PUZZLE FIGHTER™
CAUTION
IMPROPER
INSTALLATION
OF THE
JAMMA
HARNESS TO
THE
GAME
CARTRIDGE WILL CAUSE DAMAGE
TO THE ENCLOSED
PCB.
WARNING
DISASSEMBLY OF
EITHER
GAME
CARTRIDGE
WILL VOID
YOUR
WARRANTY.
GAME
CARTRIDGE
INSTALLA TION
"FULL"
KIT
21
.
Using
the supplied
wood
screws, fasten the
game
cartridge case
to the control panel
shelf, as
shown
in
Figure
1
1.
"B"
KIT
15.
To
remove
the existing
"B"
cartridge
from
the
"A"
cartridge, pull the old case clamps
apart (see Figure
12).
Carefully
remove
the old
' ;
B"
cartridge
and
install
the
new
"B'
cartridge.
Re-install the case clamps.
Case Clamp
Figure
11:
Case Mounting
ii
Connect
the
JAMMA
harness connector
and
the
auxiliary cable connector
to
the
"A'
cartridge.
If
your
cabinet
is
equipped with
Q-SOUND,
also attach the
audio
cables.
23.
Power-up
the
game
and
set
all
operator
adjustable options by
pressing the
TEST
switch.
Follow
the instructions
under
the
TEST
MENU
section
of
this
manual.
"A" Cartridge
Figure
12
:
Case
Clamp
Installation
16.
Power-up
the
game
and
set
all
operator
adjustable options by
pressing
the
TEST
switch.
Follow
the instructions under
the
TEST
MENU
section
of
this
manual.
