Ashida ADR111A Instruction Manual

Single pole protection relay
Hide thumbs
Table of Contents

Advertisement

Quick Links

ADR111A / ADR211A
Single Pole Protection Relay
INSTRUCTION MANUAL
ADR111A /
ADR211A
Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/TP
Rev No.
: 04
Page No. : 1 of 127

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADR111A and is the answer not in the manual?

Questions and answers

Related Manuals for Ashida ADR111A

Summary of Contents for Ashida ADR111A

  • Page 1 ADR111A / ADR211A ADR111A / ADR211A Single Pole Protection Relay INSTRUCTION MANUAL Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/TP Rev No. : 04 Page No. : 1 of 127...
  • Page 2 ADR211A Preface The ADR111A/ ADR211A single pole Relay Instruction Manual describes common aspects of feeder protection application and use of product. It includes the necessary information to safety, install, set, test, and operate the relay functionality. The instruction manual can be used by power engineers and other experienced protective relays application persons.
  • Page 3 Qualified personnel are individuals who • Are familiar with the installation, commissioning, operation of the equipment and of the system to which it is being connected. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SGI Rev No. : 04 Page No. : 3 of 127...
  • Page 4 However, the manual cannot cover all conceivable circumstances or include detailed information on all topics. In the event of questions or specific problems, do not take any action without proper authorization. Contact the appropriate person of Ashida Technical / Sales office and request the necessary information.
  • Page 5 IP20 rating, then a suitable protective barrier should be provided. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SGI Rev No. : 04 Page No. : 5 of 127...
  • Page 6 CT shorting on removal of the module. Therefore external shorting of the CTs may not be required, but it is advisable to use external CT shorting as general practice. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SGI Rev No. : 04 Page No. : 6 of 127...
  • Page 7 The supply input (auxiliary) for the equipment may include capacitors across the supply or to earth. To avoid electric shock or energy hazards, after completely isolating the supplies to Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SGI Rev No. : 04...
  • Page 8 Equipment in this category is qualification tested at 5KV peak, 1.2/50µs, 500Ω, 0.5J, between all supply circuits and earth and also between independent circuits Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SGI Rev No. : 04 Page No. : 8 of 127...
  • Page 9 Pollution Degree 2 Compliance is demonstrated by reference to safety standards. Altitude Operation up to 2000m IEC 60255-27:2005 EN 60255-27: 2005 CE MARKING Directives: Compliance demonstrated by reference to safety standards Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SGI Rev No. : 04 Page No. : 9 of 127...
  • Page 10 Page intentionally Left Blank...
  • Page 11 USB Connection (For ADR211A only) Mechanical, Back Terminal and Electrical Connection Drawings 2.4.1 Mechanical Dimensions without IP cover 2.4.2 Mechanical Dimensions with IP cover Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/ToC Rev No. : 04 Page No. : 11 of 127...
  • Page 12 Page No. Measurement Sheet Measurement Section 6 : SETTING SHEET Sr. No. Description Page No. Setting Sheet Relay Settings Date and Time setting Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/ToC Rev No. : 04 Page No. : 12 of 127...
  • Page 13 To View – MEASUREMENT 8.2.4 Relay Settings 8.2.4.1 To Set – Relay Settings 8.2.4.2 To View – Relay Settings 8.2.5 Trip Test 8.2.6 Fault 1 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/ToC Rev No. : 04 Page No. : 13 of 127...
  • Page 14 Section 10 : ANALYZING EVENT AND DISTURBANCE RECORD Sr. No. Description Page No. Analyzing Event and fault Record 10.1 Overview 10.2 Event recording 10.3 History Fault recording Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/ToC Rev No. : 04 Page No. : 14 of 127...
  • Page 15 11.4 Relay Testing 11.4.1. Relay Calibration & Measurement 11.4.2. Pick up and Trip Test 11.4.3. Testing of Binary Output (Output Contact Test) Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/ToC Rev No. : 04 Page No. : 15 of 127...
  • Page 16 Page intentionally Left Blank...
  • Page 17 ADR111A / ADR211A Section 1 Introduction and Specifications Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 17 of 127...

  • Page 18: Table Of Contents

    ADR111A / ADR211A Contents INTRODUCTION AND SPECIFICATIONS Overview Features Applications Technical Specifications Typical Tests Information Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 18 of 127...

