Pro's Kit MT-7801-FC User Manual

Optical laser source
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Optical Laser Source
MT-7801-FC/MT-7802-FC/MT-7803-FC
English
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT-7801-FC and is the answer not in the manual?

Questions and answers

Related Manuals for Pro's Kit MT-7801-FC

Summary of Contents for Pro's Kit MT-7801-FC

  • Page 1 Optical Laser Source MT-7801-FC/MT-7802-FC/MT-7803-FC English English...
  • Page 3 Optical Laser Source MT-7801-FC/MT-7802-FC/MT-7803-FC English English...

  • Page 4: Warning And Note

    WARNING WARNING VISIBLE LASER RADIATION VISIBLE LASER RADIATION AVOD EYE OR SKIN EXPOSURE AVOD EYE OR SKIN EXPOSURE You are cautioned that changes or modifications not espressly approved in this document TO DIRECT OR SCATTERED RADIATION TO DIRECT OR SCATTERED RADIATION SEMICONDUCTOR LASER SEMICONDUCTOR LASER could void yout authority to operate this equipment.

  • Page 5: Table Of Contents

    Contents 1. Warning and Note 2. Accessories 3. Product presentation 3.1 Description 3.2 Install the battery 3.2 On/off and permanent on 3.3 Backlight function 3.4 Select wavelength 3.5 Modulation wave output 3.6 Wavelength identification 3.7 Battery energy Indicator 3.8 Battery charge 3.9 Maintenance and solution 3.10 Detail parameter...

  • Page 6: Accessories

    Check the accessories Standard Edition PERM Set >2s OFF Optical Laser Source MT-7801-FC/MT-7802-FC/MT-7803-FC MT-7801-FC MT-7801-FC English Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm Host Damping Jacket User's Guide Packet Optional 2x AA LR6 1.5V or rechargeable battery...

  • Page 7: Product Presentation

    Description Fiber optic adapter Charging Socket PERM Set Power Button >2s OFF Wavelength ID Output wavelength switch button Load modulation frequency MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...

  • Page 8: Install The Battery

    Installing the battery 1.Pull the battery cover 2.Installing the battery 3.Push the battery cover 4.Complete...

  • Page 9: On/Off And Permanent On

    If you need to shield this function and enable the meter keeps PERM Set >2s OFF on working, only need to press the button and hold when you MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm boot the instrument.

  • Page 10: Backlight Function

    >2s OFF button, you can control the backlight function on or off. The backlight function is used when you want to use the meter at night or darker occasions. MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm...

  • Page 11: Select Wavelength

    >2s OFF the required output wavelengths. Details refer to the parameters table. The power meter or other measuring equipments should correspond the wavelength of the light source. MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm...

  • Page 12: Modulation Wave Output

    PERM Set >2s OFF confirmed carrier frequency in the current output laser. This instrument has three carrier frequencies for selecting: 270Hz, 1KHz,2KHz. MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...

  • Page 13: Wavelength Identification

    'ld'. When connect with the power meter supporting wavelength recognition function, it can show the current output wavelength of light source, and switch to measure the wavelength MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source...

  • Page 14: Battery Energy Indicator

    Four levels indication of power detection Represents the remaining 80%---100% electricity PERM Set >2s OFF Represents the remaining 40%---80% electricity Represents the remaining 20%---40% electricity MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...

  • Page 15: Battery Charge

    If you do not stop recharging at this time, the in strument will continue the trickle charge state, using small current to supply natural discharge. But this MT-7801-FC MT-7801-FC process is not more than 48 hours.

  • Page 16: Maintenance And Solution

    Meter Maintenance and Solution General maintenance Optical fiber connect the adapter should avoid contacting with hard objects and keep clean. Should be stored in a dry and ventilated place to avoid moisture. When un use for long time,should remove the batteries before storage. Fault and solution Solution Failure name...

