StreetSiren Manual de usuario
Actualizado10 de enero de 2024
StreetSiren es un dispositivo inalámbrico de alerta exterior con un volumen de
sonido de hasta 113 dB. Equipado con un marco LED brillante y una batería
preinstalada, StreetSiren se puede instalar, con gurar y operar rápidamente de
forma autónoma hasta por 5 años.
Al conectarse al sistema Ajax a través del protocolo de radio seguro
Jeweller
,
StreetSiren se comunica con el
centro
a una distancia de hasta 1.500 m en la línea
de visión.
El dispositivo se con gura mediante las
aplicaciones Ajax
para iOS, Android,
macOS y Windows. El sistema noti ca a los usuarios de todos los eventos
mediante noti caciones automáticas, SMS y llamadas (si están activadas).
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AJAX Systems StreetSiren
Summary of Contents for AJAX Systems StreetSiren
- Page 1 StreetSiren Manual de usuario Actualizado10 de enero de 2024 StreetSiren es un dispositivo inalámbrico de alerta exterior con un volumen de sonido de hasta 113 dB. Equipado con un marco LED brillante y una batería preinstalada, StreetSiren se puede instalar, con gurar y operar rápidamente de forma autónoma hasta por 5 años.
-
Page 2: Elementos Funcionales
Plus El sistema Ajax se puede conectar a una estación central de monitoreo de una empresa de seguridad. Comprar sirena de calle StreetSiren Elementos funcionales 1. marco LED 2. Indicador luminoso 3. Zumbador de sirena detrás de la red metálica. - Page 3 00:00 00:12 StreetSiren mejora signi cativamente la e ciencia del sistema de seguridad. Con una alta probabilidad, su fuerte señal de alarma y su indicación luminosa son su cientes para atraer la atención de los vecinos y disuadir a los intrusos.
- Page 4 StreetSiren switches off automatically after failing to connect to the hub. To retry the connection, you do not need to switch it off. If the device has already been assigned to another hub, switch it off and follow the standard pairing procedure.
- Page 5 Icons Icons display some of the StreetSiren states. You can view them in the Ajax app, in the Devices menu. Icon Value Shows Jeweller signal strength between the hub/range extender and StreetSiren The recommended value is 2-3 bars Battery charge level...
- Page 6 2. Select StreetSiren from the list. Parameter Value The temperature of the device which is measured on the processor and changes gradually. Acceptable error between the value in the app and temperature at the installation site is 2°C. Temperature When the device detects a temperature change at least for 2°C, the value is updated.
- Page 7 What is Attenuation Test radio Displayed if the siren is working via a signal range extender Battery level of the device. Two states available: Battery Charge How battery charge is displayed in Ajax apps The status of the tamper that responds to demount or opening of the body: Open —...
- Page 8 The volume level is measured 1 m away from the siren Duration of the audible alarm: from 3 seconds to 3 minutes. Alarm Duration The duration is set in 3-second intervals Alert if Moved The state of the accelerometer alarm Disabled —...
- Page 9 Device No. Number of the device loop (zone) Settings To change the StreetSiren settings in the Ajax app: 1. Select the hub if you have several of them or if you are using the PRO app. 2. Go to the Devices...
- Page 10 Name The name can contain up to 12 Cyrillic characters or up to 24 Latin symbols Selecting the virtual room to which StreetSiren Room DoubleDeck is assigned. The room name you can see at noti cations in the event feed Selecting the group to which the siren is assigned.
- Page 11 Switching the siren to the Jeweller signal strength test mode. The test allows you to check the signal level between the hub and StreetSiren and determine the optimal installation location Jeweller Signal Strength Test What is Jeweller Signal Strength Test...
- Page 12 Switches the device to the volume test mode Volume Test What is Volume Level Test Switching the StreetSiren to the signal fade test mode (available in siren with rmware version 3.50 and later) Signal Attenuation Test What is Attenuation Test...
- Page 13 When this option is enabled, the siren warns of Arming/Disarming arming and disarming by lighting of the LED frame and by a short beep If enabled, the siren alerts you by backlighting the LED frame and a short beep when arming and disarming the system from the Night mode Night Mode Activation/Deactivation What is Night mode...
- Page 14 When enabled, the siren beeps 1 to 4 times to indicate that opening detectors in the Disarmed system mode were triggered. The feature is available for StreetSiren with Chime on opening rmware version 3.73.1.0 and later What is Chime How to set up Chime...
- Page 15 The siren can respond to the tamper alarm of devices and detectors. The option is disabled by default. Note that the tamper reacts to the opening and closing of the body even if the system is not armed! What is a tamper For the siren to respond to tamper triggering, in Ajax app: 1.
- Page 16 The siren can inform about triggerings in armed system by means of LED indication. The option functions as follows: 1. The system registers the alarm. 2. The siren plays an alarm (duration and volume depend on settings). 3. The lower right corner of the siren LED frame blinks twice (about once every 3 seconds) until the system is disarmed.
- Page 17 Noti cations are con gured in two stages: setting up sirens and setting up opening detectors. Learn more about Chime Chime is supported by StreetSiren with rmware version 3.73.1.0 and later. Siren settings 1. Go to the Devices menu.
- Page 18 The speci ed Beep volume also applies to the volume of siren noti cations when arming/disarming and for the entry/exit delays. 7. Click Back to save the settings. 8. Repeat steps 2–7 for other sirens on which you want to enable the noti cations.
- Page 19 00:00 00:06 Event Indication Emits an acoustic signal (the duration depends Alarm on the settings) and the LED frame blinks red The siren LED frame blinks red twice in the lower right corner about every 3 seconds until the system is disarmed. An alarm was detected in the armed system (if after-alarm indication is enabled) The indication turns on after the siren has...
-
Page 20: Performance Testing
The LED frame corner lights up and goes out when the system is armed/disarmed, the alarm Low battery goes off, in case of dismounting or unauthorized opening Performance Testing The Ajax system allows conducting tests for checking the functionality of connected devices. -
Page 21: Installation Process
If the device has low or unstable signal strength even after moving, use a radio signal range extender StreetSiren is protected from dust/moisture (IP54 class), which means it can be placed outdoors. The recommended installation height is 2.5 meters and higher. Such a height hinders access to the device for intruders. -
Page 22: Maintenance
Using the double-sided adhesive tape is not recommended either for a temporary nor permanent xing. 3. Put StreetSiren on the SmartBracket panel and turn it clockwise. Fix the device with a screw. Fixing the siren to the panel with a screw makes it di cult for intruders to remove the device quickly. -
Page 23: Tech Specs
Tech specs Type of noti cation Sound and light (LEDs) Sound noti cation volume 85 dB to 113 dB at a distance of 1 m (adjustable) Operating frequency of the piezo annunciator 3.5 ± 0.5 kHz Protection against dismounting Accelerometer Jeweller Radio communication protocol Learn more... -
Page 24: Complete Set
4. Installation kit 5. Quick start guide Warranty Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase and does not apply to the pre-installed battery. If the device does not work correctly, you should rst contact the support service —... - Page 25 Subscribe to the newsletter about safe life. No spam Correo electrónico Subscribe...