  • Page 19: Introduction And Specifications

    ADR211A INTRODUCTION AND SPECIFICATIONS Overview ASHIDA has designed economical & reliable Single element over current ADR111A/ ADR211A relay to simply feeder protection wiring. The simple and compact construction of ADITYA series ADR111A/ ADR211A relay provides integrated Protection, Control and Monitoring functions for feeders. This relay is mainly deployed in various electrical utilities at industrial installations for Low voltage/ Medium voltage switchgear control.

  • Page 20: Applications

    Underground cable & feeder protection. Relay designed with fast and selective tripping ensures the stability and availability of electrical power system. ADR111A/ ADR211A relay apply for protection, control & monitoring of feeder to achieve sensitivity and selectivity on phase or ground faults.

  • Page 21: Technical Specifications

    50 Watt Inductive (L/R 45ms) max. 5A or 300V Operating Time <10msec Minimum no. of 10,000 operation loaded condition & unloaded operations 100,000 operations Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 21 of 127...
  • Page 22 Use torque control screw driver with 1.2 N- m torque maximum Rear Communication Terminal Four/Two wire RS422/RS485 signal levels Suitable up to Multi core shielded Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 22 of 127...

  • Page 23: Typical Tests Information

    80 - 1000 MHz Field Disturbance (ed3) : 2013 Modulation 80% AM @ 1 KHz Test Spot Frequency 80, 160, 380, 450 & 900 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 23 of 127...
  • Page 24 Frequency Range Limits 30 MHz – 230 MHz 50 dB (µV/m) 230 MHz – 1000 MHz 57 dB (µV/m) EUT Condition Energized Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 24 of 127...
  • Page 25 : Frequency Range = 10Hz – 150Hz , acceleration. = 1gn Response Test : Sweep rate 1 octave/min; Displacement =0.075mm, in 3 orthogonal axis. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 25 of 127...
  • Page 26 : Sweep 1/Axis (@a sweep rate of 1 octave/minute) vibration in the frequency range (5-35 Hz) at displacement X-axis: 7.5mm, Y- axis: 3.5mm amplitude of 3.5mm with acceleration of X-axis: 2gn, Y-axis: 1gn. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&S Rev No. : 04 Page No. : 26 of 127...
  • Page 27 Page intentionally Left Blank...
  • Page 28 ADR111A / ADR211A Section 2 Installation and Procedure Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 28 of 127...
  • Page 29 Mechanical, Back Terminal and Electrical Connection Drawings 2.4.1 Mechanical Dimensions without IP cover 2.4.2 Mechanical Dimensions with IP cover 2.4.3 Back Terminal and Electrical connection diagrams Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 29 of 127...

  • Page 30: Instalation And Procedure

    User should carefully plan relay placement, cable connections, and relay communication. This section contains drawings of typical ac and dc connections to the ADR111A. Use these drawings as a starting point for planning your particular relay application.

  • Page 31: Storing The Goods

    Installation Procedure 2.3.1 Safe Mounting ADR111A/ ADR211A supports flush panel mounting and can be mounted into panels using fitting clamps with M4 X 12 screws. The Protective cover and M4 X 25 screws (optional) are supplied along with the relay.
  • Page 32 After inserting the Relay in the Panel fasten the relay to the Panel as shown below. Figure 2: Fastening Relay to the panel Caution: Always use M4x12 screws for Relay fitting. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 32 of 127...
  • Page 33 After mounting the cover on relay front panel, fasten the cover fitting screw, as shown below Figure 4: Relay mounted on the panel-front view Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 33 of 127...

  • Page 34: Relay Connection And Diagram

    Current rating of external wiring, applicable as per application. 2.3.3 Relay Operating Condition The equipment should be operated within the specified electrical and environmental limits. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 34 of 127...

  • Page 35: Current Transformer (Ct) Circuit

    The terminal blocks used for ADR111A/ ADR211A relay are as shown below. The terminal block of ADR111A/ ADR211A consists of up to 18 x M4 screw terminals. M4 terminal blocks are used for CT connections, auxiliary power, output contact and rear serial port connections.

  • Page 36: Rear Serial Port Connection (For Adr211A Only)

    There is no electrical connection of the cable screen to the device. The link is provided purely to link together the two cable screens. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 36 of 127...

  • Page 37: Power Supply Connections

    This could be achieved in several ways, including placing a nickel-plated or insulating washer between the conductor and the product case, or using tinned ring terminals. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 37 of 127...

  • Page 38: Current Transformers

    B at other end) can be used to connect a local PC to the IED. This cable is the same as that used for connecting a printer to a PC. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04...

