supply being wired is within range. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No.

  • Page 53: Earth Connection

    This could be achieved in several ways, including placing a nickel-plated or insulating washer between the conductor and the product case, or using tinned ring terminals. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05...

  • Page 54: Dimensions And Electrical Connection

    ADR233B Dimensions and Electrical Connection 2.4.1 Mechanical Details – Basic Model Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 54 of 479...

  • Page 55: Back Terminal Details - Basic Model (Non Draw Out)

    ADR233B 2.4.2 Back Terminal Details – Basic Model (Non Draw out) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 55 of 479...

  • Page 56: Electrical Connection Details - Basic Model (Non Draw Out)

    ADR233B 2.4.3 Electrical Connection Details – Basic Model (Non Draw out) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 56 of 479...

  • Page 57: Back Terminal Details - Basic Model (Plug-In)

    ADR233B 2.4.4 Back Terminal Details – Basic Model (Plug-in) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 57 of 479...

  • Page 58: Electrical Connection Details - Basic Model (Plug-In)

    ADR233B 2.4.5 Electrical Connection Details – Basic Model (Plug-in) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 58 of 479...

  • Page 59: Mechanical Details - Enhanced Model

    ADR233B 2.4.6 Mechanical Details – Enhanced Model Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 59 of 479...

  • Page 60: Back Terminal Details - Enhanced Model- Plug-In (16Do&10Di)

    ADR233B 2.4.7 Back Terminal Details – Enhanced Model- Plug-in (16DO&10DI) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 60 of 479...

  • Page 61: Electrical Connection Details - Enhanced Model- Plug-In (16Do&10Di)

    ADR233B 2.4.8 Electrical Connection Details – Enhanced Model- Plug-in (16DO&10DI) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 61 of 479...

  • Page 62: Back Terminal Details - Enhanced Model- Plug-In (11Do&10Di)

    ADR233B 2.4.9 Back Terminal Details – Enhanced Model- Plug-in (11DO&10DI) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 62 of 479...

  • Page 63: Electrical Connection Details - Enhanced Model- Plug-In (11Do&10Di)

    ADR233B 2.4.10 Electrical Connection Details – Enhanced Model- Plug-in (11DO&10DI) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 63 of 479...

  • Page 64: Mechanical Dimensions (Modular 14'' Model)

    ADR233B 2.4.11 Mechanical Dimensions (Modular 14’’ Model) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 64 of 479...

  • Page 65: Back Terminal Details For (Modular 14'' Model)

    ADR233B 2.4.12 Back Terminal Details for (Modular 14’’ Model) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 65 of 479...

  • Page 66: Electrical Connection Diagrams For (Modular 14'' Model)

    ADR233B 2.4.13 Electrical Connection diagrams for (Modular 14’’ Model) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 66 of 479...

  • Page 67: Mechanical Dimensions (Modular 19'' Model)

    ADR233B 2.4.14 Mechanical Dimensions (Modular 19’’ Model) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 67 of 479...

  • Page 68: Back Terminal Details For (Modular 19'' Model)

    ADR233B 2.4.15 Back Terminal Details for (Modular 19’’ Model) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 68 of 479...

  • Page 69: Electrical Connection Diagrams For (Modular 19'' Model)

    ADR233B 2.4.16 Electrical Connection diagrams for (Modular 19’’ Model) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/I&P Rev No. : 05 Page No. : 69 of 479...
  • Page 70 Page Intentionally Left Blank...
  • Page 71 ADR233B Section 3 RTV2 Software Information Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 71 of 479...
  • Page 72 3.2.2 Microsoft .Net Framework 3.5.1 3.2.3 Installing ASHIDA Relay-Talk System 3.2.4 Uninstalling and Repairing ASHIDA Relay-Talk System Procedure 3.3.1 ASHIDA Relay Talk System Version2 (RTV2 S/W) 3.3.2 Features in RTV2 Software 3.3.3 Standard Toolbar buttons 3.3.4 Download Device Template Substation 3.4.1...
  • Page 73 3.18.16 Each GCB can be enabled or disabled. 3.18.17 GOOSE subscriber view 3.18.18 GOOSE subscriber functionality can be globally enabled or disabled Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 73 of 479...

  • Page 74: Rtv2 Software Information Overview

    Customizes ADR233B Settings and configure RTV2 Software communication, input and output for specific applications This section describes how to get started with the ADR233B and RTV2 software. It particularly explains about the software setup and working procedure. 3.1.1 RTV2 Software Features...

  • Page 75: Installation And Setup

    ADR233B Installation and Setup 3.2.1 System Requirement ASHIDA Relay Talk Version2 requires following hardware/software platform to run the application. Sr. No. Requirement Description Operating System Windows XP/7/8/8.1/10 (32-bit or 64-bit) Processors 1GHz or above 512MB or above Dot net Framework Microsoft .Net Framework 3/3.51...

  • Page 76: Installing Ashida Relay-Talk System

    Installing ASHIDA Relay-Talk System The ASHIDA Relay-Talk is delivered as a single installation file named ‘ASHIDA Relay-Talk .exe’. To install ASHIDA Relay-Talk System simply opens the file and follows the directions. To install, double click on “ASHIDA Relay-Talk SystemSetup.exe” setup file. Following window will appear.
  • Page 77 In addition to installing the required files on your system the installation application performs the following tasks. • Creates entries in the Start->Programs menu to access the features of the ASHIDA Relay- Talk System Figure 5: Relay Talk System Version2 in programs menu...

  • Page 78: Uninstalling And Repairing Ashida Relay-Talk System

    Uninstalling and Repairing ASHIDA Relay-Talk System Step1: To Uninstall the software go to windows Control Panel −>‘Add/Remove Programs’. Figure 6: Relay Talk System Version2 in Programs Step2: Right click on ASHIDA Relay-Talk System Figure 7: Confirmation to un-install Relay Talk System Version2 Doc ID...

  • Page 79: Procedure

    Procedure 3.3.1 ASHIDA Relay Talk System Version2 (RTV2 S/W) This section will guide the user on ASHIDA Relay Talk System Version2, establishing the configuration and interface with the device. To start Relay Talk System Version2: • Click Start−>Programs −> ASHIDA−> Relay Talk−> ASHIDA Relay-Talk System V2 •...

  • Page 80: Features In Rtv2 Software

    Figure 8: Main window of Relay Talk System Version2 3.3.2 Features in RTV2 Software • Connection: Edit connection preference settings to interface with ASHIDA Relay Series. • Settings: This function is to edit settings in online/offline mode. Also to read and write Settings from/to device.

  • Page 81: Standard Toolbar Buttons

    Download Device Template To Download Device template, click on “Download Device Template”. Following window will appear. Figure 9: Download Device Template screen Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 81 of 479...

  • Page 82: Adding Substation To Rt System

    To add new substations right click on “RT System”. Following context menu will appear. Figure 11: Add new substation Now click on “New Substation” then the following window will appear. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...

  • Page 83: Import Substation

    Figure 13: Import substation Now click on “Import Substation”. In the “Import substation” dialogue select a system archive to import and click Open. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 83 of 479...

  • Page 84: Export Substation

    Now click on “Export Substation” following window will appear. Figure 15: Export substation dialogue In the “Export substation” dialogue, select a destination path and click Ok. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 84 of 479...

  • Page 85: Adding Bay To Substation

    Click on “New Bay” following window will appear. Figure 17: Add new bay name Type a bay name and click OK. A new bay will be added to RT System. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...

  • Page 86: Import Bay

    To export bay right click on Bay. Following context menu will appear. Figure 19: Export Bay Now click on “Export Bay” following window will appear. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 86 of 479...

  • Page 87: Adding New Device

    Figure 20: Export Bay Dialogue In the “Export Bay” dialogue, select a destination path and click Ok. Device This section is generalized and applicable for all ASHIDA Relay models. The User should choose relevant Device Template based on Relay Model. 3.6.1 Adding New Device To add a device right click on bay and select “New Device”...

  • Page 88: Import Device

    Figure 23: Import Device Now click on “Import Device”. In the “Import Device” dialogue select a system archive to Import and click open. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 88 of 479...

  • Page 89: Export Device

    Now click on “Export Device” following window will appear. Figure 25: Export Device dialogue In the “Export Device” dialogue, select a destination path and click Ok. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 89 of 479...

  • Page 90: Communication Setting

    3.7.2 Communicating with Device Once the communication settings are done, then the Device can communicate using ASHIDA Relay Talk System Version2. The Configurator internally uses a separate communication driver to communicate with the device. This communication driver communicates with the device using communication parameters (e.g.
  • Page 91 & is 'online’. Select the device and then click on Connect button. Figure 29: Connect to device After successful communication, device name will turn into green colour. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 91 of 479...

  • Page 92: To View Settings Files From Device

    Note: - Settings with gray colour lines are Read-Only Settings. To edit other settings double click on the same. Figure 31: Edit settings file Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 92 of 479...

  • Page 93: Downloading Settings From Device

    Type a setting file name and click Ok. It will download the device template. After successfully reading the settings file of the device double click on set file. Following window will appear. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...

  • Page 94: Restore Settings From Device

    To restore settings from device, right click on Settings mode. Following window will appear. Figure 35: Restore setting files Click “Restore Settings File” to restore the settings. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 94 of 479...

  • Page 95: Read Aprologic

    Select output, assign applicable inputs. Edit T-Operating, T-Reset and HR/SR. Figure 37: Edit T Operating, T Reset and HR/SR Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 95 of 479...

  • Page 96: View Aprologic Report

    View AProLogic Report To view AProLogic Report open “*.apl” file and click on Report Option. Figure 38: Save & Report Figure 39: AProLogic Report Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 96 of 479...

  • Page 97: Restore Aprologic From Device

    Click “Restore AProLogic File” to restore AProLogic. 3.10 Events The event records can be viewed directly on relay screen, or in ASHIDA Relay Talk System Version2. When any Events occurs Event file will automatically generate under Events node or Events can be read from relay using ‘Read Events’...

  • Page 98: Read Events

    To view events data, double click on Event file. Event list with time, date and parameters will be displayed on the screen. Following window will appear on screen. Figure 42: View Events Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...

  • Page 99: To Read The History Faults From Device

    Faults. Following window will appear on screen. History file will get added under the History Faults node. Figure 43: Read History faults Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 99 of 479...

