RTX - Room
transmitter
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTX and is the answer not in the manual?

Questions and answers

Related Manuals for Produal RTX

Summary of Contents for Produal RTX

  • Page 1 RTX - Room transmitter USER GUIDE...

  • Page 2: Table Of Contents

    6.3 Modbus registers........................38 6.3.1 Input registers.........................38 6.3.2 Holding registers......................41 7 Disposal................55 Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 3: Introduction

    These transmitters are intended to be connected to building automation systems in the HVAC/R industry. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 4: Safety Precautions

    These notes also provide information that is useful but not critical to the user. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice.

  • Page 5: Main Components

    Connect dongle connector Indicator light (-L models) Occupancy sensor lens (-PIR models) Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 6: Functional Description

    VOC (-VOC models) level. You can define the dead zones for control. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 7: Maximum Selection Control

    4.6 Indicator lights The -L models have an indicator light on the cover. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 8 CAUTION: When the power supply is connected, be extra careful when handling the product without the cover. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 9: Commissioning

    CAUTION: The product may only be connected to overvoltage category I, II or III electricity network according to IEC  60664‑1. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 10: Configuring Transmitter Using The Myprodual ® Application

    Note: You can also power the device by connecting a USB cable to the MyTool ® Connect dongle. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 11 7. Tap the Configuration button. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 12 See the following chapters for more information about the settings. 9. Make the changes to the configuration. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 13: Configuring Measurement Settings

    Tap the Component setup button on the Configuration page to open the Component setup page. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 14 Contact o level condition is fulfilled. Advanced settings. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 15 The following parameters are available for configuration: Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 16 Shown if Oset is selected in Measurement correction. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 17 Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 18 20  ppm. Shown if Span is selected in Measurement correction. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 19 Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 20 40  µg/m³. Shown if Span is selected in the Measurement correction parameter. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 21 0.00 % The start value for manual overdrive of value measurement. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 22 Shown if Digital input is selected in the Input type field. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 23: Configuring Controller Settings

    The available parameters depend on the selected controller type. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 24 Cooling stops when the temperature is again at the setpoint value. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 25 Humidification (HUM) or HUM + DEHUM is selected in the Controller mode parameter. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 26 Bus / Fixed setpoint is selected in the Setpoint input parameter. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 27 150...2000 µg/m³ 1000 µg/m³ Set the control range for ventilation. ventilation (P) Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 28 (pipe temperature). Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 29: Configuring Output Settings

    The following output types are available: O Not in use. Analog Analogue output. Digital Digital output. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 30 CO₂ contact VOC contact PIR contact Condensation contact External input contact Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 31 CO₂ contact VOC contact PIR contact Condensation contact External input contact Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 32 Brightness 1...100 % 50 % Indicator light brightness. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 33 Limit for changing the indicator light colour from yellow limit green to yellow. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 34 Cyan Purple White Brightness 1...100 % 50 % Indicator light brightness. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 35: Saving And Uploading Configurations

    5. Select the settings you want to import in the Import settings popup. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 36: Updating Device Firmware

    6. Tap the Ok button in the firmware update completion dialog. 7. Tap the Close button. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 37 37 (55) 8. Tap the connection info button to disconnect the device. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 38: Modbus

    -1000.0...1000.0 °C Relative humidity measurement. 0...100 0...100 % measurement. 0...10000 0...10000 ppm Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 39 Dew point (°F). -17680…18320 -1768.0…1832.0 °F Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 40 1. On Output 3 contact. 0 - 1 0. O 1. On Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 41: Holding Registers

    0...1440 0 = override disabled, 1...1440 = override enabled in minutes Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 42 0.00...100.00  % Relay status. 0 - 1 0. O 1. On Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 43 1...247 Modbus broadcast status. 0 - 1 0. Disabled 1. Enabled Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 44 VOC limit for change from yellow 0...10000 0...10000 µg/m 1500 to red. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 45 Measured temperature, point 1. -10000...10000 -1000.0...1000.0 °C Corrected temperature, point 1. -10000...10000 -1000.0...1000.0 °C Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 46 1...60 60...3600 multiplier. contact, on level. 0...10000 0...10000 ppm 1200 Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 47 Corrected VOC, point 1. 0...10000 0...10000 µg/m Measured VOC, point 2. 0...10000 0...10000 µg/m Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 48 7. CO transmitter 8. VOC transmitter 9. Potentiometer 10. Digital input Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 49 2. Relative humidity 3. CO 4. VOC 5. Maximum selection control Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 50 Humidity control integration time, 0...5000 0 = use common value, dehumidification. 1...5000  s Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 51 Not in use. 2141 VOC control range. 150...2000 150...2000 µg/m 1000 Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 52 Controller primary output Controller secondary output 6. External input 7. Bus Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 53 Bus control start value. 0 - 1 0. O 1. On Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
  • Page 54 5. Occupancy contact 6. Condensation alarm 7. External input contact 8. Bus Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...

  • Page 55: Disposal

    Produal distributor for further information on environmental aspects and recycling instructions for professional recyclers. Produal Oy | Keltakalliontie 18, FI 48770 Kotka, Finland | tel. +358 10 219 9100 | info@produal.com | Information is subject to change without prior notice. EN - 53011W0000ug...
