Example:
X-axis ball screw pitch = 5.000mm
Motor Encoder = 2500 pulses, multiplication factor = 4
Gear Ratio= 5:1(Servomotor rotates 5 turns = ball screw Rotates 1 turn)
Resolution =
=
X-axis resolution denominator= 10
X-axis resolution numerator= 1
14. X-axis resolution multiplication factor
15. Z-axis resolution multiplication factor
□
Format= (Default=4)
Setting= 1, encoder pulses multiplied by 1.
Setting= 2, encoder pulses multiplied by 2.
Setting= 4, encoder pulses multiplied by 4.
Only one factor is selected at a time.
Note:
The multiplication factor setting is dependent on the rigidness of the
structure. The vibration of the motor during structure power feeding
suggests that the rigidness of the structure is too high. This can be
corrected by reducing the multiplication factor of the axis concerned.
Ex: When the encoder pulses at 2000 rpm, and the multiplication factor is
set to 2, the pulses are 2000×2 = 4000.
16. X-axis maximum feed rate setting.
17. Z-axis maximum feed rate setting.
□□□□□
Format=
Note: The setting is in integer format.
Ex: If you set the Z-axis to 5000, it indicates that your highest feed rate is
5000 mm per minute.
1
5000
×
5
2500 ×4
1
10
(Default =10000) Unit: mm/min
4 - 7
Chapter IV MCM Parameter Settings