  • Page 100: To View The History Faults File

    Double click on Alias node screen which will open in the main document window. Double click on record which needs to change. Following window will appear on screen. Figure 45: Alias screen Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...
  • Page 101 Select a device and go to Control node. Double click on Control node screen which will open in the main document window. Select Control and press Operate Control button. Figure 47: Operate Control Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...

  • Page 102: Disturbance Record

    (Like First In First out Logic). Disturbance record stores 12 samples per cycle. The same record can be shown in ASHIDA Relay Talk System Version2. The following window shows the recorded disturbance record.
  • Page 103 To view the disturbance record file double click on the file. It will open the file in DR Analysis and RELAY-DRV. Figure 50: View disturbance record in RELAY-DRV Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...
  • Page 104 “Measurements” columns on the relay screen or via ASHIDA Relay Talk System Version2. To view online measurements from the device double click on Measurement node.

  • Page 105: Maintenance Record

    Options under Tools. 3.18.1 System Folders Information In this screen user will find Application system paths those are as follows: • Application Folder Path Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 105 of 479...

  • Page 106: File Location Information

    In this screen user, will find General Setting of Device Timeout which are as follows: • Device connect Timeout (Sec) • Device Read Timeout (Sec) • Read DR Timeout (Sec) Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 106 of 479...

  • Page 107: Introduction

    Figure 56: General Settings Information 3.18.4 Introduction IEC 61850 Configurator is a software tool specifically designed to interface with ASHIDA relays. This section provides a brief overview of IEC 61850 Configurator is intended to get you up and running. 3.18.5...

  • Page 108: Program Should Be Started With Following Command Line Parameters

    • Import SCL - import SCL file containing definitions of GOOSE publishers of other devices to subscribe to • Exit - close application Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 108 of 479...

  • Page 109: Menu Commands

    • Write Configuration - writes configuration of GOOSE interfaces (for publisher and subscriber) to the device (to activate new configuration device should be restarted) Help menu groups functions related to on-line help Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...

  • Page 110: Standard Toolbar Buttons

    • SNTP Server address (used for time synchronization) These parameters are available only for preview and can be changed from device MMI or by another tool. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 110 of 479...

  • Page 111: Goose Publisher View

    • Ethernet Destination MAC address. • Application ID. • Configuration revision. • Goose ID. • List of published signals (contents of the published dataset). Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05 Page No. : 111 of 479...

  • Page 112: Each Gcb Can Be Enabled Or Disabled

    Each GCB can be enabled or disabled. Figure 59: Goose Publisher Note: Network output (NWOPGGIO10.Ind1.sTVal) signal is Goose Publisher which can be published to any other make device or to Ashida make IED’s 3.18.17 GOOSE subscriber view GOOSE Subscriber tab shows filtering parameters that will be used to receive and accept for processing (subscribe) GOOSE messages published by other devices.

  • Page 113: Goose Subscriber Functionality Can Be Globally Enabled Or Disabled

    Connect button. After that dialog window will popup allowing user to select published signal by reference. After accepting the selection AppID, Index and MAC Address for subscriber will be updated. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SI Rev No. : 05...
  • Page 114 Page Intentionally Left Blank...

  • Page 115: Protection Logic

    ADR233B Section 4 Protection Logic Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 115 of 479...
  • Page 116 4.16 Circuit Breaker Failure detection Function (W1/W2) 4.16.1 CBF Operating Logic (CB FAIL) 4.17 Thermal Overload Protection Function 4.18 Programmable Logic control Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 116 of 479...
  • Page 117 ADR233B PROTECTION FUNCTION & LOGIC FUNCTIONS Overview This section describes the ADR233B Transformer Management IED settings, including the protection elements and basic functions, control Input/output logic as well as the settings associated with the protection function. Application Data It describes the list of information that one will need to know about the protected equipment before calculating the relay settings.

  • Page 118: Application Data

    System phase rotation and nominal frequency • Type and location of resistance temperature devices (RTDs), if used • Expected fault current magnitudes for ground and three-phase faults Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 118 of 479...

  • Page 119: Global Settings

    After disconnect the dc supply to the binary input assigned to Active G2. Step 5: The Group2 setting will be changed to group1 setting. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 119 of 479...
  • Page 120 4.3.4 Port 1 Communication setting The Port 1 Communication settings of ADR233B IED are listed in the below table which is necessary for the communication between the IED and Local / SCADA Personal computer. Port 1 settings.

  • Page 121: Port R Communication Setting

    Disturbance Recorder. The ADR233B is provides two sampling mode for saving DR, first is RAW samples (DR of 1.5 sec) & second is 16 samples (DR of 3 sec), user can set as required.

  • Page 122: Trip Circuit Supervision Alarm (W1/W2)

    Figure 1: Trip Circuit Supervision Principle Diagram Timer CB Status Trigger Alarm Circuit Breaker Figure 2: Logic Diagram for Trip Circuit Supervision Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 122 of 479...

  • Page 123: Cb Open Supervision (W1/W2) And Cb Open Operation Alarm (W1/W2)

    & event is stored in Event Record. (Note that this time also include contact operating time of relay and time between CB main contact and auxiliary contact if any). Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05...

  • Page 124: Cb Control Operation (W1/W2)

    Thus, routine maintenance, such as oiling of mechanisms, may based upon the number of CB operations. The relay ADR233B monitor the circuit breaker operation maintain by two type of counters, one is TC “Breaker Trip counter”...

  • Page 125: System Config Settings

    SYSTEM CONFIG Settings CT/VT Ratio Setting SL. NO Setting Parameters Setting ranges W1 Ph CT Secondary 1A/5A W1 Ph CT Primary 10 – 5000A Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 125 of 479...

  • Page 126: Two Winding Phase Differential Protection

    CT Star point is for proper operation differential function. Two winding Phase Differential Protection Two winding Transformer Differential Protection (87T) functions of ADR233B uses the well- known current differential principle where current entering the protected equipment is compared with the current leaving the protected equipment. If there is no fault, the current entering the transformer will be equal to the current leaving the transformer multiplied by the inverse of the turn’s ratio.
  • Page 127 ADR233B ADR233B relay calculates the reference current “W1 Iref”, “W2 Iref” by using the setting parameters “MVA rating”, “W1 Nominal”, “W2 Nominal” from the “Equipment Data” setting menu. The reference current on W1 side is calculated by using formulae given below W1 Iref = W1 MVA / (√3* W1 Nominal)

  • Page 128: Phase Compensation

    Before the advent of numerical IEDs, this was handled by a configuration involving interposing CTs. The ADR233B provides this feature by filtering out the zero sequence components in software when the Y-connected windings grounded. In “Equipment Data” settings menu the “W1 Grounding” and “W2 Grounding” setting can be set as grounded or ungrounded.
  • Page 129 The ADR233B relay does the automatic phase compensation based on the reference of transformer vector group parameter, entered into the relay software. For example; the Transformer vector group DY1 can be set in ADR233B relay following way; “W1 Connection” = D-Delta (example) “Vector Group “= 1 (example)
  • Page 130 Idiff ≥ Slope2 * Ibias max + (Slope1 –Slope2) *Is>2 Where; Idiff and Ibias are calculated current from Winding1 current and Winding 2 current. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 130 of 479...
  • Page 131 The IHs>2 element resets when the differential current drops below 0.95* IHs>2. Harmonic Blocking Criteria: The ADR233B relay provides harmonic blocking or restrain based on the selection of Hrm Blk Criteria setting as Blocking/Restrain. Harmonic Restrain Selection:...
  • Page 132 (2*fn)/I(fn) exceeds a specific adjustable value (typical setting 20%) in at least one measuring system, Differential tripping is Blocked. ADR233B relay provides the “Cross Blocking” criteria/logic can be enabling or disabling / timer through the software in the relay. The relay provides phase segregated blocking logic if the cross blocking disabled.

  • Page 133: Restricted Earth Fault (64R) Protection

    (REF) is the protection mechanism used to protect individual transformer winding sets. The ADR233B relay is consisting of two different types of Restricted Earth Fault; Low Impedance REF (also known as Biased REF) and High Impedance REF. Each method compensates for the effect of through-fault errors in a different ways.
  • Page 134 The second slope provides stability under through fault conditions. Bias Characteristics for Low Impedance is shown in the following figure. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05...
  • Page 135 This ensures stability against external fault conditions and then the relay will operate only for faults occurring inside the protected zone. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05...

  • Page 136: Inrush Blocking

    High impedance schemes are used in a differential configuration, where one current transformer is completely saturated and the other CTs are healthy. In ADR233B relay, REF CT can be connected to either with the W1 winding or W2 winding high impedance REF.

  • Page 137: Non Directional Phase Over Current (50/51) Protection (W1/W2)

    (IDMT/DT). There are three independent stages for Ground over current Protections. The following diagram explains about the Ground over current protection function. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 137 of 479...

  • Page 138: Non Directional Residual Over Current (50N/51N) Protection (W1/W2)

    = 300A Figure 16: Residual over current from three phases (Derived Zero sequence current) ADR233B relay provides three independent stages of Residual over current protection function. The relay derives ground fault current internally through software from the three phase current.

  • Page 139: Sequence Over Current Protection (W1/W2)

    4.12 Sequence Over Current Protection (W1/W2) ADR233B provides three independent stages of phase sequence over current protection function. Each stage can be set as Positive sequence or Negative sequence over current function. The Positive & Negative sequence current is calculate from the three phase current is shown below Positive sequence current I1 = (IA+αIB+α...

  • Page 140: Idmt Characteristics

    4.13 IDMT Characteristics ADR233B relay provides inverse time over current characteristic for W1/ W2 phase over current, ground over current, Residual Over Current elements and sequence over current. Each stage is independently settable with inverse time or definite time characteristic. The following IDMT characteristics are available •...
  • Page 141 IEEE V Inverse IEEE 19.61 0.491 IEEE Inverse IEEE 28.2 0.1217 US Inverse IEEE 5.95 0.18 US ST Inverse IEEE 0.0239 0.02 0.0169 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 141 of 479...
  • Page 142 A : IEC S INVERSE, B : S INVERSE 1.3Sec, C : IEC V INVERSE, D : IEC E INVERSE, E: UK LT INVERSE Figure 19: IDMT Characteristic Graph for IEC Curves Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No.
  • Page 143 A : IEEE M INVERSE, B : IEEE V INVERSE, C : IEEE E INVERSE, D : US INVERSE, E: US ST INVERSE Figure 20: IDMT Characteristic Graph for IEEE/ANSI Curves Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05...

