AJAX Systems Superior StreetSiren Plus Jeweller User Manual

Wireless siren for outdoor and indoor use
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Superior StreetSiren Plus Jeweller user
Superior StreetSiren Plus Jeweller is a wireless siren for outdoor and
indoor use. Superior edition. It is equipped with an LED frame and a
speaker that produces a sound volume of up to 107 dB. The siren can also
be powered by a remote 12 V⎓ power supply.
Superior StreetSiren Plus Jeweller operates within an Ajax system and
communicates with a
distance of up 1,500 meters in an open space. Superior StreetSiren Plus
Jeweller operates for up to 10 years on pre-installed batteries.
This product line is developed for projects. Only accredited Ajax Systems
partners can sell, install, and administer Superior products.
Superior and Baseline product lines are mutually compatible. This opens up
numerous possibilities for building systems of any configuration.
manual
Updated November 20, 2024
hub
via the protected
Jeweller
protocol at a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Superior StreetSiren Plus Jeweller and is the answer not in the manual?

Questions and answers

Related Manuals for AJAX Systems Superior StreetSiren Plus Jeweller

Summary of Contents for AJAX Systems Superior StreetSiren Plus Jeweller

  • Page 1 Updated November 20, 2024 Superior StreetSiren Plus Jeweller is a wireless siren for outdoor and indoor use. Superior edition. It is equipped with an LED frame and a speaker that produces a sound volume of up to 107 dB. The siren can also be powered by a remote 12 V⎓...

  • Page 2: Functional Elements

    Functional elements 1. LED frame. 2. LED indicator in the lower right corner of the siren. 3. SmartBracket mounting panel. 4. On/off button. 5. First tamper. It triggers when SmartBracket is unlocked. . Second tamper. It triggers if an attempt to detach the siren from the surface or SmartBracket is detected.

  • Page 3: Operating Principle

    12. Perforated parts to run the wires. 13. Recesses to drill the holes conveniently. Compatible hubs and range extenders The siren is compatible with a hub with OS Malevich 2.26 or later versions. Check devices compatibility Operating principle Siren performs four tasks: 1.

