Ruud UA1724A Manual

• EcoNet Enabled product. The EcoNet Smart Home System
™
provides advanced air & water control for maximum energy
savings and ideal comfort.
• New composite base pan – dampens sound, captures louver
panels, eliminates corrosion and reduces number of fasteners
needed
• Powder coat paint system – for a long lasting professional finish
• The Two Stage Copeland Scroll
modulates between two capacity settings – 67% and
100% – providing more precise temperature control, lower
humidity and greater efficiency in comparison to single stage
compressors. It uses 70% fewer moving parts which also
increases efficiency and reliability.
• Modern cabinet aesthetics – increased curb appeal with visu-
ally appealing design
• Curved louver panels – provide ultimate coil protection,
enhance cabinet strength, and increased cabinet rigidity
• Optimized fan orifice – optimizes airflow and reduces unit
sound
• Rust resistant screws – confirmed through 1500-hour salt
spray testing
• PlusOne™ Expanded Valve Space – 3"-4"-5" service valve
space – provides a minimum working area of 27-square inches
for easier access
Ruud Achiever Plus
Ruud Achiever Plus
Two-Stage Air Conditioners
Two-Stage Air Conditioners
™ UltraTech ™ Compressor
Series
™
™ Series
UA17 Series
Efficiencies up to 17 SEER/13 EER
Nominal Sizes 2, 3, 4 & 5 Ton
[7.03, 10.6, 14.06 & 17.6 kW]
Cooling Capacities 17.3 to 60.5 kBTU
[5.7 to 17.7 kW]
Seasonal Energy Efficiency Ratio -
THIS MODEL
10.0
"Proper sizing and installation of equipment is critical to achieve optimal
performance. Split system air conditioners and heat pumps must be
matched with appropriate coil components to meet Energy Star.
Ask your Contractor for details or visit www.energystar.gov."
• PlusOne™ Triple Service Access – 15" wide, industry lead-
ing corner service access – makes repairs easier and faster.
The two fastener removable corner allows optimal access to
internal unit components. Individual louver panels come out
once fastener is removed, for faster coil cleaning and easier
cabinet reassembly
• Diagnostic service window with two-fastener opening –
provides access to the high and low pressure.
• External gauge port access – allows easy connection of
"low-loss" gauge ports
• Single-row condenser coil – makes unit lighter and allows
thorough coil cleaning to maintain "out of the box"
performance
• 35% fewer cabinet fasteners and fastener-free base – allow
for faster access to internal components and hassle-free
panel removal
• Service trays – hold fasteners or caps during service calls
• QR code – provides technical information on demand for
faster service calls
• Fan motor harness with extra long wires allows unit top to be
removed without disconnecting fan wire.
• High and low pressure standard on all models.
Air Conditioners
UA17 Series
SEER
17.00
USES LESS ENERGY 17.0
Rely on Ruud.™
FORM NO. A22-223 REV. 3