  • Page 17: Detail Parameter

    Detail Parameters MT-7801-FC MT-7802-FC MT-7803-FC Wave source type 1310nm/1550nm@FP 1490nm@DFB Wavelength 1310nm/1550nm(SM) 850nm/1300nm(MM) 1310nm/1490nm/1550nm(SM) >-5dBm Output power >-10dBm >-5dBm Optical connector FC/PC 0.05dBm/1 hour 0.1dBm/8 hour Stability Modulation wave 270Hz 1KHz 2KHz Auto off 10 min can be cancelled Low batter y warning...
  • Page 19 Optical Laser Source MT-7801-FC/MT-7802-FC/MT-7803-FC...
  • Page 20 VISIBLE LASER RADIATION VISIBLE LASER RADIATION AVOD EYE OR SKIN EXPOSURE AVOD EYE OR SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION TO DIRECT OR SCATTERED RADIATION SEMICONDUCTOR LASER SEMICONDUCTOR LASER Wavelength:635-650nm Wavelength:635-650nm INVISIBLE LASER RADIATION INVISIBLE LASER RADIATION AVOD EYE OR SKIN EXPOSURE AVOD EYE OR SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION TO DIRECT OR SCATTERED RADIATION...
  • Page 22 PERM Set >2s OFF Optical Laser Source MT-7801-FC/MT-7802-FC/MT-7803-FC MT-7801-FC MT-7801-FC English Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm 2x AA LR6 1.5V...
  • Page 23 PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 25 PERM Set >2s OFF PERM Set >2s OFF PERM Set >2s OFF PERM Set >2s OFF PERM MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 26 PERM Set >2s OFF PERM Set >2s OFF PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 27 PERM Set >2s OFF PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 28 PERM Set >2s OFF PERM Set >2s OFF 270Hz, 1KHz, 2KHz MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 29 PERM Set >2s OFF PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 30 80%---100% PERM Set >2s OFF 40%---80% 20%---40% MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 31 5V_500mA PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 33 MT-7801-FC MT-7802-FC MT-7803-FC 1310nm/1550nm@FP 1490nm@DFB 1310nm/1550nm 850nm/1300nm 1310nm/1490nm/1550nm >-5dBm >-10dBm >-5dBm FC/PC 0.05dBm/1 0.1dBm/8 270Hz 1KHz 2KHz -20 ~+70 <90%RH -10 ~+60 <90%RH AA/LR6 1.5V X2 PCS 165mm*80mm*35mm 280g...
  • Page 35 Optical Laser Source MT-7801-FC/MT-7802-FC/MT-7803-FC...
  • Page 36 VISIBLE LASER RADIATION VISIBLE LASER RADIATION AVOD EYE OR SKIN EXPOSURE AVOD EYE OR SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION TO DIRECT OR SCATTERED RADIATION SEMICONDUCTOR LASER SEMICONDUCTOR LASER Wavelength:635-650nm Wavelength:635-650nm INVISIBLE LASER RADIATION INVISIBLE LASER RADIATION AVOD EYE OR SKIN EXPOSURE AVOD EYE OR SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION TO DIRECT OR SCATTERED RADIATION...
  • Page 37 3.10...
  • Page 38 PERM Set >2s OFF Optical Laser Source MT-7801-FC/MT-7802-FC/MT-7803-FC MT-7801-FC MT-7801-FC English Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm 2x AA LR6 1.5V...
  • Page 39 PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 41 PERM Set >2s OFF PERM Set >2s OFF PERM Set >2s OFF PERM Set >2s OFF PERM MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 42 PERM Set >2s OFF PERM Set >2s OFF PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 43 PERM Set >2s OFF PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 44 PERM Set >2s OFF PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 45 PERM Set >2s OFF PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 46 80%---100% PERM Set >2s OFF 40%---80% 20%---40% MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 47 5V_500mA PERM Set >2s OFF MT-7801-FC MT-7801-FC Fiber Optical Light Source Fiber Optical Light Source Wavelength:1310nm / 1550nm Wavelength:1310nm / 1550nm...
  • Page 49 MT-7801-FC MT-7802-FC MT-7803-FC 1310nm/1550nm@FP 1490nm@DFB 1310nm/1550nm 850nm/1300nm 1310nm/1490nm/1550nm >-5dBm >-10dBm >-5dBm FC/PC 0.05dBm/1 0.1dBm/8 270Hz 1KHz 2KHz >40 -20 ~+70 <90%RH -10 ~+60 <90%RH AA/LR6 1.5V X2 PCS 165mm*80mm*35mm 280g...
  • Page 52 PROKIT'S INDUSTRIES CO.,LTD http://www.prokits.com.tw Email: pk@mail.prokits.com.tw ã 2020 Prokit's Industries Co., LTD. All rights reserved 2020001(C)

This manual is also suitable for:

Mt-7802-fcMt-7803-fc