  • Page 144: Timer Hold Facility / Reset Characteristics

    Value of the programmed threshold (pick-up value) (also refer as Gs as IEC standard notation) α Factor (see table) RTMS Reset time multiplier (RTMS) setting between 0.025 and 1.2 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 144 of 479...
  • Page 145 Time Delay setting Operate level of the integrator Value of Internal Time delay counter (Intergrator) Reset Time Reset Time Figure 22: IDMT Reset Characteristic Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 145 of 479...
  • Page 146 10.0 ST. Inverse 10.0 MULTIPLE OF PICKUP SETTING TD = 1.00, RTMS = 1.00 Figure 23: IDMT RESET Characteristic for IEEE/ANSI Curves Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 146 of 479...

  • Page 147: Under/Over Voltage

    Electrical power system. ADR233B relay provides over and under voltage protections with definite time delay setting. Protection functions can be programmed for alarm signal or trip signal through programmable logic.

  • Page 148: V/Hz Protection (Over Excitation)

    Flux density above the rated value saturates the iron core which may result in power transformer overheating due to large iron losses. The ADR233B relay provides six independent stages of V/Hz protection function with definite time delay setting. The below logic diagram explains about the over excitation protection function, Over excitation protection processes the voltage to frequency ratio (V/f) in relation to their nominal values which this value is exceeds the set value V/Hz Level1 then after delay time set in the “tV/Hz Level1”...

  • Page 149: Cbf Operating Logic (Cb Fail)

    If I in all phases is less than 50BF_I & Protection Reset 50BF Reset & Figure 27: CBF Operation and Reset Logic Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 149 of 479...

  • Page 150: Thermal Overload Protection Function

    4.17 Thermal Overload Protection Function ADR233B is provided with the thermal overload function which can be selected either Winding1 side or winding 2 sides by using the following settings “THOL Enable” can be set as W1 / W2 / Disabled.

  • Page 151: Thermal Overload

    C : THERMAL STATE = 50%, D: THERMAL STATE = 70%, E : THERMAL STATE = 90% Figure 28: Thermal Overload Characteristics Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05 Page No. : 151 of 479...

  • Page 152: Programmable Logic Control

    4.18 Programmable Logic control The Basic version of ADR233B relay provides total 8 nos. of target & programmable LEDs with dual colours indication and 12 Digital inputs and 11 digital outputs. The Enhanced version of ADR233B relay provides total 16 nos. of target & programmable LEDs with dual colours indication and 10 Digital inputs and 11/16 digital outputs.
  • Page 153 Then the result of AND equation will be active. This output can be used to block all protection functions through an external wiring. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/PS Rev No. : 05...
  • Page 154 Page Intentionally Left Blank...

  • Page 155: Metering Section

    ADR233B Section 5 Metering Section Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/MS Rev No. : 05 Page No. : 155 of 479...
  • Page 156 ADR233B Contents MEASUREMENT SHEET Measurement 1 Measurement 2 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/MS Rev No. : 05 Page No. : 156 of 479...
  • Page 157 0.000 Secondary residual current of Winding 1 W1 – Ia RMS = 0.000 Secondary RMS current in phase A of winding 1 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/MS Rev No. : 05 Page No. : 157 of 479...
  • Page 158 Secondary RMS current in phase A of winding 2 W2 – Ib RMS = 0.000 Secondary RMS current in phase B of winding 2 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/MS Rev No. : 05 Page No. : 158 of 479...
  • Page 159 0.00 Secondary Current in REF CT Iref Diff = 0.00 Difference Current of REF Iref Bias = 0.00 Bias Current of REF Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/MS Rev No. : 05 Page No. : 159 of 479...
  • Page 160 Page Intentionally Left Blank...

  • Page 161: Setting Sheet

    ADR233B Section 6 Setting Sheet Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 161 of 479...
  • Page 162 Sequence OC 6.8.8 Under Voltage 6.8.9 Over Voltage 6.8.10 V/Hz Protection 6.8.11 Breaker Failure (50BF) 6.8.12 Thermal Overload 6.8.13 Through Fault ACTIVE GROUP Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 162 of 479...
  • Page 163 PORT F / PORT 1 / PORT R / IRIG-B This setting is used to set the timesync Master Description ASHIDA ADR233B M0 Read only This is read only setting, used to display the type of the relay. Model Number...
  • Page 164 Disabled Disabled / Enabled / Time Enabled This setting is to enable / disable the setting group 3. If the setting group 3 is enabled from the Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 164 of 479...
  • Page 165 This setting is to Enable the communication Protocol Ethernet Mode Dual Dual / fixed This setting is used to set the Ethernet Mode as Dual or Fixed. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 165 of 479...

  • Page 166: Disturbance

    This setting is to set Pre-fault duration of disturbance recorder. Sampling 16 Samples 16 Samples / RAW Samples The setting is to select samples of Disturbance Recorder. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 166 of 479...
  • Page 167 00 to 99 Years in step of 1. Year needed when relay is not connected to SCADA system Note: * Relay shows current time, set into the relay Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05...

  • Page 168: Cb Control (For W1 & W2)

    Display the Records of fault i.e. parameter value, flag of fault & date and time of Fault Error Log Display of error generated by relay if any, in case of failure of hardware Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 168 of 479...

  • Page 169: System Config

    Disabled / Enabled This setting is to enable (activate) or disable (turn off) the Equipment Data function. Ph Differential Enabled Disabled / Enabled Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 169 of 479...

  • Page 170: Clear Records Settings

    CLEAR RECORDS settings: Sr. No Parameter Defaults setting Setting / Ranges Password 0000 0000 to zzzz/ZZZZ This setting is to enter the set password Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 170 of 479...

  • Page 171: Output & Led Test

    This setting is used to Test contact operation of relay output. Test LEDs No Operation No Operation / Apply Test This setting is used to Test the 16 no’s programmable LED’s. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 171 of 479...

  • Page 172: Group 1 Settings

    The reference currents for W1 / W2 winding of the protected object are calculated by the relay 6.8.2 Ph Differential Sr. No Parameter Defaults setting Settings / Ranges Ph Differential Enabled Disabled / Enabled Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 172 of 479...
  • Page 173 Differential protection will be blocked as selected. This setting visible only when IH5 Diff Block is enabled t 5th Hrm 0.00 S Read Only Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 173 of 479...

  • Page 174: Ref

    Inverse 1.3S / IEC V Inverse / IEC E Inverse / UK LT Inverse / IEEE M Inverse / IEEE V Inverse / IEEE E Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 174 of 479...

  • Page 175: Ground Oc

    Winding 2 are similar to Phase OC IP>1 settings. 6.8.5 Ground OC Sr. No Parameter Defaults setting Settings / Ranges IE>1 Enable Disabled Disable/Enabled Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 175 of 479...
  • Page 176 I> UB2H setting. The reset levels are 95% of these thresholds Note : Ground OC setting for IE>2 and IE>3 are similar to Ground OC IE>1 settings. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05...

  • Page 177: Residual Oc

    The 2nd harmonic blocking is applied only when the fundamental current is above 2nd Harm Thresh and below I> UB2H setting. The reset levels are 95% of these thresholds Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05...

  • Page 178: Sequence Oc

    Seq.I>1 UB2H 4 A *In 4 to 32*In in step of 0.01*In Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 178 of 479...

  • Page 179: Under Voltage

    100 to 200% in step of 1% The setting is to set operating rane of V/Hz protection. tV/Hz Level1 100.0s 0.1 to 400s in step of 0.1s Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 179 of 479...
  • Page 180 Ith>Alarm 50 to 100% in step of 1% This setting shows the thermal state threshold corresponding to a percentage of the trip threshold at Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 180 of 479...

  • Page 181: Through Fault

    Sr. No Parameter Defaults setting Setting / Ranges Active Group Group1 Read only This setting display the active group G1 is default setting. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/SS Rev No. : 05 Page No. : 181 of 479...
  • Page 182 Page Intentionally Left Blank...
  • Page 183 ADR233B Section 7 Communication Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 183 of 479...
  • Page 184 Spontaneous Events 7.3.5 General Interrogation (GI) 7.3.6 Cyclic Measurements 7.3.7 Commands 7.3.8 Disturbance Records 7.3.9 Protocol Mapping: IEC 61850 7.4.1 Protocol map Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 184 of 479...
  • Page 185 NOTE: This is a common document for Numerical Transformer Protection Relay Type ADR233B. Some of the features mentioned may not be available in different sub-types/models of ADR233B...

  • Page 186: Ethernet Network

    Port 1 is the Ethernet port. Ethernet port can be used for interfacing of relay with Ethernet network. ADR233B Ethernet port options include single or dual copper Ethernet port configuration. The Port 1 can be assigned as a “fixed”, “failover”, “switch” mode options. Dual port option can be assigned for redundancy purpose or it can also be assigned as an unmanaged switch”.
  • Page 187 Port R is generally used for SCADA communication purpose. IEC103 protocol and MODBUS RTU protocol shall be worked via Port R. IRIG-B Port (Optional): The ADR233B has equipped with IRIG-B port. The facility is provided to accept demodulated time coded input for time synchronization with external source. Doc ID...
  • Page 188 It contains time-of-year and year information in a BCD format, and (optionally) seconds- of-day in SBS. IRIG-B Signals IRIG-B is typically distributed as a DC level shift (DCLS), pulse- width coded signal (“unmodulated IRIG-B”) in ADR series of Ashida. Doc ID...
  • Page 189 Modbus web site (www.modbus.org). Overview: Physical Connection and Link Layer For connecting on MODBUS use: Rear serial port 1 - for permanent SCADA connection via Ethernet (RJ45/FO) port. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05...
  • Page 190 This mode of communication is defined by the MODBUS standard. The IED address and baud rate can be selected using the front panel menu or ASHIDA Relay Talk RTV2 Software. When using a serial interface, the data format is: 1 starts bit, 8 data bits, 1 stop bit and 1 parity bit.
  • Page 191 1 bit 15010 W1_IP>2 P 1 bit 15011 W1_IP>2 T 1 bit 15012 W1_IP>3 P 1 bit 15013 W1_IP>3 T 1 bit 15014 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 191 of 479...
  • Page 192 1 bit 15092 W2_50BF P 1 bit 15101 W2_50BF T 1 bit 15102 REF> P 1 bit 15103 REF> T 1 bit 15104 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 192 of 479...
  • Page 193 15601 H In2 ** 1 bit 15602 H In3** 1 bit 15603 H In4** 1 bit 15604 H In5** 1 bit 15605 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 193 of 479...
  • Page 194 1 bit 15711 L12 G 1 bit 15712 L13 G 1 bit 15713 L14 G 1 bit 15714 L15 G 1 bit 15715 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 194 of 479...
  • Page 195 1 bit 16005 n/w O-6 1 bit 16006 n/w O-7 1 bit 16007 n/w O-8 1 bit 16008 n/w O-9 1 bit 16009 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 195 of 479...
  • Page 196 M Out7* 1 bit 16431 M Out8* 1 bit 16432 EQN-1 1 bit 16301 EQN-2 1 bit 16302 EQN-3 1 bit 16303 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 196 of 479...
  • Page 197 1 bit 16225 VIO-26 1 bit 16226 VIO-27 1 bit 16227 VIO-28 1 bit 16228 VIO-29 1 bit 16229 VIO-30 1 bit 16230 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 197 of 479...
  • Page 198 16 bit 03050 L Out8* 16 bit 03051 M Out1* 16 bit 03052 M Out2* 16 bit 03053 M Out3* 16 bit 03054 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 198 of 479...
  • Page 199 16 bit 03156 VIO-17 16 bit 03157 VIO-18 16 bit 03158 VIO-19 16 bit 03159 VIO-20 16 bit 03160 VIO-21 16 bit 03161 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 199 of 479...
  • Page 200 33485-33486 IB-Bias 32 bit Float 33487-33488 IC-Bias 32 bit Float 33489-33490 V MAG 32 bit Float 33689-33690 FREQ 32 bit Float 33743-33744 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 200 of 479...

