Produal TEUFL Series User Manual

COMMISSIONING

Wiring

TEUFL and TEUFL-24

Connecting the transmitter to the wireless network

The FLSER commissioning tool is needed for transmitter commissioning.
1.
2.
3.
4.
5.
6.
Produal Oy Keltakalliontie 18, 48770 Kotka FINLAND
Device wiring and commissioning can only be carried out by qualified professionals. Always make the
wirings while the power is switched off.
P
5 6 1 2 3 4
+
Disconnect the transmitter power supply (battery / 24 V supply).
Set the FLSER tool switch to the MID position.
Push the + and - buttons to select the FLTA base station master ID (MID) to which you are connecting the
transmitter.
6
MID=
Push the OK button.
Set the FLSER tool switch to the S-RID position.
Push the + and - buttons to select the sensor ID (SID) for the transmitter.
8
SID=
Tel: +358 10 219 9100 / Fax: +358 5 230 9210
Information is subject to change without prior notice.
TEUFL-DI
B battery (TEUFL and TEUFL-DI)
P potentiometer for setting the transmission interval
(6 s...30 min)
B
L indicator light
- in in
L
USER GUIDE
TEUFL
V2.2 (05.12.2014)
info@produal.fi www.produal.com
1 (2)