  • Page 39: Mechanical, Back Terminal And Electrical Connection Drawings

    Mechanical, Back Terminal and Electrical Connection Drawings 2.4.1 Mechanical Dimensions without IP cover Figure 7: Case dimensions for basic version without IP cover Note: All dimensions in mm. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 39 of 127...

  • Page 40: Mechanical Dimensions With Ip Cover

    ADR211A 2.4.2 Mechanical Dimensions with IP cover Figure 8: Case dimensions for basic version with IP cover Note: All dimensions in mm. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 40 of 127...

  • Page 41: Back Terminal And Electrical Connection Diagrams

    ADR111A / ADR211A 2.4.3 Back Terminal and Electrical connection diagrams Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/I&P Rev No. : 04 Page No. : 41 of 127...
  • Page 42 Page intentionally Left Blank...
  • Page 43 ADR111A / ADR211A Section 3 PC Software Information Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No. : 04 Page No. : 43 of 127...
  • Page 44 ADR211A IED Main Screen 3.3.1 Parameter Display 3.3.2 IEDs Din Display 3.3.3 Control Operation 3.3.4 Private Setting 3.3.5 Bank Settings 3.3.6 History Fault Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No. : 04 Page No. : 44 of 127...
  • Page 45 Control Provides the control function tool (output, input, LED) NOTE: The above features are generally provided with all the ASHIDA Relays but the * marked features are not applicable to this product Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No.
  • Page 46 ADR111A / ADR211A Relay Talk software Following is a brief step-by-step instruction to download relay data using ASHIDA Relay Talk software • Start Relay Talk program from program menu Following is the main screen of Relay talk system. Figure 1: Main screen of Relay talk system For successful communication, setting of relay should match with software settings.
  • Page 47 Now, press the IED button. Figure 3: IED Setting Now press the Load IED button, the display will show following IED Main screen. Figure 4: IED main screen Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No. : 04...
  • Page 48 Auxiliary Status This is used to view the input status received by the relay Parameter Display This is used to view the parameters of current. Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No. : 04 Page No. : 48 of 127...
  • Page 49 3.3.3 Control Operation The IEDs Controls are listed in the list and depending on their type either pulse or latch the control operation Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No. : 04 Page No. : 49 of 127...
  • Page 50 These settings for IEDs are display along with their current values and expected values. Fig. 9: Private Setting 3.3.5 Bank Settings This window is to set/ to read Bank settings. Figure 10: Bank Setting Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No. : 04 Page No. : 50 of 127...
  • Page 51 To refresh all windows and parameters Clear To clear the screen Save To save the fault data in history fault Close To close the History fault window Doc ID: ADR111A _IM_01 Ref ID: ADR111A /IM/PC-SI Rev No. : 04 Page No. : 51 of 127...
  • Page 52 Page intentionally Left Blank...
  • Page 53 ADR111A / ADR211A Section 4 Protection and Logic Function Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 53 of 127...
  • Page 54 ADR111A / ADR211A Contents PROTECTION FUNCTION & LOGIC FUNCTIONS Overview Application Data Relay Settings Phase/Ground Over current Element (50/50N/51/51N) IDMT Characteristics Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 54 of 127...

  • Page 55: Protection Function & Logic Functions

    ADR211A PROTECTION FUNCTION & LOGIC FUNCTIONS Overview This section describes the ADR111A/ ADR211A Single Pole IED settings, including the protection elements and basic functions associated with the protection function. Application data. Describes the list of information that you will need to know about the protected equipment before calculating the relay settings.

  • Page 56: Phase/Ground Over Current Element (50/50N/51/51N)

    Phase/Ground Over current Element (50/50N/51/51N) The ADR111A/ ADR211A has one sensing element. Due to which the same relay can be used for OC/ EF/ REF application. The Over-current function operates for a set value of current with time delay (IDMT/DT). This function provided with two stages, Where Stage 1 (I>1) can be programmed as IDMT or...

