Pro's Kit MT-8004 User Manual

MT-8004 Telephone Line Tester
User manual
st
1 Edition, 2024
©2024 Copy Right by Prokit's Industries Co., Ltd.
Thank you for purchasing the MT-8004 Telephone Line
tester. This tester has the function of automatically detecting
FSK and DTMF call information, super lightning protection
and so on. It can meet the requirement of all kinds of switch
phones both at home and abroad. As this phone has many
functions, It looks beautiful and small in appearance and
easy to carry and use ,so please read the Instruction Manual
carefully before you use it.
I. Features:
1. FSK and DTMF caller ID display, automatic detection.
2. Backlight: Adjustable brightness.
3. Redial, callback, Flashing function.
4. Overvoltage protection.
5. 16 groups of outgoing call storage.
6. 62 groups of dynamic call storage.
7. 32-bit pre-dialing and error correction function.
8. Tone or Pulse dial mode select, suitable for different
type telephone systems.
II. User instructions
1. The preparation before using
Put the plug of the arranged phone line insert into the
outlet of the phone tester and put the other end in
external wire. Then the screen shows the initial time, and
the phone is in available.
2. Exterior line quality
This check phone is like cordless phone, if you need to
check the landline number, press the switch to dial your
own phone or other phone number to query the
landline number, and use with alligator clips to query
when checking telephone exchange room, which is
convenient and simple.
3. Internal line query
According to the instructions from the switch, the tester
can automatically receive call back and then check the
internal line.
4. Dial and call operation
To answer the phone call: Make the phone hang up.
Answer the phone directly by press the "ON/OFF"
button when hear the ring. Directly press the
"ON/OFF" button, call when hear the dial tone. The
dial number shows in the screen. Talking can begin
when connected and hang up when finish.
You can choose Tone or Pulse dialing through the
"T/P" switch. T—Tone dialing; P—Pulse dialing.
5. Flash function
The user can use the phone tester to dial two phone
number at the same time.
Using the phone tester to dial the user A number, during
the call, press the "FLASH" button, after hearing dial
tone, dial the user B number to have a call; if fail to call,
press the "FLASH" button to continue calling with the
user A.
III. Set up the system
