- Page 1 R410A REFRIGERANT INVERTER AIR CONDITIONER Wall mounted type DESIGN & TECHNICAL MANUAL For Extra Cold Climate Area INDOOR UIWH09AHWJ UIWH12AHWJ UIWH15AHWJ OUTDOOR ROSH09AHHJ ROSH12AHHJ ROSH15AHHJ DR_AS075ED_02 2020.10.16...
- Page 2 Notices: • Product specifications and design are subject to change without notice for future improvement. • For further details, please check with our authorized dealer.
-
Page 3: Table Of Contents
CONTENTS Part 1. INDOOR UNIT................1 1. Specifications....................2 2. Dimensions....................3 2-1. Models: UIWH09AHWJ, UIWH12AHWJ, and UIWH15AHWJ .........3 3. Wiring diagrams ....................5 3-1. Models: UIWH09AHWJ, UIWH12AHWJ, and UIWH15AHWJ .........5 4. Capacity table....................6 4-1. Cooling capacity.......................6 4-2. Heating capacity ......................8 5. Fan performance ..................10 5-1. - Page 4 CONTENTS (continued) Part 2. OUTDOOR UNIT..............35 1. Specifications....................36 2. Dimensions....................37 2-1. Models: ROSH09AHHJ, ROSH12AHHJ, and ROSH15AHHJ ........37 3. Installation space ..................38 3-1. Models: ROSH09AHHJ, ROSH12AHHJ, and ROSH15AHHJ ........38 4. Refrigerant circuit ..................41 4-1. Models: ROSH09AHHJ and ROSH12AHHJ ..............41 4-2. Model: ROSH15AHHJ ....................42 5.
-
Page 5: Part 1. Indoor Unit
Part 1. INDOOR UNIT WALL MOUNTED TYPE: UIWH09AHWJ UIWH12AHWJ UIWH15AHWJ... -
Page 6: Specifications
1. Specifications Wall mounted Type Inverter heat pump Model name UIWH09AHWJ UIWH12AHWJ UIWH15AHWJ Power supply 208/230 V ~ 60 Hz Power supply intake Outdoor unit Available voltage range 188—253 V 2.64 3.52 4.25 Rated Btu/h 9,000 12,000 14,500 Cooling 0.90—3.60 0.90—4.00... -
Page 7: Dimensions
2. Dimensions 2-1. Models: UIWH09AHWJ, UIWH12AHWJ, and UIWH15AHWJ Unit: in (mm) 37 (940) 10-5/8 (270) 37 (940) 18-1/2 (470) 18-1/2 (470) 3-1/16 3-1/4 15-7/16 (393) (77) (83) 15-1/4 (387) for pipe inlet Ø 2-9/16 (65) Outline of unit for pipe inlet Ø 2-9/16 (65) -
Page 8: Installation Space Requirement
Provide sufficient installation space for product safety. Unit: in (mm) Outline of unit 2 (50) or more 2 (50) or more 5 (127) or more 6 (133) or more 60 (1,500) or more - 4 - 2-1. Models: UIWH09AHWJ, UIWH12AHWJ, and UIWH15AHWJ 2. Dimensions... -
Page 9: Wiring Diagrams
3. Wiring diagrams 3-1. Models: UIWH09AHWJ, UIWH12AHWJ, and UIWH15AHWJ - 5 - 3-1. Models: UIWH09AHWJ, UIWH12AHWJ, and UIWH15AHWJ 3. Wiring diagrams... -
Page 10: Capacity Table
Airflow Rate (AFR): For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP) For heating capacity: Total Capacity (TC) and Input Power (IP) 4-1. Cooling capacity ¢ Model: UIWH09AHWJ Indoor temperature °FDB °FWB °FDB... - Page 11 ¢ Model: UIWH12AHWJ Indoor temperature °FDB °FWB °FDB kBtu kBtu kBtu kBtu kBtu kBtu 10.34 9.52 0.28 11.53 9.58 0.28 12.72 10.47 0.29 13.11 11.30 0.29 13.87 11.21 0.29 14.67 11.96 0.30 10.26 9.44 0.33 11.44 9.47 0.33 12.62 10.34 0.35 13.01 11.19...
-
Page 12: Heating Capacity
4-2. Heating capacity ¢ Model: UIWH09AHWJ Indoor temperature °FDB °FDB °FWB kBtu/h kBtu/h kBtu/h kBtu/h 11.6 2.15 11.4 2.19 11.1 2.23 10.5 2.31 14.7 2.16 14.3 2.20 14.0 2.24 13.3 2.32 16.1 2.17 15.7 2.21 15.4 2.25 14.6 2.34 16.8 2.13... - Page 13 ¢ Model: UIWH15AHWJ Indoor temperature °FDB °FDB °FWB kBtu/h kBtu/h kBtu/h kBtu/h 17.1 2.77 16.7 2.82 16.3 2.88 15.5 2.98 19.6 2.78 19.1 2.84 18.6 2.89 17.7 3.00 22.0 2.79 21.5 2.85 21.0 2.90 19.9 3.01 22.7 2.68 22.2 2.73 21.6 2.78 20.5...