  • Page 201: Physical Connection And Link Layer

    This section describes how the IEC 60870-5-103 standard is applied to the ADR233B Relay. It is not a description of the standard itself. The level at which this section is written assumes that the reader is already familiar with the IEC 60870-5-103 standard.

  • Page 202: Time Synchronisation

    The GI request can be used to read the status of the device, the function numbers, and information numbers that will be returned during the GI cycle. These are shown in the IEC 60870-5-103 profile in the Menu Database. Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No.

  • Page 203: Cyclic Measurements

    Sr. No. Description Semantics of INFORMATION NUMBER : Status Indications in monitor direction Trip LED status 1,7,9,11,12,20,21 PROT Active 9,11 Relay Error 9,11 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 203 of 479...
  • Page 204 1,7,9 N In2* 1,7,9 N In3* 1,7,9 N In4* 1,7,9 N In5* 1,7,9 N In6* 1,7,9 N In7* 1,7,9 N In8* 1,7,9 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 204 of 479...
  • Page 205 L6-R 1,7,9 L7-R 1,7,9 L8-R 1,7,9 L9-R 1,7,9 L10-R 1,7,9 L11-R 1,7,9 L12-R 1,7,9 L13-R 1,7,9 L14-R 1,7,9 L15-R 1,7,9 L16-R 1,7,9 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 205 of 479...
  • Page 206 1,7,9,11,12,20,21 M Out7* 1,7,9,11,12,20,21 M Out8* VIO-1 1,7,9 VIO-2 1,7,9 VIO-3 1,7,9 VIO-4 1,7,9 VIO-5 1,7,9 VIO-6 1,7,9 VIO-7 1,7,9 VIO-8 1,7,9 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 206 of 479...
  • Page 207 1,7,9 n/w O-10 1,7,9 n/w O-11 1,7,9 n/w O-12 1,7,9 n/w O-13 1,7,9 n/w O-14 1,7,9 n/w O-15 1,7,9 n/w O-16 1,7,9 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 207 of 479...
  • Page 208 1,7,9 EQN-12 1,7,9 EQN-13 1,7,9 EQN-14 1,7,9 EQN-15 1,7,9 EQN-16 1,7,9 NOTE: *Available only in M19” model ** Available in E0 model Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 208 of 479...
  • Page 209 1,7,9 W23I0>2 P 1,7,9 W23I0>3 P 1,7,9 Th Alarm 1,7,9 W1 50BF P 1,7,9 W1I>BbyBF 1,7,9 W2 50BF P 1,7,9 W2I>BbyBF 1,7,9 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 209 of 479...
  • Page 210 W2 IP>3 T W1 Seq>1 T W1 Seq>2 T W1 Seq>3 T W2 Seq>1 T W2 Seq>2 T W2 Seq>3 T IE>1 T Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 210 of 479...
  • Page 211 W1-Iab MAG W1-Ibc MAG W1-Ica MAG W1-I1 P MAG W1-I2 P MAG W1-I1 MAG W1-I2 MAG W1-I0 MAG W1-3I0 MAG W1-Ia RMS Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 211 of 479...
  • Page 212 W2_Ia RMS, W2_Ib RMS, W2_Ic RMS, Iref, Iref Diff, Iref Bias, IA diff, IA diff, IC diff, IA bias, IB bias, IC bias Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 212 of 479...
  • Page 213 W1_CB Close ON/OFF 1,7,9,11, 20 W2_CB Trip ON/OFF 1,7,9,11, 20 W2_CB Close ON/OFF 1,7,9,11, 20 ON/OFF 1, 7, 9, 11 J Out1 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 213 of 479...
  • Page 214 1, 7, 9, 11 n/w I-7 ON/OFF 1, 7, 9, 11 n/w I-8 ON/OFF 1, 7, 9, 11 n/w I-9 ON/OFF 1, 7, 9, 11 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 214 of 479...
  • Page 215 1, 7, 9, 11 VIO-30 ON/OFF 1, 7, 9, 11 VIO-31 ON/OFF 1, 7, 9, 11 VIO-32 ON/OFF 1, 7, 9, 11 Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 215 of 479...
  • Page 216 This document provides a proposal of mapping Ashida relay process data into IEC61850 server objects. The list of application functions of the Ashida relays is derived from the information specified as the project requirements in the document “IEC61850 Server for Ashida Electronics Preliminary Requirements Specification”.
  • Page 217 Data Attribute Dataset REFPDIF10$ST$OpCntRs$stVal dchg REFPDIF10$ST$Str$general dchg REFPDIF10$ST$Op$general dchg W1 IP>1 Non-Directional Phase Overcurrent Stage 1 Data Attribute Dataset W1IP1PTOC1$ST$OpCntRs$stVal dchg W1IP1PTOC1$ST$Str$general dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 217 of 479...
  • Page 218 Data Attribute Dataset W2IP3PTOC6$ST$OpCntRs$stVal dchg W2IP3PTOC6$ST$Str$general dchg W2IP3PTOC6$ST$Op$general dchg IE>1 Non-Directional Earth Fault Stage1 Data Attribute Dataset IE1PTOC19$ST$OpCntRs$stVal dchg IE1PTOC19$ST$Str$general dchg IE1PTOC19$ST$Op$general dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 218 of 479...
  • Page 219 W23I0>1 Non-Directional Residual OC Stage1 Data Attribute Dataset W2I01PTOC16$ST$OpCntRs$stVal dchg W2I01PTOC16$ST$Str$general dchg W2I01PTOC16$ST$Op$general dchg W23I0>2 Non-Directional Residual OC Stage2 Data Attribute Dataset W2I02PTOC17$ST$OpCntRs$stVal dchg W2I02PTOC17$ST$Str$general dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 219 of 479...
  • Page 220 Data Attribute Dataset W2SQ1PTOC10$ST$OpCntRs$stVal dchg W2SQ1PTOC10$ST$Str$general dchg W2SQ1PTOC10$ST$Op$general dchg W2 Seq>2 Sequence Overcurrent Stage2 Data Attribute Dataset W2SQ2PTOC11$ST$OpCntRs$stVal dchg W2SQ2PTOC11$ST$Str$general dchg W2SQ2PTOC11$ST$Op$general dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 220 of 479...
  • Page 221 VbyHz2PVPH2$ST$Op$general dchg V/Hz-3 Protection Stage3 Data Attribute Dataset VbyHz3PVPH3$ST$Str$general dchg VbyHz3PVPH3$ST$Op$general dchg V/Hz-4 Protection Stage4 Data Attribute Dataset VbyHz4PVPH4$ST$Str$general dchg VbyHz4PVPH4$ST$Op$general dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 221 of 479...
  • Page 222 Data Attribute Dataset W1CLFGGIO20$ST$Alm$stVal dchg W2CB Close Fail Alarm Data Attribute Dataset W2CLFGGIO21$ST$Alm$stVal dchg W1CB Open Fail Alarm Data Attribute Dataset W1OPFGGIO22$ST$Alm$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 222 of 479...
  • Page 223 W2BFRBRF2$ST$Str$general dchg W2BFRBRF2$ST$OpEx$general dchg S1-8 Binary Status Input 1-8 Data Attribute Dataset SGGIO1$ST$Ind1$stval dchg SGGIO1$ST$Ind2$stVal dchg SGGIO1$ST$Ind3$stVal dchg SGGIO1$ST$Ind4$stVal dchg SGGIO1$ST$Ind5$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 223 of 479...
  • Page 224 SGGIO31$ST$Ind4$stVal dchg SGGIO31$ST$Ind5$stVal dchg SGGIO31$ST$Ind6$stVal dchg SGGIO31$ST$Ind7$stVal dchg SGGIO31$ST$Ind8$stVal dchg RL1-8 Binary Control Output 1-8 Data Attribute Dataset RLGGIO2$CO$SPCSO1$Oper$ctlVal RLGGIO2$ST$SPCSO1$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 224 of 479...
  • Page 225 RL17-24 Binary Control Output 17-24 (Available only in M19” model) Data Attribute Dataset RLGGIO32$CO$SPCSO1$Oper$ctlVal RLGGIO32$ST$SPCSO1$stVal dchg RLGGIO32$CO$SPCSO2$Oper$ctlVal RLGGIO32$ST$SPCSO2$stVal dchg RLGGIO32$CO$SPCSO3$Oper$ctlVal RLGGIO32$ST$SPCSO3$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 225 of 479...
  • Page 226 Data Attribute Dataset GLEDGGIO8$ST$Ind1$stval dchg GLEDGGIO8$ST$Ind2$stVal dchg GLEDGGIO8$ST$Ind3$stVal dchg GLEDGGIO8$ST$Ind4$stVal dchg GLEDGGIO8$ST$Ind5$stVal dchg GLEDGGIO8$ST$Ind6$stVal dchg GLEDGGIO8$ST$Ind7$stVal dchg GLEDGGIO8$ST$Ind8$stVal dchg GLEDGGIO8$ST$Ind9$stval dchg GLEDGGIO8$ST$Ind10$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 226 of 479...
  • Page 227 NWOGGIO11$ST$Ind4$stVal dchg NWOGGIO11$ST$Ind5$stVal dchg NWOGGIO11$ST$Ind6$stVal dchg NWOGGIO11$ST$Ind7$stVal dchg NWOGGIO11$ST$Ind8$stVal dchg NWOGGIO11$ST$Ind9$stval dchg NWOGGIO11$ST$Ind10$stVal dchg NWOGGIO11$ST$Ind11$stVal dchg NWOGGIO11$ST$Ind12$stVal dchg NWOGGIO11$ST$Ind13$stVal dchg NWOGGIO11$ST$Ind14$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 227 of 479...
  • Page 228 NWIGGIO10$CO$SPCS13$Oper$ctlVal NWIGGIO10$ST$SPCS13$stVal dchg NWIGGIO10$CO$SPCS14$Oper$ctlVal NWIGGIO10$ST$SPCS14$stVal dchg NWIGGIO10$CO$SPCS15$Oper$ctlVal NWIGGIO10$ST$SPCS15$stVal dchg NWIGGIO10$CO$SPCS16$Oper$ctlVal NWIGGIO10$ST$SPCS16$stVal dchg VIOs Indication 1-32 Data Attribute Dataset VIOGGIO12$CO$SPCSO1$Oper$ctlVal VIOGGIO12$ST$SPCSO1$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 228 of 479...
  • Page 229 VIOGGIO12$CO$SPCSO16$Oper$ctlVal VIOGGIO12$ST$SPCSO16$stVal dchg VIOGGIO12$CO$SPCSO17$Oper$ctlVal VIOGGIO12$ST$SPCSO17$stVal dchg VIOGGIO12$CO$SPCSO18$Oper$ctlVal VIOGGIO12$ST$SPCSO18$stVal dchg VIOGGIO12$CO$SPCSO19$Oper$ctlVal VIOGGIO12$ST$SPCSO19$stVal dchg VIOGGIO12$CO$SPCSO20$Oper$ctlVal VIOGGIO12$ST$SPCSO20$stVal dchg VIOGGIO12$CO$SPCSO21$Oper$ctlVal VIOGGIO12$ST$SPCSO21$stVal dchg VIOGGIO12$CO$SPCSO22$Oper$ctlVal VIOGGIO12$ST$SPCSO22$stVal dchg VIOGGIO12$CO$SPCSO23$Oper$ctlVal Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 229 of 479...
  • Page 230 EQNGGIO13$ST$Ind10$stVal dchg EQNGGIO13$ST$Ind11$stVal dchg EQNGGIO13$ST$Ind12$stVal dchg EQNGGIO13$ST$Ind13$stVal dchg EQNGGIO13$ST$Ind14$stVal dchg EQNGGIO13$ST$Ind15$stVal dchg EQNGGIO13$ST$Ind16$stVal dchg Relay Healthy Data Attribute Dataset AshidaLPHD1$ST$PhyHealth$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 230 of 479...
  • Page 231 W1MSQI1$MX$SeqA$c1$cVal$mag$f dchg W1MSQI1$MX$SeqA$c2$cVal$mag$f dchg W1MSQI1$MX$SeqA$c3$cVal$mag$f dchg W2MSQI2$MX$SeqA$c1$cVal$mag$f dchg W2MSQI2$MX$SeqA$c2$cVal$mag$f dchg W2MSQI2$MX$SeqA$c3$cVal$mag$f dchg W1BOTGGIO25$MX$AnIn$mag$f dchg W2BOTGGIO26$MX$AnIn$mag$f dchg THSTGGIO34$MX$AnIn$mag$f dchg W1SgIGGIO40$MX$AnIn$mag$f dchg W2SgIGGIO41$MX$AnIn$mag$f dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 231 of 479...
  • Page 232 W2CB Circuit Breaker, T1 CB NO, T2 CB NC, Trip CB Open, Close CB Close Data Attribute Dataset CBCSWI2$ST$Loc$stVal dchg CBCSWI2$ST$OpCntRs$stVal dchg CBCSWI2$ST$Pos$stVal dchg Group Change Control 1-4 Data Attribute Dataset GRPGGIO36$CO$SPCSO1$Oper$ctlVal Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 232 of 479...
  • Page 233 Data Attribute Dataset W1SigGGIO38$ST$Alm$stVal dchg W2 Sigma I Alarm Data Attribute Dataset W2SigGGIO39$ST$Alm$stVal dchg GOOSE SUB Alarm Data Attribute Dataset SUBGGIO99$ST$Alm$stVal dchg Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/CS Rev No. : 05 Page No. : 233 of 479...
  • Page 234 Page Intentionally Left Blank...
  • Page 235 ADR233B Section 8 User Guide Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 235 of 479...
  • Page 236 To View – Error Lof 8.4.6.5 CB Data 8.4.6.5.1 To View – CB Data 8.4.6.6 Alarm Record 8.4.6.6.1 To View – Alarm Record 8.4.7 SYSTEM CONFIG Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 236 of 479...
  • Page 237 V/Hz Protection (If Enabled) 8.4.11.12 Breaker Failure 8.4.11.12.1 To Set – W1 50BF (If Disabled) 8.4.11.12.2 To Set – W1 50 BF (If Enabled) Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 237 of 479...
  • Page 238 To Set – Thermal Overload (If Enabled) 8.4.11.14 Through Fault 8.4.11.14.1 Through Fault (If Disabled) 8.4.11.14.2 Through Fault (If Enabled) 8.4.12 Active Group 8.4.12.1 To View – Active Group Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 238 of 479...