  • Page 57: Idmt Characteristics

    Delay parameter settings. After all the above condition are satisfied, the IED generates the over current trip. IDMT Characteristics ADR111A/ ADR211A relay provides following inverse time over current characteristics • Normal Inverse 1 Curve (C1) for 3s • Normal Inverse 2 Curve (C2) for 1.3s •...
  • Page 58 TMS = 0.6 TMS = 0.7 TMS = 0.8 TMS = 0.9 1.000 TMS = 1.0 1.000 10.000 0.100 Current in Ampere Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 58 of 127...
  • Page 59 TMS = 0.5 10.0 TMS = 0.6 TMS = 0.7 TMS = 0.8 TMS = 0.9 TMS = 1.0 Current in Ampere Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 59 of 127...
  • Page 60 1.000 10.000 TMS = 0.6 TMS = 0.7 TMS = 0.8 TMS = 0.9 TMS = 1.0 0.100 0.010 Current in Ampere Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 60 of 127...
  • Page 61 TMS = 0.6 TMS = 0.7 1.000 TMS = 0.8 1.000 10.000 TMS = 0.9 TMS = 1.0 0.100 0.010 Current in Ampere Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 61 of 127...
  • Page 62 1.000 10.000 TMS = 0.6 TMS = 0.7 TMS = 0.8 TMS = 0.9 TMS = 1.0 0.100 0.010 Current in Ampere Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 62 of 127...
  • Page 63 TMS = 0.6 TMS = 0.7 TMS = 0.8 TMS = 0.9 TMS = 1.0 1.000 1.000 10.000 0.100 Current in Ampere Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/PLF Rev No. : 04 Page No. : 63 of 127...
  • Page 64 Page intentionally Left Blank...
  • Page 65 ADR111A / ADR211A Section 5 Metering Section Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/MS Rev No. : 04 Page No. : 65 of 127...
  • Page 66 ADR111A / ADR211A Contents MEASUREMENT SHEET Measurement Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/MS Rev No. : 04 Page No. : 66 of 127...
  • Page 67 Measurement window displays the value of Primary Current and Secondary current based on the power system network. Parameter Unit Description I =0000.00 Primary current i =0000.00 Secondary current Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/MS Rev No. : 04 Page No. : 67 of 127...
  • Page 68 Page intentionally Left Blank...
  • Page 69 ADR111A / ADR211A Section 6 Setting Sheet Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SS Rev No. : 04 Page No. : 69 of 127...
  • Page 70 ADR111A / ADR211A Contents SETTING SHEET Relay Settings Date and Time setting Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SS Rev No. : 04 Page No. : 70 of 127...
  • Page 71 This setting specifies to BF contact can be set to Manual/Hand reset (HR) or Self reset (SR) Com Port FRONT FRONT/REAR This setting specifies to select communication port for 103 communications. Parity None None/Even/Odd Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SS Rev No. : 04 Page No. : 71 of 127...
  • Page 72 Month needed when relay is not connected to SCADA system SET Year 00 – 99 Years in step of 1. Year needed when relay is not connected to SCADA system Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/SS Rev No. : 04 Page No. : 72 of 127...
  • Page 73 Page intentionally Left Blank...
  • Page 74 ADR111A / ADR211A Section 7 Communication (Applicable to ADR211A Only) Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 74 of 127...
  • Page 75 Physical Connection and Link Layer Initialisation Time Synchronisation Spontaneous Events General Interrogation (GI) Cyclic Measurements Commands 7.10 Configuration 7.11 IEC-103 Protocol Mapping Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 75 of 127...
  • Page 76 1x addresses Read Holding Registers 4x addresses Read Input Registers 3x addresses Force Single Coil 0x addresses Preset Multiple Registers 4x addresses Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 76 of 127...

  • Page 77: Exception Codes Generated In Case Of An Error

    Num Controls (c) 16 bit 4x00259 Num Parameters 16 bit 4x00260 Num Faults (f) 16 bit 4x00261 Inverted IEC 870-5-4 CP56Time2a Format Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 77 of 127...
  • Page 78 ADR111A / ADR211A Time Synchronization – For ASHIDA RTV2 IEDs on Modbus, time synchronization is possible via a broad cast command to 800H (4x02049 through 4x02052). The format is Inverted IEC 870-5-4 CP56Time2a. Words Year 00….99 Month Week Day of Month 1...12...
  • Page 79 0x33025 LED Reset 16 bit 0x33026 Function Register No. of Format Reg. Address Code Regs Type Parameters 32 bit 3x33281- Float 3x33282 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 79 of 127...