-
Page 14: Fan Performance
5. Fan performance 5-1. Air velocity distributions ¢ Models: UIWH09AHWJ and UIWH12AHWJ Fan speed Operation mode Measuring conditions HIGH (ft) Unit: ft/s (m/s) 3 (1.0) Top view 7 (2.0) Vertical airflow direction louver: Up Horizontal airflow direction louver: Center 2 (0.5) - Page 15 ¢ Model: UIWH15AHWJ Fan speed Operation mode Measuring conditions HIGH (ft) Unit: ft/s (m/s) 3 (1.0) Top view 7 (2.0) Vertical airflow direction louver: Up Horizontal airflow direction louver: Center 2 (0.5) (ft) (ft) Unit: ft/s (m/s) 3 (1.0) 2 (0.5) 7 (2.0) Top view Vertical airflow direction louver: Up...
-
Page 16: Airflow
5-2. Airflow ¢ Models: UIWH09AHWJ and UIWH12AHWJ Cooling Fan speed Airflow HIGH QUIET Heating Fan speed Airflow HIGH QUIET - 12 - 5-2. Airflow 5. Fan performance... - Page 17 ¢ Model: UIWH15AHWJ Cooling Fan speed Airflow HIGH QUIET Heating Fan speed Airflow HIGH QUIET - 13 - 5-2. Airflow 5. Fan performance...
-
Page 18: Operation Noise (Sound Pressure)
6. Operation noise (sound pressure) 6-1. Noise level curve ¢ Model: UIWH09AHWJ Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 HIGH HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET NC-20 NC-20 QUIET... -
Page 19: Sound Level Check Point
¢ Model: UIWH15AHWJ Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz... -
Page 20: Safety Devices
7. Safety devices Model Type of protection Protection form UIWH09AHWJ UIWH12AHWJ UIWH15AHWJ Circuit protection Current fuse (PCB*) 250 V, 3.15 A 302±27 °F (150±15 °C) Activate Fan motor speed down Thermal protector Fan motor protection program 248±27 °F (120±15 °C) -
Page 21: External Input And Output
8. External input and output With using external input and output functions, this product can be operated inter-connectedly with an external device. Connector Input Output Remarks CNA01 Control input — See external input/output CNB01 — Operation status output settings for details. CNB02 —... - Page 22 • Circuit diagram example • Contact capacity: DC 24 V or more, Indoor unit 10 mA or more. Communication kit Connected unit control PCB • *: Make the distance from the PCB to Example: Switch Connector the connected unit within 33 ft (10 •...
- Page 23 • Optional part Part name Model name Exterior External input wire External connect kit RXXWZXZ5 Communication kit RXTWBXF1 * For operating the external function, the wall mounted type requires the communication kit in addi- tion to the wire (RXXWZXZ5). - 19 - 8-1.
-
Page 24: External Output
8-2. External output With using external output function, operating status of this product can be transmitted to the exter- nal device, and also, this product can be inter-connected with the external device. ¢ Operation status output Circuit diagram example Indoor unit control PCB Communication kit... - Page 25 ¢ Error status output Circuit diagram example Indoor unit control PCB Communication kit Connected unit Connector DC 24 V Example: Relay unit Example: Display Relay power supply 33 ft (10 m)* Signal Optional parts Locally purchased • *: Make the distance from the PCB to the connected unit within 33 ft (10 m). •...
-
Page 26: Remote Controller
9. Remote controller 9-1. Wireless remote controller ¢ Overview SENSOR button Signal transmitter MODE button FAN button MIN. HEAT button ECONOMY button SWING button TEMP. button OUTDOOR UNIT SET button LOW NOISE button POWERFUL button WEEKLY button TIMER SETTING button Start/Stop ON/OFF button button... - Page 27 ¢ Specifications Controller Unit: in (mm) Top view 11/16 2-3/8 (17) (61) Front view Side view Size (H × W × D) in (mm) 8-1/16 × 2-3/8 × 11/16 (205 × 61 × 17) Weight oz (g) 4.4 (124) (without batteries) ...
-
Page 28: Function Settings
10. Function settings To adjust the functions of this product according to the installation environment, various types of function settings are available. NOTE: Incorrect settings can cause a product malfunction. 10-1. Function settings by using remote controller Some function settings can be changed on the remote controller. After confirming the setting proce- dure and the content of each function setting, select appropriate functions for your installation envi- ronment. - Page 29 NOTES: • The air conditioner custom code is set to prior to shipment. • If you do not know the air conditioner custom code setting, try each of the custom codes ( → → → ) until you find the code that operates the air conditioner. - 25 - 10-1.