  • Page 239: User Guide Overview

    FRONT PANEL AND CONTROL The HMI module provided with 20x4 LCD, 9 numbers of soft feather touch keys and 16 numbers of dual LED’s on the Front Panel of the relay. Figure 1: Front Panel details of ADR233B-B0 Transformer Protection Relay ADR233B...
  • Page 240 ADR233B Figure 2: Front Panel details of ADR233B-M0 Sr. No. Legend Function Programmable Dual Colour LED Default Assignment: GREEN LED – indicates Relay Enabled. Default Assignment: RED LED – indicates Relay Error. Programmable Dual Colour LED Programmable Dual Colour LED...

  • Page 241: User Interface

    • Display of Error Log for hardware and software faults 8.2.2 Touch Keys The function of relay controlled by the following keys provided on the Front Plate: Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 241 of 479...

  • Page 242: Leds

    8.2.3 LEDS The ADR233B relay provides 16 nos. of dual color LED’s for indication. The following table explains the assignment process to LED. Here G represents Green LED and R Represent Red LED. Sr. No.

  • Page 243: Communication Ports

    This window will be displayed General Settings Step 5 : Press the Edit Key to activate the settings Password **** Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 243 of 479...
  • Page 244 Step 9: After editing the Password, press the EDIT Key. The settable Alpha / Numerical value will stop blinking. Step 10: Press the Right arrow key () to move to the next option Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 244 of 479...
  • Page 245 Company will provide one time password to enable to set new password. For one time password the user needs to send serial number, Date & Month display on Relay HMI. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 245 of 479...

  • Page 246: Menus

    After Power ON or when the TARGET RESET + EDIT Feather Touch Keys are pressed simultaneously; the relay will display the following message. This window will flash momentarily showing the following ADR233B Relay Type : ADR233B Tx. Diff Prot Relay Name : TRANSFORMER DIFFERENTIAL PROTECTION...

  • Page 247: Main Menu List

    Record, Error Log, CB Data and Alarm Record. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 247 of 479...
  • Page 248 OC, W2 Residual OC) , Sequence OC (W1 Sequence OC, W2 Sequence OC), Under Voltage, Over Voltage, V/Hz Protection, Breaker Failure (W1 50BF, W2 50BF), Thermal Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 248 of 479...

  • Page 249: Active Group

    CA of Winding 1 (W1). W1 – ICA MAG : Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 249 of 479...
  • Page 250 Press the Minus / Down arrow key (- /) to move to the next W1 – I2 P ANG : 0 Deg option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 250 of 479...
  • Page 251 W2 – IC MAG : (W2) & Neutral. IN MAG : Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 251 of 479...
  • Page 252 Secondary Current in Phase BC of Winding 2 (W2). 0 Deg Press the Minus / Down arrow key (- /) to move to the next W2 – Ibc MAG : option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 252 of 479...
  • Page 253 0.00 A W2 – Ib RMS : Press the Minus / Down arrow key (- /) to move to the next 0.00 A option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 253 of 479...

  • Page 254: To View - Measurement 2

    Press the Minus / Down arrow key (- /) to move to the next 0.00 pu option. IA – Diff : 0.00 pu Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 254 of 479...

  • Page 255: Global

    Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port, CB CONTOL Disturbance, Display Contrast & Date and Time. REPORTING Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 255 of 479...
  • Page 256 Password protected window for “PORT R” setting i.e. Unit ID, Baud Rate and Set Parity. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 256 of 479...

  • Page 257: General Setting

    GLOBAL Disturbance, Display Contrast and Date and Time. CB CONTOL Press the Right arrow key () to move to the next option. REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 257 of 479...
  • Page 258 (- /) the Phase Ref. can be set i.e. PT / W1-Rph / W2-Rph. Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 258 of 479...
  • Page 259 (- /) the PB–1 Operation can be set i.e. No Enabled Operation / Enabled. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 259 of 479...
  • Page 260 Press the Minus / Down arrow key (- /) to move to the next option. Read-only General Settings This window shows the Description of the relay. Description ASHIDA ADR233B E0 Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No.
  • Page 261 (- /) select Virtual Scheme 2 can be set i.e. Disabled Disabled / Enabled. Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 261 of 479...

  • Page 262: Save Settings

    Factory Defaults, Active Group, Copy From, Copy To, G1, G2, G3 and G4. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 262 of 479...
  • Page 263 (- /) the G1 can be set i.e. Disabled / Enabled / Enabled TimeEnabled. Note: When set as Enabled Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 263 of 479...
  • Page 264 This window will flash for a moment and it will move to the SAVE SETTINGS Main Menu. MEASURMENTS  GLOBAL CB CONTOL REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 264 of 479...

  • Page 265: Setting Group (If Set As Timeenabled)

    (- /) the Copy from can be set i.e. G1 / G2 / G3 / Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 265 of 479...
  • Page 266 The setting range is from 0 to 400s in step of 0.1s. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 266 of 479...
  • Page 267 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 267 of 479...