  • Page 80: Physical Connection And Link Layer

    The relay will also produce a power up event, when the relay is powered up. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 80 of 127...
  • Page 81 A list of the supported commands is contained in the Menu database. The device will respond to other commands with ASDU 1, with a cause of transmission (COT) indicating ‘negative acknowledgement’. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 81 of 127...
  • Page 82 I in MEA format 2, 7 NOTE: The measurands transmitted by the relay are sent as a proportion of 1.2 times of the rated value Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 82 of 127...
  • Page 83 Initialization of general interrogation Time synchronization Sr. No. Description Semantics of INFORMATION NUMBER : General commands in control direction LED Reset Trip relay Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/CS Rev No. : 04 Page No. : 83 of 127...
  • Page 84 Page intentionally Left Blank...
  • Page 85 ADR111A / ADR211A Section 8 User Guide Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 85 of 127...
  • Page 86 To View – STATUS 8.2.9 DATE AND TIME SETTINGS 8.2.9.1 To Set – DATE AND TIME Settings 8.2.9.2 To View – DATE AND TIME Settings Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 86 of 127...

  • Page 87: User Guide

    HR type when TRIP contact selected as HR ◄ : Feather Touch Key Left arrow Key [] for navigating through the menus and submenus and save settings. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 87 of 127...

  • Page 88: User Interface

    This key is interlocked with LED RESET key. This is normally required during firmware update of relay. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 88 of 127...

  • Page 89: Rs422 / Rs485 Port (For Adr211A)

    NOTE: At the time of setting if changes are not carried within 100s then the display will reset itself and return to the main menu. 8.1.3 LEDs The ADR111A/ ADR211A Relay is having 4 dual colour LED’s of high intensity for easy identification of type of fault for easy user interface. Function ON / : Green LED indicates Relay OK.

  • Page 90: Menus

    After the Power ON or when the H/W. RESET + LED RESET key is pressed, the relay will display the following message. This window will flash momentarily showing the following. Ashida Digital Relay Name : Ashida Digital Relay Relay Then the control will automatically move to next option. This window will flash momentarily showing the following.
  • Page 91 Press the Plus / Up arrow key (+ /) to move to the next option. To view “Status” Status Press the Plus / Up arrow key (+ /) to move to the next option. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 91 of 127...

  • Page 92: Measurement

    This window shows actual Secondary load current as per the i = 000.00 CT Secondary selection. Press the Right arrow key () to move to the next option. MEASUREMENTS Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 92 of 127...

  • Page 93: Relay Settings

    By using the Plus / Up arrow key (+ /) or the Minus / Down Range 5 – 250% arrow key (- /) the desired I> can be set. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 93 of 127...
  • Page 94 C5 = Long Time Inverse (10 Times 13.3 sec) C6 = Definite Time (Inst. to 99.9 sec) Press the left arrow Key () to move to the next option. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 94 of 127...
  • Page 95 The Setting Range is from 10 to 5000A in steps of 1A. (For example suppose CT Ratio is 500/1A then you have to select Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 95 of 127...
  • Page 96 By using the Plus / Up arrow key (+ /) or the Minus / Down Range 1 – 5 arrow key (- /) the desired Baud Rate can be set. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 96 of 127...

  • Page 97: To View - Relay Settings

    This window shows the set Unit ID. Unit ID = 001 Press the right arrow key () to move to the next option. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 97 of 127...
  • Page 98 This window shows the set Harmonic Restrain Function. Hrm. Rst. = 000% Press the right arrow key () to move to the Main Menu. Relay Settings Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 98 of 127...

  • Page 99: Trip Test

    Ampere i.e. 9999A and If Fault current is ≥ 10000 then display will show the current in Kilo Ampere i.e. 10.00K Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 99 of 127...

  • Page 100: To View Error Log

    “Error Log” menu. This feature is very useful for giving pre information to avoid mal operation. Following are some of Error codes: - Error Code Description Setting Error EEPROM Error RTC Error Crystal Error Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 100 of 127...

  • Page 101: Status

    (+ /) or the down arrow key (- /). Note: Default password setting is ‘0000’ Press the left arrow Key () to move to the next option. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 101 of 127...
  • Page 102 The setting range is from 1 to 12 in steps of 1. Press the left arrow Key () to move to the next option. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 102 of 127...

  • Page 103: To View - Date And Time Settings

    Press the Right arrow key () to move to the next option. Time : 15:20:25 Date : 02/06/16 Press the Right arrow key () to return to the Main Menu. DATE AND TIME Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/UG Rev No. : 04 Page No. : 103 of 127...
  • Page 104 Page intentionally Left Blank...
  • Page 105 ADR111A / ADR211A Section 9 Flow Chart Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 105 of 127...
  • Page 106 To View – Status Flow Chart – Date and Time 9.8.1 To Set – Date and Time 9.8.2 To View – Date and Time Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 106 of 127...
  • Page 107 = 000.00 MEASUREMENT Relay Settings Trip Test Fault 5 Fault 1 Error Log Fault 2 Status Fault 3 DATE / TIME Fault 4 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 107 of 127...