-
Page 30: Contents Of Function Setting
¢ Contents of function setting Each function setting listed in this section is adjustable in accordance with the installation environ- ment. NOTE: Setting will not be changed if invalid numbers or setting values are selected. Function setting list Function no. Functions Filter sign 30/31... - Page 31 2) Room temperature control for indoor unit sensor NOTE: Before performing this setting, refer to Function 95. Depending on the installed environment, correction of the room temperature sensor may be re- quired. Select the appropriate control setting according to the installed environment. The temperature of the room temperature sensor is corrected as follows: Corrected temp.
- Page 32 4) Room temperature sensor switching (Only for wired remote controller) When using the wired remote controller temperature sensor, change the setting to "Both" (01). Function number Setting value Setting description Factory setting Indoor unit ♦ Both 00: Sensor on the indoor unit is active. 01: Sensors on both indoor unit and wired remote controller are active.
- Page 33 9) Room temperature control for wired remote controller sensor NOTE: Before performing this setting, refer to Function 95. Depending on the installed environment, correction of the room temperature sensor may be re- quired. Select the appropriate control setting according to the installed environment. To change this setting, set Function 42 to "Both"...
-
Page 34: 10-2.Custom Code Setting For Wireless Remote Controller
10-2. Custom code setting for wireless remote controller To interconnect the air conditioner and the wireless remote controller, assignment of the custom code for the wireless remote controller is required. NOTE: Air conditioner cannot receive a signal if the air conditioner has not been set for the custom code. -
Page 35: 10-3.Switching The Temperature Unit Of Remote Controller
10-3. Switching the temperature unit of remote controller Displayed temperature unit on the remote controller LCD can be switched between °F (Fahrenheit) and °C (Celsius). To change temperature unit, do as follows: Press the TEMP. (Up) button ( ) for at least 5 seconds to display the current temperature unit. (Factory setting: °F) Press the TEMP. -
Page 36: Accessories
11. Accessories Part name Exterior Q’ty Part name Exterior Q’ty Operating manual Cloth tape Installation manual Tapping screw (large) Wall hook bracket Tapping screw (small) Remote controller Air cleaning filter Battery Filter holder Remote controller Seal A holder (for 15 model) - 32 - 11. -
Page 37: Optional Parts
12. Optional parts 12-1. Controllers Exterior Part name Model name Summary Large and full-dot liquid crystal screen, wide and large keys easy to press, Monitor Mo 10:00AM user-intuitive arrow key. Mode Set temp. Wired remote ° F Wire type: Polar 3-wire Cool High UXRVNUM... - Page 38 - 34 - 12-2. Others 12. Optional parts...
-
Page 39: Part 2. Outdoor Unit
Part 2. OUTDOOR UNIT SINGLE TYPE: ROSH09AHHJ ROSH12AHHJ ROSH15AHHJ... -
Page 40: Specifications
1. Specifications Type Inverter heat pump Model name ROSH09AHHJ ROSH12AHHJ ROSH15AHHJ Power supply 208/230 V ~ 60 Hz Available voltage range 188—253 V Starting current Cooling 989 (1,680) 1,206 (2,050) Airflow rate CFM (m Heating 1,082 (1,840) Type × Q'ty Propeller fan ×... -
Page 41: Dimensions
2. Dimensions 2-1. Models: ROSH09AHHJ, ROSH12AHHJ, and ROSH15AHHJ Unit: in (mm) Top view 3/4 (19) 2-5/8 (67) 11/16 (18) 7/8 (23) 11-5/16 (288) 31-1/8 (790) 13-7/8 (352) Front view Side view 21-1/4 (540) Airflow 1(25) hole 8-1/4 (209) 3/8(10) hole 2-3/16 (55) ø13/16 (20) hole... -
Page 42: Installation Space
3. Installation space 3-1. Models: ROSH09AHHJ, ROSH12AHHJ, and ROSH15AHHJ ¢ Space requirement Provide sufficient installation space for product safety. Single outdoor unit installation • When the upper space is open: Unit: in (mm) When there are obstacles at the rear only. When there are obstacles at the rear and sides. -
Page 43: Multiple Outdoor Unit Installation