  • Page 268: Port Fport

    This window shows the Set Parity of the relay. Set Parity None Press the Right arrow key () to move to the Main Menu. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 268 of 479...
  • Page 269 The setting range is from 0 to 255. As per Editing Password setting. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 269 of 479...
  • Page 270 (- /) the Protocol can be set i.e. Disabled / Disabled Enabled. Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 270 of 479...
  • Page 271 PORT 1 This window shows the Primary LAN1. Primary LAN 1 Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 271 of 479...

  • Page 272: Port R

    SCADA computer. Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 272 of 479...

  • Page 273: Irig Port (Optional)

    GLOBAL Disturbance, Display Contrast and Date and Time. CB CONTOL Press the Right arrow key () to move to the next option. REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 273 of 479...

  • Page 274: Disturbance

    The setting range is from 5% to 95% in step of 1%. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 274 of 479...

  • Page 275: Display Contrast (Read Only)

    This window shows the Contrast of the relay. Contrast Set 50 % Press the Right arrow key () to move to the Main Menu. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 275 of 479...

  • Page 276: Date And Time

    (- /) the Local Time Enable can be set i.e. Disabled Disabled / Fixed / Flexible. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 276 of 479...
  • Page 277 (- /) the SET Date can be set. Range 1 – 31 The setting range is from 1 to 31 in step of 1. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 277 of 479...

  • Page 278: Date And Time (If Enabled)

    GLOBAL Disturbance, Display Contrast and Date and Time. CB CONTOL Press the Right arrow key () to move to the next option. REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 278 of 479...
  • Page 279 This window shows the set DST Enable. DST Enabled Disabled Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 279 of 479...
  • Page 280 The setting range is from 1 to 31 in step of 1. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 280 of 479...

  • Page 281: Cb Control

    CB CONTROL and W2 CB CONTROL. GLOBAL  Press the Right arrow key () to move to the next option. CB CONTOL REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 281 of 479...
  • Page 282 The setting range is from 1 to 5000 A instep of 1A. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 282 of 479...

  • Page 283: Cb Control - W1 Cb Control (If Enabled)

    CB CONTROL and W2 CB CONTROL. GLOBAL  Press the Right arrow key () to move to the next option. CB CONTOL REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 283 of 479...
  • Page 284 The setting range is from 50 to 1000ms in step of 10ms. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 284 of 479...
  • Page 285 Local + Remote Local / Remote / Local + Remote. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 285 of 479...

  • Page 286: To View - Reporting

    Record, Error Log, CB Data and Alarm Record. GLOBAL Press the Right arrow key () to move to the next option. CB CONTOL  REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 286 of 479...
  • Page 287 This menu is to view “Alarm Record” Alarm Record Press the Left arrow key () to move to the Main Menu. MEASURMENT GLOBAL CB CONTOL  REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 287 of 479...

  • Page 288: Events

    Event Num = 18 Press the Right arrow key () to move to the Main Menu. Th Trip MEASURMENT GLOBAL CB CONTOL  REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 288 of 479...

  • Page 289: Status

    H In : 87654321 Press the Minus / Down arrow key (- /) to move to the next 00000000 option. I In : Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 289 of 479...

  • Page 290: Fault Record

    This window shows Fault Record ( i.e. Fault Number 01 to 10) Fault Num = 01 Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 290 of 479...
  • Page 291 Press the Minus / Down arrow key (- /) to move to the next 2.00620 A option. W2 – Ib MAG 2.00190 A Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 291 of 479...

  • Page 292: Error Log

    Record, Error Log, CB Data and Alarm Record. GLOBAL Press the Right arrow key () to move to the next option. CB CONTOL  REPORTING Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 292 of 479...

  • Page 293: Cb Data

    Breaker Operation Counter W1–BOT = 0 mSec Press the Minus / Down arrow key (- /) to move to the next W1–BOC option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 293 of 479...

  • Page 294: Alarm Record

    This window shows Tripping counter, Breaker Opening Time 13/04/2018 and Breaker Operation Counter 06:14:50:900 Press the Right arrow key () to move to the Main Menu. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 294 of 479...

  • Page 295: System Config

    The setting range is from 10 to 5000A in step of 1A. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 295 of 479...
  • Page 296 (- /) the CT Star Point can be set i.e. Towards Towards Object Object / Away From Object. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 296 of 479...
  • Page 297 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 297 of 479...

  • Page 298: Protections

    (- /) the REF can be set i.e. Disabled / Enabled. Enabled Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 298 of 479...
  • Page 299 (- /) the W2 Residual OC can be set i.e. Disabled Enabled / Enabled. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 299 of 479...
  • Page 300 (- /) the V/Hz Protection can be set i.e. Disabled Enabled / Enabled. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 300 of 479...
  • Page 301 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 301 of 479...

  • Page 302: Clear Records

    (- /) the Clear Disturbance Record can be set i.e. Yes / No. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 302 of 479...
  • Page 303 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 303 of 479...

  • Page 304: Output & Led Test

    Range 0 – 1 Not Operated / 1 = Operated) Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 304 of 479...
  • Page 305 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 305 of 479...

  • Page 306: Group 1 - Menu List

    Cross blocking) 5th Hrm Diff BLK (5H Diff Threshold & t 5th Hrm) Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 306 of 479...
  • Page 307 3Io>3 Enable) can be set as Disabled / Enabled Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 307 of 479...
  • Page 308 V/Hz-4 Protection, V/Hz-5 Protection and V/Hz-6 Protection can be set as Disabled/Enabled. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 308 of 479...

  • Page 309: Group

    Voltage, V/Hz Protection, Breaker Failure, Thermal Overload GROUP 1  and Through Fault. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 309 of 479...
  • Page 310 The setting range is from 1 to 1000 KV in step of 0.1KV. Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 310 of 479...
  • Page 311 (- /) the W2 Grounding can be set i.e. Grounded Grounded / Ungrounded Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 311 of 479...
  • Page 312 This window shows the REF Match Factor. REF Match Factor 1.000 Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 312 of 479...

  • Page 313: Ph Differential

    Password protected window for “Ph Differential” setting i.e. Ph Differential Disabled / Enabled. Disabled Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 313 of 479...

  • Page 314: Ph Differential (If Enabled)

    Voltage, V/Hz Protection, Breaker Failure, Thermal Overload GROUP 1  and Through Fault. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 314 of 479...
  • Page 315 The setting range is from 0.1 to 10pu in step of 0.1pu. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 315 of 479...
  • Page 316 (- /) the Ph Differential can be set i.e. Disabled / Enabled Enabled. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 316 of 479...
  • Page 317 / Enabled / TimeEnabled Note: When set as TimeEnabled. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 317 of 479...
  • Page 318 Range 0 – 10 s Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 318 of 479...

  • Page 319: Ref

    Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 319 of 479...

  • Page 320: Ref (If Lowz)

    (- /) the Ref. Winding can be set. i.e. W1 / W2. Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 320 of 479...
  • Page 321 The setting range is from 0 to 10s in step of 0.1s. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 321 of 479...

  • Page 322: Ref (If Highz)

    Voltage, V/Hz Protection, Breaker Failure, Thermal Overload GROUP 1  and Through Fault. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 322 of 479...
  • Page 323 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 323 of 479...

  • Page 324: Phase Oc

    By using the Plus / Up arrow key (+ /) or the Minus / Down IP>1 Enable arrow key (- /) the IP>1 Enable can be set i.e. Disabled Disabled/Enabled. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 324 of 479...
  • Page 325 CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Note : The Phase OC settings of W2 Phase OC is similar to W1 Phase Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 325 of 479...

  • Page 326: W1 Phase Oc (If Iec/ Uk Curve Is Selected)

    IEEE E Inverse / US Inverse / US ST Inverse. Note: When set as IEC Curve. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 326 of 479...
  • Page 327 Note: If Disabled the IP>1 2H BLK function is blocked. Press the Minus / Down arrow key (- /) to move to the next option. If Enabled Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 327 of 479...
  • Page 328 Note : The Phase OC settings of W1 IP>2 Enable and IP>3 Enable for all IEC Curves is similar to Phase OC setting of W1 IP>1 Enable. Note : The Phase OC settings of W2 Phase OC is similar to W1 Phase Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 328 of 479...

  • Page 329: W1 Phase Oc (If Ieee / Us Curve Is Selected)

    Note : When set as IEEE M Inverse Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 329 of 479...
  • Page 330 The setting range is from 0.025 to 1.2 in step of 0.001 Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 330 of 479...
  • Page 331 This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS PROTECTION CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 331 of 479...

  • Page 332: W1 Phase Oc (If Definite Time Is Selected)

    (- /) the IP>1 Enabled can be set i.e. Disabled / Enabled Enabled. Note: When set as Enabled Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 332 of 479...
  • Page 333 The setting range is from 0s to 100s in step of 0.01s Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 333 of 479...
  • Page 334 This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS PROTECTION CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 334 of 479...

  • Page 335: Ground Oc

    (- /) the IE>1 Enable can be set i.e. Disabled / Disabled Enabled. Note: When set as Disabled Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 335 of 479...

  • Page 336: Ground Oc (If Iec Curve Is Selected)

    OC, Residual OC, Sequence OC, Under Voltage, Over OUTPUT & LED TEST Voltage, V/Hz Protection, Breaker Failure, Thermal Overload GROUP 1  and Through Fault. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 336 of 479...
  • Page 337 0.05 to 4.00 xIn in step of 0.01 xIn. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 337 of 479...
  • Page 338 The setting range is from 5% to 70% in step of 1% Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 338 of 479...

  • Page 339: Ground Oc (If Ieee / Us Curve Is Selected)

    (- /) select Ground OC. Phase OC  Ground OC Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 339 of 479...
  • Page 340 The setting range is from 0.01 to 100 in step of 0.01 Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 340 of 479...
  • Page 341 The setting range is from 5 to 70% in step of 1% Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 341 of 479...

  • Page 342: Ground Oc (If Definite Time Is Selected)

    (- /) select Ground OC. Phase OC  Ground OC Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 342 of 479...
  • Page 343 The setting range is from 0 (Inst) to 1899.9sec in step of 0.01sec. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 343 of 479...
  • Page 344 The setting range is from 4.0 to 32.0 xIn in step 0.1 xIn. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 344 of 479...

  • Page 345: Residual Oc

     W1 Residual OC arrow key (- /) select W1 Residual OC. W2 Residual OC Password protected window for “W1 Residual OC” setting Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 345 of 479...
  • Page 346 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 346 of 479...

