- Page 1 Wireless WallSwitch User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0...
-
Page 2: Foreword
User’s Manual Foreword General This manual introduces the installation, functions and operations of the Wireless WallSwitch (hereinafter referred to as the "wallswitch"). Read carefully before using the device, and keep the manual safe for future reference. Model DHI-ARM7012-W2(868); DHI-ARM7012-W2 Safety Instructions The following signal words might appear in the manual. -
Page 3: About The Manual
User’s Manual About the Manual ● The manual is for reference only. Slight differences might be found between the manual and the product. ● We are not liable for losses incurred due to operating the product in ways that are not in compliance with the manual. -
Page 4: Important Safeguards And Warnings
User’s Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the wallswitch, hazard protection, and protection of property damage. Read carefully before using the wallswitch, and comply with the guidelines when using it. Operation Requirements ●... -
Page 5: Table Of Contents
User’s Manual Table of Contents Foreword ......................................I Important Safeguards and Warnings ..........................III 1 Introduction....................................1 1.1 Overview ..................................... 1 1.2 Technical Specifications .............................. 1 2 Checklist ......................................3 3 Appearance ....................................4 4 Adding the Wireless WallSwitch to the Hub ......................5 5 Installation .................................... -
Page 6: Introduction
User’s Manual 1 Introduction 1.1 Overview Wireless WallSwitch is a power switch that can be used to remotely control 110–240 VAC power. The output terminal N is directly connected to the power input terminal N, and the connection between the output terminal L and the power input terminal L is controlled through opening and closing of the built-in relay. - Page 7 User’s Manual Type Parameter Description Operating –10 °C to +55 °C (+14 °F to +131 °F) (indoor) Temperature Storage –10 °C to +55 °C (+14 °F to +131 °F) Temperature Operating 10%–90% (RH) Humidity Storage Humidity 10%–90% (RH) DHI-ARM7012-W2(868) and DHI-ARM7012-W2: Power Supply 100–240 VAC, 50/60 Hz Product...
-
Page 8: Checklist
User’s Manual 2 Checklist Figure 2-1 Checklist Table 2-1 Checklist Quantit Item Name Item Name Quantity WallSwitch Quick start guide Double-sided adhesive Legal and regulatory tape information QR code – – –... -
Page 9: Appearance
User’s Manual 3 Appearance Figure 3-1 Appearance Table 3-1 Structure Name Description Antenna Sends and receives signals. Indicator ● Press and hold the button for 2 seconds, and then the system enters pairing mode. Solid on for 1 second, then off for 0.5 seconds, ◇... -
Page 10: Adding The Wireless Wallswitch To The Hub
User’s Manual 4 Adding the Wireless WallSwitch to the Hub Before you connect wallswitch to the hub, install the DMSS app to your phone. This manual uses iOS as an example. ● Make sure that the version of the DMSS app is 1.99.200 or later, and the hub is V1.001.0000004.0.R.221104 or later. -
Page 11: Installation
User’s Manual 5 Installation Before installation, add the wallswitch to the hub and check the signal strength of the installation location. We recommend installing the wallswitch in a place with a signal strength of at least 2 bars. 5.1 Wiring ●... -
Page 12: Installing The Wireless Wallswitch
User’s Manual Figure 5-1 Wire 5.2 Installing the Wireless WallSwitch Figure 5-2 Attach the wallswitch... -
Page 13: Configuration
User’s Manual 6 Configuration You can view and edit general information of the wallswitch. 6.1 Viewing Status On the hub screen, select a wallswitch from the peripheral list, and then you can view the status of the wallswitch. Table 6-1 Status Parameter Value The status for whether the functions of the repeater are... - Page 14 User’s Manual Table 6-2 Parameter description Parameter Description ● View wallswitch name, type, SN and device model. Device Configuration ● Edit wallswitch name, and then tap Save to save configuration. Area Select the area to which the wallswitch is assigned. Whether send sensor information to the alarm hub.
- Page 15 User’s Manual Parameter Description ● Select from high, low, and automatic. ● The higher transmission power levels are, the further transmissions can travel, but power consumption increases. Transit Power ● If you select Low, the wallswitch will enter into reduced sensitivity mode.
-
Page 16: Appendix 1 Cybersecurity Recommendations
IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. Below are some tips and recommendations from Dahua on how to create a more secured security system. - Page 17 User’s Manual The account lock feature is enabled by default, and we recommend you to keep it on to guarantee the account security. If an attacker attempts to log in with the wrong password several times, the corresponding account and the source IP address will be locked. 5.
- Page 18 ● Enable IP/MAC address filtering function to limit the range of hosts allowed to access the device. More information Please visit Dahua official website security emergency response center for security announcements and the latest security recommendations.
- Page 19 User’s Manual...