Multiple outdoor unit installation • When the upper space is open: Unit: in (mm) When there are obstacles at the rear only. When there are obstacles at the front only. 40 (1,000) or more 8 (200) or more When there are obstacles at the front and rear. -
Page 44: Outdoor Unit Installation In Multi-Row
Outdoor unit installation in multi-row Unit: in (mm) Single parallel unit arrangement Multiple parallel unit arrangement 4 (100) or more 8 (200) or more 40 (1,000) 80 (2,000) or more or more 8 (200) or more 16 (400) or more 40 (1,000) or more 20 (500) or more 8 (200) or more... -
Page 45: Refrigerant Circuit
4. Refrigerant circuit 4-1. Models: ROSH09AHHJ and ROSH12AHHJ Heat exchanger 3-way ( INDOOR ) valve 2-way valve Muffler Muffler 4-way valve Strainer Acccumlator Expansion valve Heat exchanger Strainer ( OUTDOOR ) Cooling Heating :Thermistor (Discharge temperature) :Thermistor (Outdoor temperature) :Thermistor (Heat exchanger out temperature) :Thermistor (Room temperature) :Thermistor (Pipe temperature) - 41 -... -
Page 46: Model: Rosh15Ahhj
4-2. Model: ROSH15AHHJ Heat exchanger (INDOOR) 3-Way 2-Way valve valve Muffler Muffler Receiver Strainer Expansion valve Heat exchanger (OUTDOOR) Strainer Cooling Heating : Thermistor (Discharge temp.) : Thermistor (Outdoor temp.) : Thermistor (Heat exchanger out temp.) : Thermistor (Room temp.) : Thermistor (Pipe temp.) - 42 - 4-2. -
Page 47: Wiring Diagrams
5. Wiring diagrams 5-1. Models: ROSH09AHHJ and ROSH12AHHJ SERVICE MONITOR 1 2 3 4 5 6 7 8 9 10 CN580 - 43 - 5-1. Models: ROSH09AHHJ and ROSH12AHHJ 5. Wiring diagrams... -
Page 48: Model: Rosh15Ahhj
5-2. Model: ROSH15AHHJ SERVICE MONITOR 1 2 3 4 5 6 7 8 9 10 CN950 - 44 - 5-2. Model: ROSH15AHHJ 5. Wiring diagrams... -
Page 49: Capacity Compensation Rate For Pipe Length And Height Difference
6. Capacity compensation rate for pipe length and height difference Height difference H Indoor unit is higher than outdoor unit Indoor unit is lower than outdoor unit Outdoor unit Indoor unit Outdoor unit Indoor unit Connection pipe Connection pipe 6-1. Models: ROSH09AHHJ and ROSH12AHHJ NOTE: Values mentioned in the table are calculated based on the maximum capacity. -
Page 50: Model: Rosh15Ahhj
6-2. Model: ROSH15AHHJ NOTE: Values mentioned in the table are calculated based on the maximum capacity. Pipe length COOLING 0.951 0.950 0.979 0.967 0.966 Indoor unit is higher than outdoor unit *1 0.988 0.983 0.971 0.970 0.994 0.992 0.987 0.975 0.974 1.002 1.000... -
Page 51: Models: Rosh09Ahhj And Rosh12Ahhj
7. Additional charge calculation 7-1. Models: ROSH09AHHJ and ROSH12AHHJ Refrigerant type R410A lb oz 2 lb 14 oz Refrigerant amount 1,300 ¢ Refrigerant charge 49 or less 66 (Max.) Total pipe length 0.22 oz/ft 15 or less 20 (Max.) +3.5 (20 g/m) Additional charge +100... -
Page 52: Airflow
8. Airflow 8-1. Models: ROSH09AHHJ and ROSH12AHHJ Cooling 1,680 Heating 1,840 1,082 8-2. Model: ROSH15AHHJ Cooling 2,050 1,206 Heating 1,840 1,082 - 48 - 8-1. Models: ROSH09AHHJ and ROSH12AHHJ 8. Airflow... -
Page 53: Operation Noise (Sound Pressure)
9. Operation noise (sound pressure) 9-1. Noise level curve ¢ Model: ROSH09AHHJ Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000... -
Page 54: Sound Level Check Point
¢ Model: ROSH15AHHJ Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz 9-2. -
Page 55: Electrical Characteristics
10. Electrical characteristics Model name ROSH09AHHJ ROSH12AHHJ ROSH15AHHJ Voltage 208/230~ Power supply Frequency MCA *1 14.4 18.2 Starting current MAX. CKT. BKR *3 Power cable Wiring Size spec. *2 Connection Limited wiring cable *4 ft (m) 68 (21) length *1: Minimum Circuit Ampacity (Calculation based on UL1995) *2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. -
Page 56: Safety Devices
11. Safety devices Model Type of Protection form protection ROSH09AHHJ ROSH12AHHJ ROSH15AHHJ 250 V, 20 A Current fuse (Near the 250 V, 5 A terminal) 250 V, 5 A 250 V, 25 A Circuit protection Current fuse (Filter PCB) — 250 V, 5 A 250 V, 15 A 250 V, 3.15 A... -
Page 57: Accessories
12. Accessories Part name Exterior Q’ty Part name Exterior Q’ty Installation manual - 53 - 12. Accessories...