  • Page 347: W1 Residual Oc (If Iec Curve Is Selected)

    (- /) the 3Io>1 Enable can be set i.e. Disabled / Enabled Enabled. Note: When set as Enabled. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 347 of 479...
  • Page 348 The setting range is from 0 to 100s in step of 0.01s Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 348 of 479...
  • Page 349 This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS PROTECTION CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 349 of 479...

  • Page 350: Residual Oc (If Ieee / Us Curve Is Selected)

    (- /) the 3Io>1 Enable can be set i.e. Disabled / Enabled Enabled. Note: When set as Enabled. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 350 of 479...
  • Page 351 The setting range is from 0s to 100s in step of 0.01s Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 351 of 479...
  • Page 352 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 352 of 479...

  • Page 353: Residual Oc (If Definite Time Is Selected)

    3Io>1 Enable, 3Io>2 Enable and 3Io>3 Enable can be set as Disabled/Enabled. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 353 of 479...
  • Page 354 (- /) the 3Io>1 D/O Char can be set i.e. Disabled / Note: If Disabled the D/O Characteristics function is blocked. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 354 of 479...
  • Page 355 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 355 of 479...

  • Page 356: Sequence Oc

    Password protected window for “W1 Sequence OC” setting i.e. Seq. I>1 Enable, Seq. I>2 Enable and Seq. I>3 Enable can be set as Disabled / -Seq / +Seq. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 356 of 479...
  • Page 357 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 357 of 479...

  • Page 358: Sequence Oc (If Iec Curve Is Selected)

    +Seq -Seq / +Seq. Note: When set as -Seq / +Seq. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 358 of 479...
  • Page 359 The setting range is from 0 to 100s in step of 0.01s Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 359 of 479...
  • Page 360 This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS PROTECTION CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 360 of 479...

  • Page 361: Sequence Oc (If Ieee / Us Curve Is Selected)

    / +Seq / - Seq. Note: If set as +Seq / - Seq. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 361 of 479...
  • Page 362 The setting range is from 0s to 100s in step of 0.01s Press the Minus / Down arrow key (- /) to move to the next Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 362 of 479...
  • Page 363 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 363 of 479...

  • Page 364: Sequence Oc (If Definite Time Is Selected)

    Seq. I>1 Enable, Seq. I>2 Enable and Seq. I>3 Enable can be set as Disabled / -Seq / +Seq. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 364 of 479...
  • Page 365 (- /) the Seq.I>1 D/O Char can be set i.e. Disabled / DT. Note: If Disabled the D/O Characteristics function is blocked. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 365 of 479...
  • Page 366 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 366 of 479...

  • Page 367: Under Voltage

    Disabled set i.e. Disabled / Enabled. Note: When set as Disabled. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 367 of 479...

  • Page 368: To Set - Under Voltage (If Enabled)

    Disabled / Enabled. Enabled Note: When set as Enabled. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 368 of 479...

  • Page 369: Over Voltage

    Voltage, V/Hz Protection, Breaker Failure, Thermal Overload GROUP 1  and Through Fault. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 369 of 479...

  • Page 370: To Set - Over Voltage (If Enable)

    Voltage, V/Hz Protection, Breaker Failure, Thermal Overload GROUP 1  and Through Fault. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 370 of 479...
  • Page 371 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 371 of 479...

  • Page 372: V/Hz Protection

    – 4 Protection, V/Hz – 5 Protection, V/Hz – 6 Protection are set as Disabled. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 372 of 479...

  • Page 373: V/Hz Protection (If Enabled)

    (- /) select V/Hz – 1 Protection. Enabled Password protected window for “V/Hz – 1 Protection” setting i.e. can be set as Disabled / Enabled. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 373 of 479...
  • Page 374 This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS PROTECTION CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 374 of 479...

  • Page 375: Breaker Failure

    Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 375 of 479...

  • Page 376: To Set - W1 50 Bf (If Enabled)

    (- /) the desired W1_50BF Enable can be set i.e. Enabled Disabled / Enabled. Note: When set as Enabled. Press the Right arrow key () to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 376 of 479...
  • Page 377 Press Target Reset Key For Cancel This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 377 of 479...
  • Page 378 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 378 of 479...
  • Page 379 The setting range is from 5 to 400 % in step of 1 %. Press the Minus / Down arrow key (- /) to move to the next option. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 379 of 479...
  • Page 380 PROTECTION CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Note: The settings for Thermal Overload i.e. W2 is similar to W1 Settings. Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 380 of 479...
  • Page 381 This window will flash for a moment and it will move to the Main Menu. SAVE SETTINGS PROTECTION CLEAR RECORDS OUTPUT & LED TEST GROUP 1  Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 381 of 479...
  • Page 382 Press the Right arrow key () to move to the next option. Press the Left arrow key () to SAVE the changes. Press Key For SAVE Press Target Reset Key For Cancel Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 382 of 479...

  • Page 383: Active Group

    Press the Right arrow key () to move to the Main Menu G1 – G4 Group1  ACTIVE GROUP MEASURMENT GLOBAL CB CONTOL Doc ID :ADR233B/IM/01 Ref ID : ADR233B/IM/UG Rev No. : 05 Page No. : 383 of 479...
  • Page 384 Page Intentionally Left Blank...

  • Page 385: Flow Chart

    ADR233B Section 9 Flow Chart Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 385 of 479...
  • Page 386 Ph Differential (If Disabled) 9.11.2.2 Ph Differential (If Enabled) 9.11.3 9.11.3.1 REF (If Disabled) 9.11.3.2 REF (If LowZ) 9.11.3.3 REF (If HighZ) Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 386 of 479...
  • Page 387 Thermal Overload (If Disabled) 9.11.12.2 Thermal Overload (If Enabled) 9.11.13 Through Fault 9.11.13.1 Through Fault (If Disabled) 9.11.13.2 Through Fault (If Enabled) 9.12 Active Group Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 387 of 479...

  • Page 388: Flow Chart Overview

    Note: By using the Up arrow key ( ) and the down arrow key ( ) the Main Menu settings can be scrolled. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 388 of 479...
  • Page 389 DISCARD Settings DISCARD Settings) Target Reset This window will flash for a moment and the control will return to the main menu. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 389 of 479...
  • Page 390 0.000 A W1 – 3I0 MAG : W1 – Iab ANG : 0.00 A 0 Deg W1 – Ia RMS 0.04 A Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 390 of 479...
  • Page 391 W2 – I1 P MAG : 0.00 Hz V/Hz : W2 – I2 P ANG : 0.00 0 Deg Th State W2 – I1 MAG : Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 391 of 479...

  • Page 392: To View - Measurement

    0.00 pu IC – Diff : 0.00 pu Iref 0.00 pu Iref – Diff : 0.00 pu Iref Bias : 0.00 pu Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 392 of 479...
  • Page 393 Note: By using the Up arrow key ( ) and the down arrow key ( ) the Main Menu settings can be scrolled. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 393 of 479...

  • Page 394: General Settings

    PORT F No Operation General Setting General Setting General Settings General Setting Hardware Version Description SubStn_ID PB-1 Operation Vx.xx ASHIDA ADR233B E0 Enabled General Settings General Setting General Settings Phase Ref. General Setting Equipment Model Number tPB-1 Pulse Transformer ADR233BE0xxxxxxxxxxS 0.50 s...

  • Page 395: Settings Group

    No Operation Setting Group Enabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 395 of 479...
  • Page 396 Range 0 – 400 s Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 396 of 479...
  • Page 397 CB CONTROL PORT F REPORTING PORT 1 PORT F Unit ID PORT F Baud Rate 57600 BPS PORT F Set Parity None Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 397 of 479...
  • Page 398 DISCARD Settings Target Reset Note : (*) indicates Edit key used to modify settings. Refer Edit Password and Save Setting in Flow Chart. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 398 of 479...
  • Page 399 PORT R Set Parity Even Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 399 of 479...
  • Page 400 IRIG Port IRIG Port Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 400 of 479...
  • Page 401 Range 5 – 95% Disturbance Sampling 16 Samples Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 401 of 479...

  • Page 402: Display Contrast

    Display contrast Contrast Set 50 % Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 402 of 479...

  • Page 403: Date And Time

    Range 0 – 23 Range 0 – 99 Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 403 of 479...
  • Page 404 Range 0 – 23 Range 0 – 99 Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 404 of 479...
  • Page 405 Key For Cancel DISCARD Settings Target Reset Note: The CB Control settings of W2 CB Control is similar to W1 CB Control Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 405 of 479...
  • Page 406 Key For Cancel DISCARD Settings Target Reset Note: The CB Control setting of W2 CB Control is similar to W1 CB Control. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 406 of 479...
  • Page 407 ADR233B Reporting GLOBAL CB CONTROL REPORTING SYSTEM CONFIG Event CB Data Status Fault Record Alarm Record Error Log Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 407 of 479...

  • Page 408: Event Reporting

    SYSTEM CONFIG Event Event Num = 18 Event Num = 18 Date : 13/03/2021 Time : 09:24:25:050 Event Num = 18 Th Trip Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 408 of 479...

  • Page 409: Status Reporting

    O In : 87654321 00000000 J Out : 87654321 00000000 K Out : 87654321 00000000 L Out : 87654321 00000000 M Out : 87654321 00000000 Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 409 of 479...
  • Page 410 REPORTING SYSTEM CONFIG Status H In : 87654321 00000000 I In : J Out : 87654321 00000000 K Out : 87654321 00000000 Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 410 of 479...
  • Page 411 REPORTING SYSTEM CONFIG Status H In : 87654321 00000000 I In : 4321 0000 J Out : 87654321 00000000 K Out : Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 411 of 479...
  • Page 412 W1 I1 T W2 – Ia MAG V/Hz W2 I2 T 2.00620 A 2.2210 W2 – Ib MAG Th State 2.00190 A Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 412 of 479...
  • Page 413 REPORTING SYSTEM CONFIG Error Log Maint Rec Num = Error Cod = 00000002 RTC Error Errorcod : 00000002 RTC Error 21/06/2017 10:39:25:527 Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 413 of 479...
  • Page 414 CB Data – Reporting GLOBAL CB CONTROL REPORTING SYSTEM CONFIG CB Data W1–BOT = 0 mSec W1–BOC W2–BOT = 0 mSec W2–BOC Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 414 of 479...
  • Page 415 ADR233B 9.6.6 Alarm Record – Reporting GLOBAL CB CONTROL REPORTING SYSTEM CONFIG Alarm Record W1–TCS Alarm 13/04/2018 06:13:50:236 Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 415 of 479...
  • Page 416 Setting Values Secondary Towards Object Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 416 of 479...
  • Page 417 Through Fault Enabled Enabled Enabled Press 3 Key For Save SAVE Settings Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 417 of 479...
  • Page 418 CLEAR RECORDS Thermal State Error Record Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 418 of 479...
  • Page 419 00000000 Range 0 – 1 Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 419 of 479...
  • Page 420 Note: By using the Up arrow key ( ) and the down arrow key ( ) the Main Menu settings can be scrolled. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 420 of 479...