  • Page 4: Jamming Detection

    This feature prevents the siren from being turned off. Jamming detection Superior StreetSiren Plus Jeweller features a radio interference detection algorithm. When a potential jamming attempt occurs, the algorithm detects a sudden increase or decrease in the noise level. It takes into account not only the amplitude of the noise but also the duration over time.
  • Page 5 (CMS) using SurGard (Contact ID), SIA (DC-09), ADEMCO 685, and other protocols Superior StreetSiren Plus Jeweller can transmit the following events: 1. The lid is open/closed. 2. The mounting panel is locked/unlocked.
  • Page 6 (4G) Jeweller and third-party security control panels. To pair Superior StreetSiren Plus Jeweller with the hub, you must locate the siren at the same secured site as the system (within the range of the hub radio network). If you plan to use the...
  • Page 7 The power button is recessed into the enclosure and is tight to press. You can use a thin, hard object, such as a pencil, to press it. To be paired with the hub, Superior StreetSiren Plus Jeweller must be within the hub’s radio communication range, i.e., at the same guarded site.
  • Page 8 No connection with the hub or radio signal range extender via Jeweller. The device battery is low. Icons The icons display some Superior StreetSiren Plus Jeweller states. To access them: 1. Sign in to the Ajax app 2. Select a hub.
  • Page 9 Displayed if the battery charge is 25% or below. Displayed if the mounting panel is unlocked. Learn more Displayed if a high level of radio interference is detected. Learn more Displayed if Signal attenuation test is set to Attenuation or Max. Learn more radio signal range Displayed when the siren operates via a...
  • Page 10 Learn more States The states include information about the siren and its operating parameters. The states of Superior StreetSiren Plus Jeweller can be found in Ajax apps 1. Go to the Devices tab. 2. Select Superior StreetSiren Plus Jeweller from the list.
  • Page 11 Status of connection between a hub (or a range extender) and Superior StreetSiren Plus Jeweller: Online — the siren is added to a hub (or Connection via Jeweller a range extender). Offline — the siren is not added to a hub (or a range extender).
  • Page 12 integrity of the device enclosure and the mounting panel is not compromised. Normal state. What is a tamper The status of the siren’s tamper, which responds if SmartBracket is unlocked: Unlocked — SmartBracket is unlocked, or the integrity of the siren enclosure is compromised.
  • Page 13 Settings of the siren LED indication: Off — an LED indication is off. Armed — the siren’s LED indicator flashes once every 3 seconds when the LED indication system is in Armed mode. Always — the siren’s LED indicator flashes once every 3 seconds, regardless of the siren security mode.
  • Page 14 entering/leaving, or opening detector triggering: Quiet — 85 dB volume. Loud — 97 dB volume. Very loud — 107 dB volume. The volume level is measured 1 m away from the siren. Shows whether the noise level in the radio channel is high: OK —...
  • Page 15 Device ID siren enclosure and its package. Device No. Siren loop (zone) number. Settings To change Superior StreetSiren Plus Jeweller settings in the Ajax apps 1. Go to the Devices tab. 2. Select Superior StreetSiren Plus Jeweller from the list. 3. Go to Settings by clicking on the gear icon 4.
  • Page 16 The name can contain up to 12 Cyrillic characters or up to 24 Latin characters. Selecting the virtual room to which Superior StreetSiren Plus Jeweller is assigned. Room The room name is displayed in the text of SMS and notifications in the events feed. Selecting when an audible alarm must be enabled: Always —...
  • Page 17 Loud — 97 dB volume. Very loud — 107 dB volume. The volume level is measured 1 m away from the siren. The duration of the sound signal in case of an alarm is from 3 seconds to 3 minutes. Alarm duration Sets in increments of 3 seconds.
  • Page 18 Full-frame backlight — the entire LED frame lights up. This feature is available only when an external power supply is connected. If the feature is enabled, the security Radio interference detection company and users will be notified of a sabotage attempt. Opens the siren notification settings.
  • Page 19 No — the siren operates in normal mode and transmits all events. Entirely — the siren does not execute system commands or participate in automation scenarios, and the system ignores siren alarms and other notifications. Lid only — the system only ignores notifications of the siren’s tamper triggering.
  • Page 20 Beeps settings Event Meaning Beep on armed mode change When this feature is enabled, the siren Arming/disarming warns of arming and disarming by lighting the LED frame and making a short beep. If the feature is enabled, the siren notifies users by backlighting the LED frame and making a short beep when the system is armed/disarmed in Night mode.
  • Page 21 Notifies a user that the Delay when entering time is running out. There are 4 options to choose from when the fast beep should start: Never Fast beep on Entry delay expiration Last 5 seconds Last 10 seconds Last 15 seconds Notifies a user that the Delay when leaving time is running out.
  • Page 22 The volume level is measured 1 m away from the siren. Setting the siren response to device alarms In Ajax apps, you can separately configure the siren response to alarms of each detector in the system. This feature is helpful if you do not need to activate the siren in case of a specific device’s alarm, for example, when LeaksProtect Jeweller triggers.
  • Page 23 1. Open the Ajax app 2. Go to the Devices tab. 3. Go to the device Settings 4. Select the Service menu. 5. Go to Sounds and alerts. . Enable the Alert with siren if lid of hub or any detector is open option. 7.
  • Page 24 The siren can inform about triggerings in the armed system with LED indication. The feature functions as follows: 1. The system registers the alarm. 2. The siren plays an alarm (duration and volume depend on the settings). 3. The siren uses a light indication with a pattern according to the LED indication type setting: The LED indicator in the lower right corner flashes twice, about every 3 seconds.
  • Page 25 3. Select devices for Specific alert on alarm cancellation and Specific alert on alarm abort features. 4. Tap Back to apply the settings. Learn more about ANSI/SIA CP-01-2019 system requirements * Superior StreetSiren Plus Jeweller is not certified according to ANSI/SIA CP-01-2019.
  • Page 26 How to set up Chime Chime is a sound signal that indicates the triggering of the opening detectors when the system is disarmed. The feature is used, for example, in stores to notify employees that someone has entered the building. Notifications are configured in two stages: setting up sirens and setting up opening detectors.

  • Page 27: Functionality Testing

    frame flashes 3 times, and then the siren turns off. The system is armed The LED frame flashes once, and the siren (if the LED indication is enabled) emits a short beep. The system is disarmed The LED frame flashes twice, and the siren (if the LED indication is enabled) emits two short beeps.

  • Page 28: Selecting The Installation Site

    . Run the test. Selecting the installation site The placement of Superior StreetSiren Plus Jeweller is determined by its distance from the hub and the presence of obstacles that impede the passage of the radio signal, such as walls, inter-floor constructions, or large-size objects at the site.

  • Page 29: Installation

    the Devices tab shows the signal strength: Three bars — excellent signal strength. Two bars — good signal strength. One bar — low signal strength, stable operation is not guaranteed. Crossed out icon — no signal. Check the Jeweller signal strength before performing a final installation. With a signal strength of one or zero bars, we do not guarantee the stable operation of the device.
  • Page 30 Superior StreetSiren Plus Jeweller operates on pre-installed batteries for up to 10 years and is equipped with terminals for connecting a 12 V⎓ power supply unit.

  • Page 31: Installing The Siren

    Installing the siren Before installing the siren, ensure that the optimal location that complies with the requirements of this manual is selected. The recommended installation height is 2.5 m or more. This will make it difficult for intruders to access the device. If you try to detach the siren from the mounting panel, the system will raise an alarm.

  • Page 32: Technical Specifications

    Technical specifications All technical specifications of Superior StreetSiren Plus Jeweller Compliance with standards Setup in compliance with EN requirements...
  • Page 33 Manufactured by “AS Manufacturing” LLC Subscribe to the newsletter about safe life. No spam Email Subscribe...