  • Page 108: Flow Chart - Measurement

    ADR111A / ADR211A Flow Chart – Measurement 9.2.1 To View – Measurement MEASUREMENTS I = 0000A i = 000.00 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 108 of 127...

  • Page 109: Flow Chart - Relay Setting

    Com Port = FRONT Range C1 – C6 FRONT/REAR I>C6 Time = 00.1 Parity = None Range 00 – 99.9 S None/Even/Odd Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 109 of 127...

  • Page 110: To View - Relay Setting

    Hrm. Rst. = 000% I>> Delay = 00.05 CT Sec. = 01A CT Pri. = 0010A Trip Cont = HR BF Cont = HR Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 110 of 127...

  • Page 111: Flow Chart - Trip Test

    9.4.1 To Set – Trip Test Trip Test Password = 0000 Use Inr / Dec I>> : TC:0000 I> : FAULT 1 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 111 of 127...

  • Page 112: Flow Chart - Fault

    = 000.00 02/06/16 14:32:51:085 Flow Chart – Error Log 9.6.1 To View – Error Log Error Log Error Code : 0000 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 112 of 127...

  • Page 113: Flow Chart - Status

    ADR111A / ADR211A Flow Chart – Status 9.7.1 To View – Status STATUS SWV : 02.00 HWV : 02.00 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 113 of 127...

  • Page 114: Flow Chart - Date And Time

    SET Date = 002 Range 1 – 31 9.8.2 To View – Date and Time DATE AND TIME Time : 15:20:25 Date : 02/06/16 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/FC Rev No. : 04 Page No. : 114 of 127...
  • Page 115 Page intentionally Left Blank...
  • Page 116 ADR111A / ADR211A Section 10 Analyzing Events and Fault Record Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/DR Rev No. : 04 Page No. : 116 of 127...
  • Page 117 ADR111A / ADR211A Contents ANALYZING EVENT AND FAULT RECORD 10.1 Overview 10.2 Event recording 10.3 History Fault recording Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/DR Rev No. : 04 Page No. : 117 of 127...
  • Page 118 ADR211A relay is provides built in history fault recording facility for recoding the fault with the current, symmetrical components parameter value. Relay records history fault and stored in to non-volatile memory. Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/DR Rev No. : 04 Page No. : 118 of 127...
  • Page 119 ADR111A / ADR211A Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/DR Rev No. : 04 Page No. : 119 of 127...
  • Page 120 Page intentionally Left Blank...
  • Page 121 ADR111A / ADR211A Section 11 Testing and Commissioning Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/TC Rev No. : 04 Page No. : 121 of 127...
  • Page 122 11.4 Relay Testing 11.4.1. Relay Calibration & Measurement 11.4.2. Pick up and Trip Test 11.4.3. Testing of Binary Output (Output Contact Test) Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/TC Rev No. : 04 Page No. : 122 of 127...

  • Page 123: Testing And Commissioning

    11.1 Commissioning Test, Equipment Required The following connection tests help you enter settings into the ADR111A/ ADR211A and verify that the relay is properly connected. Brief functional tests ensure that the relay settings are correct. It is unnecessary to test every element, timer, and function in these tests.

  • Page 124: Check Relay Setting

    Ensure all fault & trip contacts have been reset before leaving relay. If relay ADR111A/ ADR211A is a newly installed or the CB has been just maintained the trip counter of Relay should be zero. This counter can be reset by loading Default Setting Note: This will also clear all fault memory and the set password.

  • Page 125: Relay Testing

    11.4 Relay Testing 11.4.1. Relay Calibration & Measurement Before conducting actual test, confirm relay calibration by following method. Connect ADR111A/ ADR211A relay to current injector and timer. Following chart shows terminal numbers of connections. Source Terminal Relay Terminal Relay Connection A1 –...

  • Page 126: Testing Of Binary Output (Output Contact Test)

    Again check the continuity in between NO and C output contact terminal. Binary Output Terminals Binary Output A9 – A10 TRIP A11 – A12 ALARM A13 – A14 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/TC Rev No. : 04 Page No. : 126 of 127...
  • Page 127 Note Applicable only for ADR211A is added – Sec 7 • C4A curve Graph is added – Sec 4 27.06.2016 Mechanical Drawing for IP cover added 25.11.2016 Doc ID : ADR111A_IM_01 Ref ID : ADR111A/IM/RS Rev No. : 04 Page No. : 127 of 127...