  • Page 421: Equipment Data

    33.0 KV Range 1 – 1000KV Press 3 Key For Save SAVE Settings Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 421 of 479...
  • Page 422 5th Hrm Diff BLK Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 422 of 479...
  • Page 423 Range 0 - 10 s Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 423 of 479...
  • Page 424 Phase OC REF Enable Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 424 of 479...
  • Page 425 Range 0.1 – 10 pu Range 5 – 70% Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 425 of 479...
  • Page 426 Range 5 – 70 % Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 426 of 479...
  • Page 427 Key For Cancel DISCARD Settings Target Reset Note : The Phase OC settings of W2 Phase OC is similar to W1 Phase OC Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 427 of 479...
  • Page 428 W1 Phase OC of IP>1 Enable. Note: The Phase OC settings of W2 Phase OC is similar to that W1 Phase Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 428 of 479...
  • Page 429 Note: The W1 Phase OC settings of IP>2 Enable and IP>3 Enable for all IEEE / US Curves is similar to W1 Phase OC setting of IP>1 Enable. Note: The Phase OC settings of W2 Phase OC is similar to W1 Phase Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 429 of 479...
  • Page 430 W1 Phase OC setting of IP>1 Enable. Note: The Phase OC settings of W2 Phase OC is similar to that W1 Phase Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 430 of 479...
  • Page 431 Ground OC IE>3 Enable Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 431 of 479...
  • Page 432 Note: The Ground OC settings of IE>2 Enable and IE>3 Enable for all IEC Curves is similar to Ground OC setting of IE>1 Enable. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 432 of 479...
  • Page 433 Note: The Ground OC settings of IE>2 Enable and IE>3 Enable for all IEEE / US Curves is similar to Ground OC setting of IE>1 Enable. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 433 of 479...
  • Page 434 Note : The Ground OC settings of IE>2 Enable and IE>3 Enable for Definite Time Curve is similar to Ground OC setting of IE>1 Enable. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 434 of 479...
  • Page 435 Key For Cancel DISCARD Settings Target Reset Note: The Residual OC settings of W2 Residual OC is similar to W1 Residual OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 435 of 479...
  • Page 436 W1 Residual OC setting of 3Io>1 Enable. Note: The Residual OC settings of W2 Residual OC is similar to that W1 Residual OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 436 of 479...
  • Page 437 W1 Residual OC setting of IE>1 Enable. Note: The Residual OC settings of W2 Residual OC is similar to W1 Residual OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 437 of 479...
  • Page 438 W1 Residual OC setting of 3Io>1 Enable. Note: The Residual OC settings of W2 Residual OC is similar to W1 Residual OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 438 of 479...
  • Page 439 Key For Cancel DISCARD Settings Target Reset Note: The Sequence OC settings of W2 Sequence OC is similar to W1 Sequence OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 439 of 479...
  • Page 440 W1 Sequence OC setting of Seq.I>1 Enable. Note : The Sequence OC settings of W2 Sequence OC will be similar to that W1 Sequence OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 440 of 479...
  • Page 441 W1 Sequence OC setting of Seq.I>1 Enable. Note: The Sequence OC settings of W2 Sequence OC is similar to W1 Sequence OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 441 of 479...
  • Page 442 Sequence W1 OC setting of Seq.I>1 Enable. Note: The Sequence OC settings of W2 Sequence OC is similar to that W1 Sequence OC. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 442 of 479...

  • Page 443: Under Voltage

    Under Voltage Under Voltage SET Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 443 of 479...
  • Page 444 0.1 s Range 0 – 99s Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 444 of 479...

  • Page 445: Over Voltage

    Over Voltage Over Voltage SET Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 445 of 479...
  • Page 446 0.1 s Range 0 – 99s Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 446 of 479...
  • Page 447 V/Hz-3 Protection V/Hz-6 Protection Disabled Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 447 of 479...
  • Page 448 Note: The V/Hz Protection settings of V/Hz-2 Protection, V/Hz-3 Protection, V/Hz-4 Protection, V/Hz-5 Protection and V/Hz-6 Protection is similar to V/Hz-1 Protection Settings. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 448 of 479...

  • Page 449: Breaker Failure

    Key For Cancel DISCARD Settings Target Reset Note: The 50 BF settings of W2 50 BF is similar to W1 50 BF settings. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 449 of 479...
  • Page 450 DISCARD Settings Target Reset Note: The settings for 50 BF i.e. W2 50 BF will be similar to W1 50 BF Settings. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 450 of 479...
  • Page 451 Thermal Overload THOL Enable Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 451 of 479...
  • Page 452 0.05 – 4.00 xIn Range 1 – 1.5 Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 452 of 479...

  • Page 453: Through Fault

    Through Fault TF Enable Disabled Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 453 of 479...
  • Page 454 Range 0.08 to 20.0 pu Press 3 Key SAVE Settings For Save Press Target Reset Key For Cancel DISCARD Settings Target Reset Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 454 of 479...

  • Page 455: Active Group

    ADR233B 9.12 Active Group ACTIVE GROUP MEASUREMENT GLOBAL CB CONTROL ACTIVE GROUP G1/G4 Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/FC Rev No. : 05 Page No. : 455 of 479...
  • Page 456 Page Intentionally Left Blank...
  • Page 457 ADR233B Section 10 Analyzing Event and Disturbance Record Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/DR Rev No. : 05 Page No. : 457 of 479...
  • Page 458 ADR233B Contents ANALYZING EVENT AND DISTURBANCE RECORD 10.1 Overview 10.2 Event recording 10.3 Disturbance recording 10.4 Positive Sequence Over current function Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/DR Rev No. : 05 Page No. : 458 of 479...

  • Page 459: Event Recording

    10.2 Event recording ADR233B relay provides a feature to record and store 512 nos. of events (with event time stamping is with 1mSec precision) in non-volatile memory through internally by protection and control functions and externally by triggering the digital inputs. And these can be extracted using communication port or can be seen on the LCD.

  • Page 460: Disturbance Recording

    16 samples (DR of 3 seconds), user can set as required. 10.4 History Fault recording: ADR233B relay provides built in history fault recording facility for recoding the fault with the voltage, current, symmetrical components parameter value. Relay records history fault and stored in to non-volatile memory.
  • Page 461 DR analysis software. Analogue and Digital channels should be recorded with pre fault and post fault conditions. Waveform can be exported to COMTRADE format. Disturbance record: Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/DR Rev No. : 05...
  • Page 462 ADR233B Event Record: Fault History Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/DR Rev No. : 05 Page No. : 462 of 479...
  • Page 463 Page Intentionally Left Blank...

  • Page 464: Testing And Commissioning

    ADR233B Section 11 Testing and Commissioning Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 464 of 479...
  • Page 465 Through Fault Stability Check 11.4.3 Pick up and Trip Test 11.5 Testing of Binary Input 11.6 Testing of Binary Output 11.7 LED Test Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 465 of 479...

  • Page 466: Checking Of External Circuitry

    11.1 Commissioning Tests & Equipments Required The following tests help you to configure the settings in ADR233B and verify whether the relay is properly working or not. The tests are conducted to ensure whether the relay settings and logics are correct or not. The procedure can be modified as necessary to confirm to standard practices.

  • Page 467: Check Relay Settings

    It should be ensured that the CT connections are replaced in accordance with the relevant external connections or schemes Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 467 of 479...

  • Page 468: Relay Testing

    Ensure all fault & Annunciation contacts, trip contacts has been reset before disconnecting relay. If relay ADR233B is a newly installed then the trip counter of Relay should be zero while the Relay is newly installation with CB. This counter can be reset by enabling Fault record/ CB data in Clear Record Setting Menu Note: This will also clear all fault memory and the set password.
  • Page 469 O IN1 (+ / -) Input2 O3 – O4 * O IN2 (+ / -) Input3 O5 – O6 * O IN3 (+ / -) Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 469 of 479...
  • Page 470 M OUT 6 (C–NO) Output7 M13 – M14 * M OUT 7 (C–NO) Output8 M15 – M16 – M17 * M OUT 8 (C–NO–NC) Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 470 of 479...
  • Page 471 Measure the Primary current at CT terminal & Secondary current at relay CT terminal using Clamp meter/ Tong tester. • Observe & note down the primary & secondary current on Relay Measurement window. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 471 of 479...
  • Page 472 W1 Y W1 B W2 R W2 Y W2 B Id R Id Y Id B Ib R Ib Y Ib B IREF Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 472 of 479...
  • Page 473 The measured timing should be ±5% of actual timing i.e. 10.029 Sec. • Repeat the above procedure for remaining phases and Earth Fault. Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 473 of 479...
  • Page 474 ________ms ________ms Time Delay at 10 times of W13Io>1 setting ________ms ________ms Time Delay at 2 times of W23Io>1 setting ________ms ________ms Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 474 of 479...
  • Page 475 O1 – O2 * Input2 O3 – O4 * Input3 O5 – O6 * Input4 O7 – O8 * Input5 O9 – O10 * Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 475 of 479...

  • Page 476: Testing Of Binary Output

    L1 – L2 * Output2 L3 – L4 * Output3 L5 – L6 * Output4 L7 – L8 * Output5 L9 – L10 * Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 476 of 479...
  • Page 477 Apply voltage to respective Binary input so the respective LED is operated. • After that remove voltage of Binary input and respective LED is off Doc ID : ADR233B_IM_01 Ref ID : ADR233B/IM/TC Rev No. : 05 Page No. : 477 of 479...
  • Page 478 Details of E0 version added 23.12.2018 Details of B0 version added 25.11.2019 Updated as per firmware version V4.03 27.03.2021 Updated as per firmware version V5.03b Doc ID : ADR233B/IM/01 Ref ID : ADR233B/IM/RS Rev No. : 05 Page No. : 478 of 479...

  • Page 479: All Rights Reserved

    No ASHIDA trademarks may be used without written permission. The information in this document is provided for informational use only and is subject to change without legal notice. ASHIDA ELECTRONICS PVT LTD. has approved only the English language document.

Table of Contents

Save PDF
