Produal Proxima WTR24 Quick Start Manual

Produal Proxima
®
Produal Proxima
temperature, humidity and CO
setpoint knob, and occupancy detection. The transmitters require 24 V supply voltage. Transmitters are
compatible with the Produal Proxima
The information is transmitted to the base unit according to the base unit poll interval. Data may be
additionally transmitted using change-of-value (COV) based transmission. COV means that the data
is sent to base station after the value has changed enough. If COV based transmission is used, the
required value change must be configured with Produal MyTool
The wireless network needs one base unit. Commissioning is done by using Produal MyTool
phone application.
Technical specifications
Property
Supply
Wireless network properties
Frequency
Maximum transmit power
(E.I.R.P)
Bandwidth
Modulation
Network range (maximum
distance between devices)
Temperature measurement
Range
Accuracy
Accuracy (CO2 models)
Humidity measurement (RH
models)
Range
Accuracy (25 °C)
CO measurement (CO2
2
models)
Range
Accuracy
Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com
Published: 02.11.2023
WTR24 - wireless room transmitter
®
WTR24 externally powered wireless transmitters are for detecting indoor
level. The transmitters can also be equipped with a display, advanced
2
®
MESH wireless network.
Value
24 Vac/dc (22...28 V), <2 VA
2.4 GHz (2400...2483.5 MHz)
4 mW (6 dBm)
2000 kHz
GFSK
up to 100 m in the line of sight, typically 10...20 m inside buildings
Note: The maximum distance between devices depends on the
installation environment.
0...50 °C
typically ±0.2 °C, max ±0.4 °C (3σ)
±1 °C
0...100 %rH
typ. ±2 %rH (10...90 %rH), max. ±5 %rH
0...2000 ppm
typ. ±40 ppm ±3 % of value
Information is subject to change without prior notice.
®
.
1 (6)
